SMD050F-2 Information
SMD050F-2 by TE Connectivity is a Non-linear Resistor.
Non-linear Resistors are under the broader part category of Resistors.
Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.
Price & Stock for SMD050F-2
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
|
Bristol Electronics | 7876 |
|
RFQ | ||
|
|
Bristol Electronics | Min Qty: 11 | 5495 |
|
$0.1268 / $0.4875 | Buy Now |
|
|
Bristol Electronics | 3779 |
|
RFQ | ||
|
|
Bristol Electronics | 1989 |
|
RFQ | ||
|
|
Bristol Electronics | 1858 |
|
RFQ | ||
|
|
Bristol Electronics | 1750 |
|
RFQ | ||
|
|
Bristol Electronics | 1242 |
|
RFQ | ||
|
|
Bristol Electronics | 1182 |
|
RFQ | ||
|
|
Bristol Electronics | 1094 |
|
RFQ | ||
|
|
Quest Components | RESISTOR, TEMPERATURE DEPENDENT, PTC, SURFACE MOUNT | 5938 |
|
$0.2267 / $0.7555 | Buy Now |
Part Details for SMD050F-2
SMD050F-2 CAD Models
SMD050F-2 Part Data Attributes
|
|
SMD050F-2
TE Connectivity
Buy Now
Datasheet
|
Compare Parts:
SMD050F-2
TE Connectivity
PTC Thermistor, Surface Mount, CHIP, 2920, ROHS COMPLIANT
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Transferred | |
| Ihs Manufacturer | TE CONNECTIVITY LTD | |
| Package Description | CHIP, 2920, ROHS COMPLIANT | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8533.40.80.70 | |
| Factory Lead Time | 8 Weeks | |
| Samacsys Manufacturer | TE Connectivity | |
| Additional Feature | RESISTANCE VALUE 0.87 OHM AT 20 DEG CEL | |
| JESD-609 Code | e3 | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Shape | RECTANGULAR PACKAGE | |
| Rated Power Dissipation (P) | 1.5 W | |
| Resistor Type | PTC THERMISTOR | |
| Surface Mount | YES | |
| Terminal Finish | Matte Tin (Sn) - with Nickel (Ni) barrier | |
| Terminal Placement | DUAL | |
| Terminal Shape | FLAT | |
| Thermistor Application | OVERLOAD PROTECTION |
Alternate Parts for SMD050F-2
This table gives cross-reference parts and alternative options found for SMD050F-2. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of SMD050F-2, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| SMD0304 | TE Connectivity | Check for Price | RESISTOR, TEMPERATURE DEPENDENT, PTC, SURFACE MOUNT | SMD050F-2 vs SMD0304 |
| SMD050F | Littelfuse Inc | Check for Price | PTC Thermistor, | SMD050F-2 vs SMD050F |
| MF-SM050 | Bourns Inc | Check for Price | PTC Resettable Fuse, Surface Mount, ROHS COMPLIANT | SMD050F-2 vs MF-SM050 |
SMD050F-2 Frequently Asked Questions (FAQ)
-
The recommended soldering temperature profile for SMD050F-2 is a peak temperature of 240°C to 250°C, with a dwell time of 1-2 seconds. It's essential to follow the JEDEC J-STD-020 standard for reflow soldering.
-
To ensure reliability in high-vibration applications, it's crucial to follow proper mounting and soldering techniques. Additionally, consider using a vibration-dampening material, such as a silicone adhesive, to secure the component to the PCB.
-
The maximum operating temperature range for SMD050F-2 is -40°C to 125°C. However, it's essential to note that the component's performance may degrade at extreme temperatures, so it's crucial to consider the specific application requirements.
-
While SMD050F-2 is designed to operate in a variety of environments, it's not recommended for use in extremely humid or high-moisture environments. If exposure to moisture is unavoidable, consider applying a conformal coating to protect the component.
-
The recommended PCB layout and land pattern for SMD050F-2 can be found in the TE Connectivity application note or the IPC-7351 standard. It's essential to follow these guidelines to ensure proper soldering and component reliability.
