Microcontrollers and Processors / Microcontrollers / ATMEGA8-16AU
Datasheets
ATMEGA8-16AU by:

IC MCU 8BIT 8KB FLASH 32TQFP

Part Details for ATMEGA8-16AU by Microchip Technology Inc

Results Overview of ATMEGA8-16AU by Microchip Technology Inc

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Industrial Automation

ATMEGA8-16AU Information

ATMEGA8-16AU by Microchip Technology Inc is a Microcontroller.
Microcontrollers are under the broader part category of Microcontrollers and Processors.

Microcontrollers (MCUs) are small, low-power integrated circuits used to control embedded systems. Microcontrollers are primarily used to automate and control devices. Read more about Microcontrollers and Processors on our Microcontrollers and Processors part category page.

Price & Stock for ATMEGA8-16AU

Part # Distributor Description Stock Price Buy
DISTI # 01M6900
Newark Mcu, 8Bit, Atmega, 16Mhz, Tqfp-32, Product Range:Avr Atmega Family Atmega8 Series Microcontrollers, Cpu Speed:16Mhz, Program Memory Size:8Kb, Ram Memory Size:1Kb, No. Of Pins:32Pins, Mcu Case Style:Tqfp, No. Of I/O S:23I/O S, Rohs Compliant: Yes |Microchip ATMEGA8-16AU RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk 1589
  • 1 $4.6400
  • 10 $4.5800
  • 25 $4.5200
  • 50 $4.4500
  • 100 $4.3900
  • 500 $4.2800
$4.2800 / $4.6400 Buy Now
DISTI # 25AC6142
Newark 16Mhz, Tqfp, Ind Temp, Green Rohs Compliant: Yes |Microchip ATMEGA8-16AU RoHS: Compliant Min Qty: 250 Package Multiple: 1 Date Code: 0 Container: Bulk 0
  • 100 $3.4100
$3.4100 Buy Now
DISTI # ATMEGA8-16AU-ND
DigiKey IC MCU 8BIT 8KB FLASH 32TQFP Min Qty: 1 Lead time: 6 Weeks Container: Tray 1562
In Stock
  • 1 $3.0900
  • 25 $2.8400
  • 100 $2.7250
$2.7250 / $3.0900 Buy Now
DISTI # ATMEGA8-16AU
Avnet Americas 8 Bit MCU, AVR ATmega Family ATmega8 Series Microcontrollers, AVR, 16 MHz, 8 KB, 32 Pins, TQFP - Trays (Alt: ATMEGA8-16AU) RoHS: Compliant Min Qty: 250 Package Multiple: 1 Lead time: 6 Weeks, 0 Days Container: Tray 15
  • 250 $2.6618
  • 260 $2.6399
  • 510 $2.6180
  • 1,300 $2.5962
  • 2,500 $2.5744
$2.5744 / $2.6618 Buy Now
DISTI # 556-ATMEGA8-16AU
Mouser Electronics 8-bit Microcontrollers - MCU 8kB Flash 0.5kB EEPROM 23 I/O Pins RoHS: Compliant 4198
  • 1 $3.0900
  • 25 $2.8400
  • 100 $2.7200
$2.7200 / $3.0900 Buy Now
DISTI # ATMEGA8-16AU
Microchip Technology Inc 16MHZ, TQFP, IND TEMP, GREEN, TQFP, Projected EOL: 2039-11-02 COO: Philippines, Thailand ECCN: EAR99 RoHS: Compliant Lead time: 6 Weeks, 0 Days Container: Tray 93

Alternates Available
  • 1 $3.0900
  • 25 $2.8400
  • 100 $2.5700
  • 1,000 $2.3600
  • 5,000 $2.2600
$2.2600 / $3.0900 Buy Now
Future Electronics ATmega Series 8 KB Flash 1 KB SRAM 16 MHz 8-Bit Microcontroller - TQFP-32 RoHS: Compliant pbFree: Yes Min Qty: 1 Package Multiple: 1 Lead time: 6 Weeks Container: Tray 250
Tray
  • 1 $2.7900
  • 15 $2.7300
  • 30 $2.7000
  • 100 $2.6500
  • 200 $2.5900
$2.5900 / $2.7900 Buy Now
Onlinecomponents.com MCU - 8-bit AVR - 8KB Flash - 1KB SRAM - 16MHz - 5V - 32-Pin TQFP - Tray RoHS: Compliant 398 In Stock
6250 Factory Stock
  • 5 $3.2500
  • 50 $2.9900
  • 100 $2.9400
  • 250 $2.8300
  • 500 $2.6900
  • 1,000 $2.6500
  • 2,500 $2.6100
  • 5,000 $2.5700
$2.5700 / $3.2500 Buy Now
DISTI # 69913898
Verical MCU 8-bit AVR RISC 8KB Flash 5V 32-Pin TQFP Tray RoHS: Compliant Min Qty: 20 Package Multiple: 5 Date Code: 2332 Americas - 395
  • 20 $4.2250
  • 50 $3.8870
  • 100 $3.8220
  • 250 $3.6790
  • 500 $3.4970
$3.4970 / $4.2250 Buy Now
DISTI # 87359619
Verical MCU 8-bit AVR RISC 8KB Flash 5V 32-Pin TQFP Tray RoHS: Compliant Min Qty: 16 Package Multiple: 1 Americas - 281
  • 16 $4.4100
$4.4100 Buy Now
Future Electronics ATmega Series 8 KB Flash 1 KB SRAM 16 MHz 8-Bit Microcontroller - TQFP-32 Min Qty: 1 Package Multiple: 1 250
null
  • 1 $2.7900
  • 15 $2.7300
  • 30 $2.7000
  • 100 $2.6500
  • 200 $2.5900
$2.5900 / $2.7900 Buy Now
DISTI # ATMEGA8-16AU
TME IC: AVR microcontroller, TQFP32, 2.7÷5.5VDC, Ext.inter: 2, Cmp: 1 Min Qty: 1 317
  • 1 $3.6500
  • 10 $3.5000
  • 25 $3.3000
  • 100 $3.0000
$3.0000 / $3.6500 Buy Now
NAC 16MHZ, TQFP, IND TEMP, GREEN - Package: 32 TQFP 7x7x1mm TRAY RoHS: Compliant Min Qty: 250 Package Multiple: 250 Container: Tray 0
  • 1 $3.2100
  • 100 $2.9100
  • 500 $2.7300
  • 1,000 $2.6600
$2.6600 / $3.2100 Buy Now
DISTI # ATMEGA8-16AU
Avnet Silica 8 Bit MCU AVR ATmega Family ATmega8 Series Microcontrollers AVR 16 MHz 8 KB 32 Pins TQFP (Alt: ATMEGA8-16AU) RoHS: Compliant Min Qty: 250 Package Multiple: 250 Lead time: 8 Weeks, 0 Days Silica - 0
Buy Now
DISTI # ATMEGA8-16AU
EBV Elektronik 8 Bit MCU AVR ATmega Family ATmega8 Series Microcontrollers AVR 16 MHz 8 KB 32 Pins TQFP (Alt: ATMEGA8-16AU) RoHS: Compliant Min Qty: 250 Package Multiple: 250 Lead time: 7 Weeks, 0 Days EBV - 0
Buy Now
Master Electronics MCU - 8-bit AVR - 8KB Flash - 1KB SRAM - 16MHz - 5V - 32-Pin TQFP - Tray RoHS: Compliant 398 In Stock
6250 Factory Stock
  • 5 $3.2500
  • 50 $2.9900
  • 100 $2.9400
  • 250 $2.8300
  • 500 $2.6900
  • 1,000 $2.6500
  • 2,500 $2.6100
  • 5,000 $2.5700
$2.5700 / $3.2500 Buy Now
Win Source Electronics IC MCU 8BIT 8KB FLASH 32TQFP 4500
  • 16 $3.7822
  • 33 $3.5382
  • 51 $3.4163
  • 73 $3.1722
  • 95 $3.0503
  • 119 $2.9282
$2.9282 / $3.7822 Buy Now

Part Details for ATMEGA8-16AU

ATMEGA8-16AU CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

ATMEGA8-16AU Part Data Attributes

Parametric Data
ATMEGA8-16AU Microchip Technology Inc
Buy Now Datasheet
Compare Parts:
ATMEGA8-16AU Microchip Technology Inc IC MCU 8BIT 8KB FLASH 32TQFP
Pbfree Code Yes
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer MICROCHIP TECHNOLOGY INC
Package Description 7 X 7 MM, 1 MM HEIGHT, 0.80 MM PITCH, GREEN, PLASTIC, MS-026ABA, TQFP-32
Reach Compliance Code compliant
ECCN Code EAR99
HTS Code 8542.31.00.01
Factory Lead Time 6 Weeks
Samacsys Manufacturer Microchip
Has ADC YES
Address Bus Width
Bit Size 8
Boundary Scan NO
CPU Family AVR RISC
Clock Frequency-Max 16 MHz
DAC Channels NO
DMA Channels NO
External Data Bus Width
Format FIXED POINT
Integrated Cache NO
JESD-30 Code S-PQFP-G32
JESD-609 Code e3
Length 7 mm
Low Power Mode YES
Moisture Sensitivity Level 3
Number of External Interrupts 2
Number of I/O Lines 23
Number of Serial I/Os 1
Number of Terminals 32
Number of Timers 3
On Chip Data RAM Width 8
On Chip Program ROM Width 8
Operating Temperature-Max 85 °C
Operating Temperature-Min -40 °C
PWM Channels YES
Package Body Material PLASTIC/EPOXY
Package Code TQFP
Package Equivalence Code TQFP32,.35SQ,32
Package Shape SQUARE
Package Style FLATPACK, THIN PROFILE
Peak Reflow Temperature (Cel) 260
Qualification Status Not Qualified
RAM (bytes) 1024
ROM (words) 8192
ROM Programmability FLASH
Seated Height-Max 1.2 mm
Speed 16 MHz
Supply Current-Max 15 mA
Supply Voltage-Max 5.5 V
Supply Voltage-Min 5 V
Supply Voltage-Nom 5 V
Surface Mount YES
Technology CMOS
Temperature Grade INDUSTRIAL
Terminal Finish MATTE TIN
Terminal Form GULL WING
Terminal Pitch 0.8 mm
Terminal Position QUAD
Time@Peak Reflow Temperature-Max (s) 40
Width 7 mm
uPs/uCs/Peripheral ICs Type MICROCONTROLLER, RISC

Alternate Parts for ATMEGA8-16AU

This table gives cross-reference parts and alternative options found for ATMEGA8-16AU. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of ATMEGA8-16AU, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
ATMEGA8-16AI Atmel Corporation Check for Price RISC Microcontroller, 8-Bit, FLASH, AVR RISC CPU, 16MHz, CMOS, PQFP32, 7 X 7 MM, 1 MM HEIGHT, 0.80 MM PITCH, PLASTIC, MS-026ABA, TQFP-32 ATMEGA8-16AU vs ATMEGA8-16AI
ATMEGA8-16AUR Microchip Technology Inc Check for Price IC MCU 8BIT 8KB FLASH 32TQFP ATMEGA8-16AU vs ATMEGA8-16AUR
ATMEGA8-16AU-SL383 Atmel Corporation Check for Price Microcontroller, 8-Bit, FLASH, AVR RISC CPU, 16MHz, CMOS, PQFP32, 7 X 7 MM, 1 MM HEIGHT, 0.80 MM PITCH, GREEN, PLASTIC, MS-026ABA, TQFP-32 ATMEGA8-16AU vs ATMEGA8-16AU-SL383
Part Number Manufacturer Composite Price Description Compare
ATMEGA8-16AL Atmel Corporation Check for Price RISC Microcontroller, 8-Bit, FLASH, 16MHz, CMOS, PQFP32, 7 X 7 MM, 1 MM HEIGHT, 0.80 MM PITCH, PLASTIC, MS-026ABA, TQFP-32 ATMEGA8-16AU vs ATMEGA8-16AL
ATMEGA8-16AC Atmel Corporation Check for Price RISC Microcontroller, 8-Bit, FLASH, AVR RISC CPU, 16MHz, CMOS, PQFP32, 7 X 7 MM, 1 MM HEIGHT, 0.80 MM PITCH, PLASTIC, MS-026ABA, TQFP-32 ATMEGA8-16AU vs ATMEGA8-16AC
ATMEGA8-16AURA3 Microchip Technology Inc Check for Price RISC Microcontroller, 8-Bit, FLASH, 16MHz, CMOS, PQFP32 ATMEGA8-16AU vs ATMEGA8-16AURA3
ATMEGA8-16AU Atmel Corporation Check for Price RISC Microcontroller, 8-Bit, FLASH, AVR RISC CPU, 16MHz, CMOS, PQFP32, 7 X 7 MM, 1 MM HEIGHT, 0.80 MM PITCH, GREEN, PLASTIC, MS-026ABA, TQFP-32 ATMEGA8-16AU vs ATMEGA8-16AU

ATMEGA8-16AU Related Parts

ATMEGA8-16AU Frequently Asked Questions (FAQ)

  • The ATMEGA8-16AU can operate at a maximum clock frequency of 16 MHz.

  • The ATMEGA8-16AU consumes approximately 0.1 μA in sleep mode.

  • Yes, the ATMEGA8-16AU is designed to operate in a wide temperature range of -40°C to 85°C and can be used in harsh environments.

  • The ATMEGA8-16AU has 8 KB of flash memory available for program storage.

  • No, the ATMEGA8-16AU does not have a built-in USB interface. It is not suitable for USB applications.
