3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for VIPER26HD by STMicroelectronics
Results Overview of VIPER26HD by STMicroelectronics
- Distributor Offerings: (15 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (1 option)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Environmental Monitoring
Virtual Reality (VR), Augmented Reality (AR), and Vision Systems
Automotive
VIPER26HD Information
VIPER26HD by STMicroelectronics is an Other Signal Circuit.
Other Signal Circuits are under the broader part category of Signal Circuits.
A signal is an electronic means of transmitting information, either as an analog signal with continuous values or a digital signal with discrete values. Signals are used in various systems and networks. Read more about Signal Circuits on our Signal Circuits part category page.
Price & Stock for VIPER26HD
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
497-10742-5-ND
|
DigiKey | IC OFFLINE SWITCH FLYBACK 16SO Min Qty: 1 Lead time: 18 Weeks Container: Tube |
1424 In Stock |
|
$0.4943 / $1.0600 | Buy Now |
|
DISTI #
VIPER26HD
|
Avnet Americas | Off Line Converter 16-Pin SO N Tube - Rail/Tube (Alt: VIPER26HD) RoHS: Compliant Min Qty: 2000 Package Multiple: 1000 Lead time: 18 Weeks, 0 Days Container: Tube | 0 |
|
$0.4268 / $0.4538 | Buy Now |
|
DISTI #
511-VIPER26HD
|
Mouser Electronics | AC/DC Converters VIPer Plus 800V Fixed freq 115 kHz RoHS: Compliant | 15952 |
|
$0.5040 / $1.0600 | Buy Now |
|
DISTI #
V36:1790_06568510
|
Arrow Electronics | AC to DC Switching Converter Flyback 127kHz Tube 16-Pin SO N RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 18 Weeks Date Code: 2340 | Americas - 11000 |
|
$0.4276 / $0.4523 | Buy Now |
|
DISTI #
E02:0323_03155787
|
Arrow Electronics | AC to DC Switching Converter Flyback 127kHz Tube 16-Pin SO N RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 18 Weeks Date Code: 2427 | Europe - 5630 |
|
$0.5009 / $1.0020 | Buy Now |
|
DISTI #
V99:2348_18462647
|
Arrow Electronics | AC to DC Switching Converter Flyback 127kHz Tube 16-Pin SO N RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 2311 | Americas - 145 |
|
$0.5084 | Buy Now |
|
|
STMicroelectronics | Fixed frequency VIPer plus family COO: Thailand RoHS: Compliant Min Qty: 1 | 15948 |
|
$0.5300 / $1.0400 | Buy Now |
|
|
Future Electronics | VIPER26 Series 23.5 V 70% 127 kHz Fixed Frequency VIPerTM Plus Family - SO-16 RoHS: Compliant pbFree: Yes Min Qty: 1000 Package Multiple: 50 Lead time: 20 Weeks Container: Tube | 0Tube |
|
$0.4600 / $0.5100 | Buy Now |
|
DISTI #
86894771
|
Verical | AC to DC Switching Converter Flyback 127kHz Tube 16-Pin SO N RoHS: Compliant Min Qty: 12 Package Multiple: 1 Date Code: 2427 | Americas - 5628 |
|
$0.5047 / $0.7335 | Buy Now |
|
|
Future Electronics | VIPER26 Series 23.5 V 70% 127 kHz Fixed Frequency VIPerTM Plus Family - SO-16 Min Qty: 1 Package Multiple: 1 |
5 null |
|
$0.4800 / $0.5450 | Buy Now |
Part Details for VIPER26HD
VIPER26HD CAD Models
VIPER26HD Part Data Attributes
|
|
VIPER26HD
STMicroelectronics
Buy Now
Datasheet
|
Compare Parts:
VIPER26HD
STMicroelectronics
Fixed frequency VIPer plus family
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | STMICROELECTRONICS | |
| Part Package Code | SOIC | |
| Pin Count | 16 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 18 Weeks | |
| Samacsys Manufacturer | STMicroelectronics | |
| Analog IC - Other Type | ANALOG CIRCUIT | |
| Control Mode | CURRENT-MODE | |
| JESD-30 Code | R-PDSO-G16 | |
| JESD-609 Code | e4 | |
| Length | 9.9 mm | |
| Moisture Sensitivity Level | 3 | |
| Number of Functions | 1 | |
| Number of Terminals | 16 | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SOP | |
| Package Equivalence Code | SOP16,.25 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.75 mm | |
| Supply Voltage-Max (Vsup) | 23.5 V | |
| Supply Voltage-Min (Vsup) | 11.5 V | |
| Supply Voltage-Nom (Vsup) | 14 V | |
| Surface Mount | YES | |
| Switching Frequency-Max | 127 kHz | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 1.27 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 3.9 mm |
Alternate Parts for VIPER26HD
This table gives cross-reference parts and alternative options found for VIPER26HD. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of VIPER26HD, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| VIPER26HDTR | STMicroelectronics | $0.6699 | Fixed frequency VIPer plus family | VIPER26HD vs VIPER26HDTR |
VIPER26HD Frequently Asked Questions (FAQ)
-
STMicroelectronics recommends a 4-layer PCB with a solid ground plane, and a separate layer for the high-voltage power supply. The layout should also minimize the loop area of the high-frequency circuits to reduce EMI.
-
To ensure the VIPER26HD operates within its SOA, monitor the device's junction temperature, output current, and input voltage. Use thermal management techniques, such as heat sinks or thermal interfaces, to keep the junction temperature below 150°C.
-
When selecting a transformer for the VIPER26HD, consider the transformer's turns ratio, inductance, and core material. Ensure the transformer is designed for high-frequency operation and can handle the required power levels.
-
Optimize the output filter by selecting the right component values and layout to minimize EMI. Use a common-mode choke and a differential-mode filter to reduce conducted EMI. Ensure the filter is designed to meet the required attenuation levels for regulatory compliance.
-
Use a combination of oscilloscopes, signal generators, and power analyzers to verify the VIPER26HD's performance. Measure the output voltage, current, and power factor to ensure the device is operating within its specifications.
