LT3032IDE#PBF Information
LT3032IDE#PBF by Analog Devices Inc is a Linear Regulator IC.
Linear Regulator ICs are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for LT3032IDE#PBF
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
51AK8553
|
Newark | Ldo, Adj, 1.22V To 20V, 0.15A/-0.15A, Output Type:Adjustable, Input Voltage Min:2.3V, Input Voltage Max:20V, No. Of Outputs:2Outputs, Output Voltage Min:1.22V, Output Voltage Max:20V, Polarity:Positive/Negative, No. Of Pins:14Pins Rohs Compliant: Yes |Analog Devices LT3032IDE#PBF RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 0 |
|
$3.8600 / $7.2000 | Buy Now |
|
DISTI #
505-LT3032IDE#PBF-ND
|
DigiKey | IC REG LINEAR POS/NEG ADJ 14-DFN Min Qty: 1 Lead time: 10 Weeks Container: Tube |
2746 In Stock |
|
$3.8375 / $8.7700 | Buy Now |
|
DISTI #
584-LT3032IDE#PBF
|
Mouser Electronics | LDO Voltage Regulators 2x 150mA Pos/Neg L N L Drop Lin Reg RoHS: Compliant | 9051 |
|
$3.8300 / $7.2000 | Buy Now |
|
DISTI #
V36:1790_06424260
|
Arrow Electronics | LDO Regulator Neg/Pos ±1.22V to ±20V 0.15A/-0.15A 14-Pin DFN EP Tube RoHS: Compliant Min Qty: 91 Package Multiple: 91 Lead time: 10 Weeks | Americas - 89 |
|
$3.6700 / $3.7050 | Buy Now |
|
DISTI #
V99:2348_06424260
|
Arrow Electronics | LDO Regulator Neg/Pos ±1.22V to ±20V 0.15A/-0.15A 14-Pin DFN EP Tube RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 10 Weeks | Americas - 47 |
|
$3.8960 / $7.1250 | Buy Now |
|
|
Analog Devices Inc | 2x 150mA Pos/Neg L N L Drop Li Package Multiple: 91 | 550 |
|
$3.0700 / $8.7700 | Buy Now |
|
DISTI #
80621060
|
Verical | LDO Regulator Neg/Pos ±1.22V to ±20V 0.15A/-0.15A 14-Pin DFN EP Tube RoHS: Compliant Min Qty: 89 Package Multiple: 89 Date Code: 2407 | Americas - 89 |
|
$3.6700 / $3.7050 | Buy Now |
|
DISTI #
87004318
|
Verical | LDO Regulator Neg/Pos ±1.22V to ±20V 0.15A/-0.15A 14-Pin DFN EP Tube RoHS: Compliant Min Qty: 2 Package Multiple: 1 Date Code: 2407 | Americas - 47 |
|
$3.6400 | Buy Now |
|
DISTI #
LT3032IDE#PBF
|
Richardson RFPD | VOLTAGE REGULATOR RoHS: Compliant Min Qty: 1 | 52 |
|
$3.9700 / $4.9000 | Buy Now |
Part Details for LT3032IDE#PBF
LT3032IDE#PBF CAD Models
LT3032IDE#PBF Part Data Attributes
|
|
LT3032IDE#PBF
Analog Devices Inc
Buy Now
Datasheet
|
Compare Parts:
LT3032IDE#PBF
Analog Devices Inc
LT3032IDE#PBF
|
| Pbfree Code | No | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ANALOG DEVICES INC | |
| Package Description | 4 X 3 MM, 0.75 MM HEIGHT, LEAD FREE, PLASTIC, DFN-14 | |
| Pin Count | 14 | |
| Manufacturer Package Code | 05-08-1731 | |
| Reach Compliance Code | compliant | |
| Samacsys Manufacturer | Analog Devices | |
| JESD-30 Code | R-PDSO-N14 | |
| JESD-609 Code | e3 | |
| Length | 4 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 14 | |
| Operating Temperature TJ-Max | 125 °C | |
| Operating Temperature TJ-Min | -40 °C | |
| Output Current1-Max | 0.15 A | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | HVSON | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Regulator Type | FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR | |
| Seated Height-Max | 0.8 mm | |
| Surface Mount | YES | |
| Technology | BIPOLAR | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 3 mm |
