Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for CL-SB-12A-02T by Nidec Copal Electronics Corporation
Results Overview of CL-SB-12A-02T by Nidec Copal Electronics Corporation
- Distributor Offerings: (3 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Energy and Power Systems
Renewable Energy
Automotive
CL-SB-12A-02T Information
CL-SB-12A-02T by Nidec Copal Electronics Corporation is a Slide Switch.
Slide Switches are under the broader part category of Switches.
Electrical switches are binary devices that control the flow of current in a circuit by either allowing or preventing the flow of electrons. Read more about Switches on our Switches part category page.
Price & Stock for CL-SB-12A-02T
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
CL-SB-12A-02T
|
Avnet Americas | Switch Slide ON-ON SPDT Top 200mA 12VDC 10000Cycles J-Lead T/R - Tape and Reel (Alt: CL-SB-12A-02T) RoHS: Compliant Min Qty: 500 Package Multiple: 500 Lead time: 15 Weeks, 0 Days Container: Reel | 0 |
|
$0.7296 / $0.8976 | Buy Now |
|
DISTI #
87176027
|
Verical | Switch Slide ON ON SPDT Top Slide 0.2A 12VDC J-Bend SMD T/R RoHS: Compliant Min Qty: 75 Package Multiple: 1 | Americas - 460 |
|
$1.1400 / $1.3600 | Buy Now |
|
DISTI #
CL-SB-12A-02T
|
Avnet Abacus | Switch Slide ONON SPDT Top 200mA 12VDC 10000Cycles JLead TR (Alt: CL-SB-12A-02T) RoHS: Compliant Min Qty: 500 Package Multiple: 500 Lead time: 14 Weeks, 0 Days | Abacus - 0 |
|
Buy Now |
Part Details for CL-SB-12A-02T
CL-SB-12A-02T CAD Models
CL-SB-12A-02T Part Data Attributes
|
|
CL-SB-12A-02T
Nidec Copal Electronics Corporation
Buy Now
Datasheet
|
Compare Parts:
CL-SB-12A-02T
Nidec Copal Electronics Corporation
SWITCH SLIDE SPDT 200MA 12V
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | NIDEC COPAL ELECTRONICS CORP | |
| Reach Compliance Code | compliant | |
| Factory Lead Time | 15 Weeks | |
| Samacsys Manufacturer | Nidec Copal | |
| Actuator Length | 0.079 inch | |
| Actuator Material | POLYAMIDE | |
| Actuator Type | TOP TYPE | |
| Body Breadth | 3.5 mm | |
| Body Height | 3.5 mm | |
| Body Length or Diameter | 8.5 mm | |
| Center Contact Material | COPPER ALLOY | |
| Center Contact Plating | GOLD | |
| Contact Current(DC)-Max | 0.2 A | |
| Contact (DC) Max Rating R Load | .2A@12VDC | |
| Contact Resistance | 0.07 mΩ | |
| Contact Timing | BREAK-BEFORE-MAKE | |
| Contact Voltage(DC)-Max | 12 V | |
| Dielectric Withstand Volts | 500VAC V | |
| Electrical Life | 10000 Cycle(s) | |
| End Contact Material | COPPER ALLOY | |
| End Contact Plating | GOLD | |
| Housing Material | POLYPHENYLENE SULPHIDE | |
| Insulation Resistance | 100000000 Ω | |
| Insulator Material | POLYPHENYLENE SULPHIDE | |
| Mounting Feature | SURFACE MOUNT-STRAIGHT | |
| Number of Positions | 2 | |
| Operating Force-Max | 2.5 N | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Packing Method | TR | |
| Solderability | REFLOW | |
| Surface Mount | NO | |
| Switch Action | LATCHED | |
| Switch Function | SPDT | |
| Switch Type | SLIDE SWITCH | |
| Terminal Material | COPPER ALLOY | |
| Termination Type | SOLDER |
CL-SB-12A-02T Frequently Asked Questions (FAQ)
-
Store the component in a dry, cool place, away from direct sunlight, with a temperature range of 10°C to 30°C and humidity below 70%. Avoid storing in areas with high electromagnetic interference.
-
Handle the component in an ESD-protected environment, wear an ESD wrist strap or use ESD-safe tools, and avoid touching the component's pins or leads.
-
The recommended soldering temperature is 250°C (±5°C) with a soldering time of 3-5 seconds. Avoid exceeding 260°C to prevent damage to the component.
-
While the component is designed to withstand some vibration, it's recommended to consult with Nidec Copal Electronics Corporation or a qualified engineer to determine the suitability of CL-SB-12A-02T for high-vibration applications.
-
Use a soft, dry brush or a lint-free cloth to gently remove any debris or contaminants. Avoid using chemicals, solvents, or ultrasonic cleaning methods, as they may damage the component.
