ADC0848CCVX/NOPB Information
ADC0848CCVX/NOPB by Texas Instruments is an Analog to Digital Converter.
Analog to Digital Converters are under the broader part category of Converters.
A converter is an electrical circuit that transforms electric energy into a different form that will support a elecrical load needed by a device. Read more about Converters on our Converters part category page.
Price & Stock for ADC0848CCVX/NOPB
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
2156-ADC0848CCVX/NOPB-296-ND
|
DigiKey | ADC0848 8-BIT MICROPROCESSOR COM Min Qty: 56 Lead time: 1 Weeks Container: Bulk MARKETPLACE PRODUCT |
370 In Stock |
|
$5.4100 | Buy Now |
|
DISTI #
296-35230-1-ND
|
DigiKey | IC ADC 8BIT SAR 28PLCC Min Qty: 1 Lead time: 6 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
12 In Stock |
|
$7.0530 / $9.0700 | Buy Now |
|
DISTI #
85962348
|
Verical | 8-Channel Single ADC SAR 25ksps 8-bit Parallel 28-Pin PLCC T/R RoHS: Compliant Min Qty: 58 Package Multiple: 1 Date Code: 1801 | Americas - 370 |
|
$5.2000 / $6.5000 | Buy Now |
|
|
Rochester Electronics | 8-Bit Microprocessor Compatible A/D Converter with Multiplexer Option RoHS: Compliant Status: End of Life / Last Time Buy Min Qty: 1 | 370 |
|
$4.1600 / $5.2000 | Buy Now |
Part Details for ADC0848CCVX/NOPB
ADC0848CCVX/NOPB CAD Models
ADC0848CCVX/NOPB Part Data Attributes
|
|
ADC0848CCVX/NOPB
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
ADC0848CCVX/NOPB
Texas Instruments
8-Bit, 8-channel, microprocessor compatible A/D converter with multiplexer option 28-PLCC -40 to 85
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Part Package Code | QLCC | |
| Package Description | GREEN, PLASTIC, LCC-28 | |
| Pin Count | 28 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Analog Input Voltage-Max | 6 V | |
| Analog Input Voltage-Min | ||
| Conversion Time-Max | 60 µs | |
| Converter Type | ADC, SUCCESSIVE APPROXIMATION | |
| JESD-30 Code | S-PQCC-J28 | |
| JESD-609 Code | e3 | |
| Length | 11.43 mm | |
| Linearity Error-Max (EL) | 0.3906% | |
| Moisture Sensitivity Level | 2A | |
| Number of Analog In Channels | 8 | |
| Number of Bits | 8 | |
| Number of Functions | 1 | |
| Number of Terminals | 28 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Bit Code | BINARY | |
| Output Format | PARALLEL, 8 BITS | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | QCCJ | |
| Package Equivalence Code | LDCC28,.5SQ | |
| Package Shape | SQUARE | |
| Package Style | CHIP CARRIER | |
| Peak Reflow Temperature (Cel) | 245 | |
| Qualification Status | Not Qualified | |
| Sample Rate | 0.033 MHz | |
| Seated Height-Max | 4.57 mm | |
| Supply Current-Max | 2.5 mA | |
| Supply Voltage-Min | 4.5 V | |
| Supply Voltage-Nom | 5 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | J BEND | |
| Terminal Pitch | 1.27 mm | |
| Terminal Position | QUAD | |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED | |
| Width | 11.43 mm |
Alternate Parts for ADC0848CCVX/NOPB
This table gives cross-reference parts and alternative options found for ADC0848CCVX/NOPB. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of ADC0848CCVX/NOPB, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| ADC0848CCVX/NOPB | National Semiconductor Corporation | Check for Price | IC 8-CH 8-BIT SUCCESSIVE APPROXIMATION ADC, PARALLEL ACCESS, PQCC28, PLASTIC, LCC-28, Analog to Digital Converter | ADC0848CCVX/NOPB vs ADC0848CCVX/NOPB |
| ADC0848CCVX | National Semiconductor Corporation | Check for Price | IC 8-CH 8-BIT SUCCESSIVE APPROXIMATION ADC, PARALLEL ACCESS, PQCC28, PLASTIC, LCC-28, Analog to Digital Converter | ADC0848CCVX/NOPB vs ADC0848CCVX |
