74HCT193DB-Q100J Information
74HCT193DB-Q100J by Nexperia is a Counter.
Counters are under the broader part category of Logic Components.
Digital logic governs the behavior of signals in electronic circuits, enabling complex decisions based on simple binary inputs (yes/no). Logic components perform operations from these signals. Read more about Logic Components on our Logic part category page.
Part Details for 74HCT193DB-Q100J
74HCT193DB-Q100J CAD Models
74HCT193DB-Q100J Part Data Attributes
|
|
74HCT193DB-Q100J
Nexperia
Buy Now
Datasheet
|
Compare Parts:
74HCT193DB-Q100J
Nexperia
74HC193-Q100; 74HCT193-Q100 - Presettable synchronous 4-bit binary up/down counter@en-us SSOP1 16-Pin
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | NEXPERIA | |
| Part Package Code | SSOP1 | |
| Package Description | 5.30 MM, PLASTIC, MO-150, SOT338-1, SSOP-16 | |
| Pin Count | 16 | |
| Manufacturer Package Code | SOT338-1 | |
| Reach Compliance Code | compliant | |
| Samacsys Manufacturer | Nexperia | |
| Count Direction | BIDIRECTIONAL | |
| Family | HCT | |
| JESD-30 Code | R-PDSO-G16 | |
| JESD-609 Code | e4 | |
| Length | 6.2 mm | |
| Load/Preset Input | YES | |
| Logic IC Type | BINARY COUNTER | |
| Mode of Operation | SYNCHRONOUS | |
| Moisture Sensitivity Level | 1 | |
| Number of Bits | 4 | |
| Number of Functions | 1 | |
| Number of Terminals | 16 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SSOP | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Propagation Delay (tpd) | 65 ns | |
| Screening Level | AEC-Q100 | |
| Seated Height-Max | 2 mm | |
| Supply Voltage-Max (Vsup) | 5.5 V | |
| Supply Voltage-Min (Vsup) | 4.5 V | |
| Supply Voltage-Nom (Vsup) | 5 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | NICKEL PALLADIUM GOLD | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Trigger Type | POSITIVE EDGE | |
| Width | 5.3 mm | |
| fmax-Min | 13 MHz |
