74ALVC32D,112 Information
74ALVC32D,112 by Nexperia is a Gate.
Gates are under the broader part category of Logic Components.
Digital logic governs the behavior of signals in electronic circuits, enabling complex decisions based on simple binary inputs (yes/no). Logic components perform operations from these signals. Read more about Logic Components on our Logic part category page.
Price & Stock for 74ALVC32D,112
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
2156-74ALVC32D,112-ND
|
DigiKey | IC GATE OR 4CH 2-INP 14SO Min Qty: 2270 Lead time: 1 Weeks Container: Bulk MARKETPLACE PRODUCT |
2270 In Stock |
|
$0.1700 | Buy Now |
|
DISTI #
86087176
|
Verical | OR Gate 4-Element 2-IN CMOS 14-Pin SO Bulk RoHS: Compliant Min Qty: 2198 Package Multiple: 1 Date Code: 2001 | Americas - 39900 |
|
$0.1275 / $0.1706 | Buy Now |
|
|
Rochester Electronics | OR Gate, ALVC/VCX/A Series, 4-Func, 2-Input, CMOS, PDSO14 RoHS: Compliant Status: Obsolete Min Qty: 1 | 40595 |
|
$0.1020 / $0.1645 | Buy Now |
|
DISTI #
74ALVC32D,112
|
Avnet Silica | OR Gate Quad 2 Input 14 Pins SOIC 74ALVC32 (Alt: 74ALVC32D,112) RoHS: Compliant Min Qty: 57 Package Multiple: 57 | Silica - 0 |
|
Buy Now | |
|
DISTI #
74ALVC32D,112
|
EBV Elektronik | OR Gate Quad 2 Input 14 Pins SOIC 74ALVC32 (Alt: 74ALVC32D,112) RoHS: Compliant Min Qty: 57 Package Multiple: 57 | EBV - 0 |
|
Buy Now |
Part Details for 74ALVC32D,112
74ALVC32D,112 CAD Models
74ALVC32D,112 Part Data Attributes
|
|
74ALVC32D,112
Nexperia
Buy Now
Datasheet
|
Compare Parts:
74ALVC32D,112
Nexperia
74ALVC32 - Quad 2-input OR gate@en-us SOIC 14-Pin
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | NEXPERIA | |
| Part Package Code | SOIC | |
| Package Description | PLASTIC, MS-012, SOT-108-1, SOP-14 | |
| Pin Count | 14 | |
| Manufacturer Package Code | SOT108-1 | |
| Reach Compliance Code | compliant | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 4 Weeks | |
| Samacsys Manufacturer | Nexperia | |
| Family | ALVC/VCX/A | |
| JESD-30 Code | R-PDSO-G14 | |
| JESD-609 Code | e4 | |
| Length | 8.65 mm | |
| Logic IC Type | OR GATE | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 4 | |
| Number of Inputs | 2 | |
| Number of Terminals | 14 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SOP | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Propagation Delay (tpd) | 4.7 ns | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.75 mm | |
| Supply Voltage-Max (Vsup) | 3.6 V | |
| Supply Voltage-Min (Vsup) | 1.65 V | |
| Supply Voltage-Nom (Vsup) | 2.7 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | NICKEL PALLADIUM GOLD | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 1.27 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 3.9 mm |
