Switches / Rotary Switches / 1-1825007-0
Datasheets
1-1825007-0 by: TE Connectivity

Rotary Coded Switch, 10 Positions, Decimal, Latched, 0.4A, 20VDC, Wire Terminal, Flush Type Actuator, Panel Mount

Part Details for 1-1825007-0 by TE Connectivity

Results Overview of 1-1825007-0 by TE Connectivity

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Industrial Automation Energy and Power Systems Transportation and Logistics Renewable Energy Automotive Robotics and Drones

1-1825007-0 Information

1-1825007-0 by TE Connectivity is a Rotary Switch.
Rotary Switches are under the broader part category of Switches.

Electrical switches are binary devices that control the flow of current in a circuit by either allowing or preventing the flow of electrons. Read more about Switches on our Switches part category page.

Price & Stock for 1-1825007-0

Part # Distributor Description Stock Price Buy
DISTI # 21R1932
Newark Drd10Setr04=Rot Dip,10P, smt |Te Connectivity 1-1825007-0 RoHS: Not Compliant Min Qty: 5000 Package Multiple: 1 Date Code: 0 Container: Bulk 0
  • 2,500 $2.8500
$2.8500 Buy Now
DISTI # 1-1825007-0-ND
DigiKey SWITCH ROTARY DIP BCD 0.4VA 20V Min Qty: 5000 Lead time: 20 Weeks Container: Tape & Reel (TR) Temporarily Out of Stock
  • 5,000 $2.6905
$2.6905 Buy Now
DISTI # 1-1825007-0
Avnet Americas Switch DIP SP10T 10 Flush Screwdriver 20VAC 20VDC 0.4VA Gull Wing 2.54mm SMD T/R - Bulk (Alt: 1-1825007-0) RoHS: Compliant Min Qty: 5000 Package Multiple: 5000 Lead time: 19 Weeks, 3 Days Container: Bulk 0
  • 5,000 $2.6367
  • 10,000 $2.6232
  • 20,000 $2.6098
  • 30,000 $2.5963
  • 40,000 $2.5829
$2.5829 / $2.6367 Buy Now
DISTI # 72032576
RS Switch, Drd10Setr04=Rot DIP,10P, Smt Min Qty: 5000 Package Multiple: 1 Container: Bulk 0
  • 5,000 $3.7900
  • 10,000 $3.6000
  • 20,000 $3.4900
$3.4900 / $3.7900 RFQ
DISTI # AMP1-1825007-0
Heilind Electronics DRD10SETR04=ROT DIP,10P,SMT Americas - 0 in Stock
  • 5,000 $3.1653
$3.1653 Buy Now
Onlinecomponents.com DRD10SETR04=ROT DIP,10P,SMT RoHS: Compliant 0
  • 1,250 $8.0100
  • 2,500 $4.0900
  • 3,750 $2.7800
  • 5,000 $2.7300
$2.7300 / $8.0100 Buy Now
DISTI # AMP1-1825007-0
Interstate Connecting Components DRD10SETR04=ROT DIP,10P,SMT 0
  • 5,000 $3.1653
$3.1653 Buy Now
DISTI # 1-1825007-0
Richardson RFPD GENERAL PURPOSE MECHANICAL SWITCH RoHS: Compliant Min Qty: 1 0
RFQ
DISTI # 1-1825007-0
Avnet Abacus Switch DIP SP10T 10 Flush Screwdriver 20VAC 20VDC 04VA Gull Wing 254mm SMD TR (Alt: 1-1825007-0) RoHS: Compliant Min Qty: 5000 Package Multiple: 5000 Lead time: 22 Weeks, 0 Days Abacus - 0
Buy Now
DISTI # 1-1825007-0
Avnet Abacus Switch DIP SP10T 10 Flush Screwdriver 20VAC 20VDC 04VA Gull Wing 254mm SMD TR (Alt: 1-1825007-0) RoHS: Compliant Min Qty: 5000 Package Multiple: 1 Lead time: 24 Weeks, 0 Days Abacus - 0
Buy Now
Master Electronics DRD10SETR04=ROT DIP,10P,SMT RoHS: Compliant 0
  • 1,250 $8.0100
  • 2,500 $4.0900
  • 3,750 $2.7800
  • 5,000 $2.7300
$2.7300 / $8.0100 Buy Now

Part Details for 1-1825007-0

1-1825007-0 Part Data Attributes

Parametric Data
1-1825007-0 TE Connectivity
Buy Now Datasheet
Compare Parts:
1-1825007-0 TE Connectivity Rotary Coded Switch, 10 Positions, Decimal, Latched, 0.4A, 20VDC, Wire Terminal, Flush Type Actuator, Panel Mount
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer TE CONNECTIVITY LTD
Package Description ROHS COMPLIANT
Reach Compliance Code compliant
Factory Lead Time 19 Weeks, 3 Days
Samacsys Manufacturer TE Connectivity
Actuator Color RED
Actuator Material POLYAMIDE
Actuator Type FLUSH TYPE
Additional Feature ROHS COMPLIANT
Body Breadth 10.01 mm
Body Color BLACK
Body Height 5.99 mm
Body Length or Diameter 10.01 mm
Center Contact Material COPPER ALLOY
Center Contact Plating GOLD OVER NICKEL
Contact (AC) Max Rating R Load .02A@20VAC
Contact Current(AC)-Max 0.4 A
Contact Current(DC)-Max 0.4 A
Contact (DC) Max Power Rating R Load 0.4VA@20VDC
Contact (DC) Max Rating R Load .02A@20VDC
Contact Resistance 0.05 mΩ
Contact Voltage(AC)-Max 20 V
Contact Voltage(DC)-Max 20 V
Dielectric Withstand Volts 300VAC V
Electrical Life 10000 Cycle(s)
End Contact Material COPPER ALLOY
End Contact Plating GOLD OVER NICKEL
Housing Material POLYETHYLENE
Insulation Resistance 1000000000 Ω
Insulator Material POLYPHENYLENE SULPHIDE
Mounting Feature PANEL MOUNT
Number of Positions 10
Number of Switch Sections 10
Operating Temperature-Max 85 °C
Operating Temperature-Min -30 °C
Packing Method TR
Surface Mount NO
Switch Action LATCHED
Switch Function BINARY CODED DECIMAL
Switch Type ROTARY CODED SWITCH
Terminal Length 0.146 inch
Terminal Material COPPER ALLOY
Termination Type WIRE

1-1825007-0 Frequently Asked Questions (FAQ)

  • The recommended torque for the screw terminals is 0.5-0.7 Nm (4.4-6.3 in-lbs) to ensure secure connections.

  • Yes, the 1-1825007-0 connector is designed to withstand high-vibration environments, making it suitable for applications such as industrial machinery, transportation, and aerospace.

  • Yes, the connector is rated for use in harsh environments, including outdoor and humid conditions, due to its IP67 rating and sealed construction.

  • The operating temperature range for the 1-1825007-0 connector is -40°C to 125°C (-40°F to 257°F), making it suitable for a wide range of applications.

  • Yes, the connector is designed for automated assembly processes, featuring a pick-and-place compatible design and tape-and-reel packaging.
