ZSPM4551AA1W Information
ZSPM4551AA1W by Renesas Electronics Corporation is a Power Management Circuit.
Power Management Circuits are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Part Details for ZSPM4551AA1W
ZSPM4551AA1W CAD Models
ZSPM4551AA1W Part Data Attributes
|
|
ZSPM4551AA1W
Renesas Electronics Corporation
Buy Now
Datasheet
|
Compare Parts:
ZSPM4551AA1W
Renesas Electronics Corporation
High-Efficiency Charger for Li-Ion Batteries, VFQFPN0/Reel
|
| Pbfree Code | Yes | |
| Part Life Cycle Code | Not Recommended | |
| Ihs Manufacturer | RENESAS ELECTRONICS CORP | |
| Part Package Code | VFQFPN | |
| Package Description | PQFN-16 | |
| Pin Count | 16 | |
| Manufacturer Package Code | NBG16 | |
| Reach Compliance Code | unknown | |
| ECCN Code | NLR | |
| HTS Code | 8542310001 | |
| Samacsys Manufacturer | Renesas Electronics | |
| Adjustable Threshold | NO | |
| Analog IC - Other Type | POWER SUPPLY SUPPORT CIRCUIT | |
| JESD-30 Code | S-XQCC-N16 | |
| Length | 4 mm | |
| Number of Channels | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 16 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | UNSPECIFIED | |
| Package Code | HVQCCN | |
| Package Equivalence Code | LCC16,.16SQ,25 | |
| Package Shape | SQUARE | |
| Package Style | CHIP CARRIER, HEAT SINK/SLUG, VERY THIN PROFILE | |
| Seated Height-Max | 1 mm | |
| Supply Voltage-Max (Vsup) | 7.2 V | |
| Supply Voltage-Min (Vsup) | 3.5 V | |
| Supply Voltage-Nom (Vsup) | 5.3 V | |
| Surface Mount | YES | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | QUAD | |
| Threshold Voltage-Nom | +3.15V | |
| Width | 4 mm |
