Part Details for YSF-122+ by Mini-Circuits
Results Overview of YSF-122+ by Mini-Circuits
- Distributor Offerings: (2 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Education and Research
Industrial Automation
Electronic Manufacturing
YSF-122+ Information
YSF-122+ by Mini-Circuits is an RF/Microwave Amplifier.
RF/Microwave Amplifiers are under the broader part category of RF and Microwave Components.
RF and Microwave Engineering focuses on the design and operation of devices that transmit or receive radio waves. The main distinction between RF and microwave engineering is their wavelength, which influences how energy is transmitted and used in various applications. Read more about RF and Microwave Components on our RF and Microwave part category page.
Price & Stock for YSF-122+
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
3157-YSF-122+TR-ND
|
DigiKey | SMT GAIN BLOCK, 800 - 1200 MHZ Min Qty: 500 Lead time: 2 Weeks Container: Tape & Reel (TR) | Temporarily Out of Stock |
|
$3.0500 / $3.1800 | Buy Now |
|
DISTI #
139-YSF-122+
|
Mouser Electronics | RF Amplifier SMT Gain Block, 800 - 1200 MHz, 50? RoHS: Compliant | 465 |
|
$2.9300 / $4.0800 | Buy Now |
Part Details for YSF-122+
YSF-122+ CAD Models
YSF-122+ Part Data Attributes
|
|
YSF-122+
Mini-Circuits
Buy Now
Datasheet
|
Compare Parts:
YSF-122+
Mini-Circuits
Narrow Band Low Power Amplifier, 800MHz Min, 1200MHz Max, 1 Func, 6 X 5 MM, ROHS COMPLIANT, PLASTIC, CASE DL1020, MCLP-8
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | MINI-CIRCUITS | |
| Reach Compliance Code | unknown | |
| ECCN Code | EAR99 | |
| Samacsys Manufacturer | Mini-Circuits | |
| Additional Feature | LOW NOISE | |
| Characteristic Impedance | 50 Ω | |
| Construction | COMPONENT | |
| Gain | 18.3 dB | |
| Input Power-Max (CW) | 21 dBm | |
| JESD-609 Code | e2 | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Functions | 1 | |
| Number of Terminals | 8 | |
| Operating Frequency-Max | 1200 MHz | |
| Operating Frequency-Min | 800 MHz | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Equivalence Code | SOLCC8,.25 | |
| Power Supplies | 5 V | |
| RF/Microwave Device Type | NARROW BAND MEDIUM POWER | |
| Supply Current-Max | 145 mA | |
| Surface Mount | YES | |
| Terminal Finish | Tin/Silver (Sn/Ag) - with Nickel (Ni) barrier |
