XM7D-0512 Information
XM7D-0512 by OMRON Electronic Components LLC is a Telecom and Datacom Connector.
Telecom and Datacom Connectors are under the broader part category of Connectors.
Connectors are devices that join electrical termination points to form circuits. With various types designed for specific functions like data, power, or signal transmission, choosing the right connector is essential for compatibility and device performance. Read more about Connectors on our Connectors part category page.
Price & Stock for XM7D-0512
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
41X5165
|
Newark | Mini Usb, 2.0 Type B, Receptacle, Th, Usb Connector Type:Mini Usb Type B, Usb Standard:Usb 2.0, Gender:Receptacle, No. Of Positions:5Positions, Connector Mounting:Through Hole Mount, Orientation:Right Angle, Product Range:- Rohs Compliant: Yes |Omron Electronic Components XM7D-0512 RoHS: Compliant Min Qty: 100 Package Multiple: 1 Date Code: 0 Container: Bulk | 0 |
|
Buy Now |
Part Details for XM7D-0512
XM7D-0512 CAD Models
XM7D-0512 Part Data Attributes
|
|
XM7D-0512
OMRON Electronic Components LLC
Buy Now
Datasheet
|
Compare Parts:
XM7D-0512
OMRON Electronic Components LLC
Telecom and Datacom Connector,
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | OMRON CORP | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8536.69.40.30 | |
| Samacsys Manufacturer | Omron Electronics | |
| Body/Shell Style | SOCKET | |
| Connector Type | USB CONNECTOR | |
| Contact Finish Mating | NOT SPECIFIED | |
| Contact Gender | FEMALE | |
| Contact Material | NOT SPECIFIED | |
| DIN Conformance | NO | |
| Empty Shell | NO | |
| Filter Feature | NO | |
| IEC Conformance | NO | |
| Insulator Material | LIQUID CRYSTAL POLYMER | |
| MIL Conformance | NO | |
| Mixed Contacts | NO | |
| Mounting Style | RIGHT ANGLE | |
| Mounting Type | BOARD | |
| Option | GENERAL PURPOSE | |
| Shell Finish | NICKEL | |
| Shell Material | COPPER ALLOY | |
| Termination Type | SOLDER | |
| Total Number of Contacts | 5 |
