Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for XC7Z014S-2CLG484E by AMD
Results Overview of XC7Z014S-2CLG484E by AMD
- Distributor Offerings: (3 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
XC7Z014S-2CLG484E Information
XC7Z014S-2CLG484E by AMD is an Other uP/uC/Peripheral IC.
Other uPs/uCs/Peripheral ICs are under the broader part category of Microcontrollers and Processors.
Microcontrollers (MCUs) are small, low-power integrated circuits used to control embedded systems. Microcontrollers are primarily used to automate and control devices. Read more about Microcontrollers and Processors on our Microcontrollers and Processors part category page.
Price & Stock for XC7Z014S-2CLG484E
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
122-2029-ND
|
DigiKey | IC SOC CORTEX-A9 766MHZ 484BGA Min Qty: 84 Lead time: 16 Weeks Container: Tray | Temporarily Out of Stock |
|
$149.5000 | Buy Now |
|
DISTI #
XC7Z014S-2CLG484E
|
Avnet Americas | FPGA Zynq-7000 Family 65000 Cells 766MHz 28nm 1V 484-Pin WCBGA Tray - Trays (Alt: XC7Z014S-2CLG484E) RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 16 Weeks, 0 Days Container: Tray | 0 |
|
$132.2500 | Buy Now |
|
DISTI #
217-C7Z014S-2CLG484E
|
Mouser Electronics | SoC FPGA XC7Z014S-2CLG484E RoHS: Compliant | 18 |
|
$149.4800 | Buy Now |
Part Details for XC7Z014S-2CLG484E
XC7Z014S-2CLG484E CAD Models
XC7Z014S-2CLG484E Part Data Attributes
|
|
XC7Z014S-2CLG484E
AMD
Buy Now
Datasheet
|
Compare Parts:
XC7Z014S-2CLG484E
AMD
SoC, CMOS, PBGA484, CSBGA-484
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ADVANCED MICRO DEVICES INC | |
| Package Description | CSBGA-484 | |
| Reach Compliance Code | compliant | |
| Factory Lead Time | 16 Weeks | |
| Samacsys Manufacturer | AMD | |
| JESD-30 Code | S-PBGA-B484 | |
| JESD-609 Code | e1 | |
| Length | 19 mm | |
| Moisture Sensitivity Level | 3 | |
| Number of Terminals | 484 | |
| Operating Temperature-Max | 100 °C | |
| Operating Temperature-Min | ||
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | LFBGA | |
| Package Equivalence Code | BGA484,22X22,32 | |
| Package Shape | SQUARE | |
| Package Style | GRID ARRAY, LOW PROFILE, FINE PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Seated Height-Max | 1.6 mm | |
| Supply Voltage-Max | 1.05 V | |
| Supply Voltage-Min | 0.95 V | |
| Supply Voltage-Nom | 1 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Terminal Finish | TIN SILVER COPPER | |
| Terminal Form | BALL | |
| Terminal Pitch | 0.8 mm | |
| Terminal Position | BOTTOM | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 19 mm | |
| uPs/uCs/Peripheral ICs Type | SoC |
