WSLP12061L000FEA Information
WSLP12061L000FEA by Vishay Intertechnologies is a Fixed Resistor.
Fixed Resistors are under the broader part category of Resistors.
Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.
Price & Stock for WSLP12061L000FEA
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
08AJ1745
|
Newark | Res, 0R001, 1W, 1206, Metal Strip, Resistance:0.001Ohm, Product Range:Wslp Series, Resistor Case/Package:1206 [3216 Metric], Power Rating:1W, Resistance Tolerance:± 1%, Resistor Technology:Metal Strip, Product Length:3.2Mm Rohs Compliant: Yes |Vishay WSLP12061L000FEA RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 3998 |
|
$0.1600 | Buy Now |
|
DISTI #
85W2648
|
Newark | Res, 0R001, 1W, 1206, Metal Strip, Resistance:0.001Ohm, Product Range:Wslp Series, Resistor Case/Package:1206 [3216 Metric], Power Rating:1W, Resistance Tolerance:± 1%, Resistor Technology:Metal Strip, Product Length:3.2Mm Rohs Compliant: Yes |Vishay WSLP12061L000FEA RoHS: Compliant Min Qty: 4000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.4290 / $0.4540 | Buy Now |
|
DISTI #
71-WSLP12061L000FEA
|
Mouser Electronics | Current Sense Resistors - SMD 1watt .001ohms 1% RoHS: Compliant | 14750 |
|
$0.3870 / $1.0000 | Buy Now |
|
DISTI #
V72:2272_09632827
|
Arrow Electronics | Res Metal Strip 1206 0.001 Ohm 1% 1W ±275ppm/°C Sulfur Resistant Pad SMD T/R Automotive AEC-Q200 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 7 Weeks Date Code: 2216 Container: Cut Strips | Americas - 2230 |
|
$0.3788 / $0.6347 | Buy Now |
|
|
Future Electronics | WSLP Series 1206 1 W 1 mOhm ±1% ±275 ppm/°C SMT Power Metal Strip® Resistor RoHS: Compliant pbFree: Yes Min Qty: 4000 Package Multiple: 4000 Lead time: 7 Weeks Container: Reel | 12000Reel |
|
$0.3400 | Buy Now |
|
DISTI #
66407772
|
Verical | Res Metal Strip 1206 0.001 Ohm 1% 1W ±275ppm/°C Sulfur Resistant Pad SMD T/R Automotive AEC-Q200 RoHS: Compliant Min Qty: 313 Package Multiple: 1 | Americas - 3998 |
|
$0.3212 / $0.3842 | Buy Now |
|
DISTI #
61720058
|
Verical | Res Metal Strip 1206 0.001 Ohm 1% 1W ±275ppm/°C Sulfur Resistant Pad SMD T/R Automotive AEC-Q200 RoHS: Compliant Min Qty: 10 Package Multiple: 1 Date Code: 2216 | Americas - 2230 |
|
$0.6347 | Buy Now |
|
|
Bristol Electronics | 5701 |
|
RFQ | ||
|
|
Quest Components | 1440 |
|
$0.5400 / $1.3500 | Buy Now | |
|
|
Quest Components | 480 |
|
$0.6480 / $1.6200 | Buy Now |
Part Details for WSLP12061L000FEA
WSLP12061L000FEA CAD Models
WSLP12061L000FEA Part Data Attributes
|
|
WSLP12061L000FEA
Vishay Intertechnologies
Buy Now
Datasheet
|
Compare Parts:
WSLP12061L000FEA
Vishay Intertechnologies
Fixed Resistor, Metal Strip, 1W, 0.001ohm, 0.0316V, 1% +/-Tol, 275ppm/Cel, Surface Mount, 1206, CHIP
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | VISHAY INTERTECHNOLOGY INC | |
| Package Description | CHIP | |
| Reach Compliance Code | compliant | |
| Factory Lead Time | 7 Weeks | |
| Samacsys Manufacturer | Vishay | |
| Additional Feature | ANTI-SULFUR | |
| Construction | Rectangular | |
| JESD-609 Code | e3 | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 170 °C | |
| Operating Temperature-Min | -65 °C | |
| Package Height | 0.635 mm | |
| Package Length | 3.2 mm | |
| Package Shape | RECTANGULAR PACKAGE | |
| Package Style | SMT | |
| Package Width | 1.6 mm | |
| Packing Method | TR, Embossed Plastic, 7 Inch | |
| Rated Power Dissipation (P) | 1 W | |
| Rated Temperature | 70 °C | |
| Reference Standard | AEC-Q200 | |
| Resistance | 0.001 Ω | |
| Resistor Type | FIXED RESISTOR | |
| Size Code | 1206 | |
| Surface Mount | YES | |
| Technology | METAL STRIP | |
| Temperature Coefficient | 275 ppm/°C | |
| Terminal Finish | Matte Tin (Sn) - with Nickel (Ni) barrier | |
| Terminal Shape | WRAPAROUND | |
| Tolerance | 1% | |
| Working Voltage | 0.0316 V |
