WSL25129L000FEA18 Information
WSL25129L000FEA18 by Vishay Intertechnologies is a Fixed Resistor.
Fixed Resistors are under the broader part category of Resistors.
Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.
Price & Stock for WSL25129L000FEA18
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
72M6592
|
Newark | Current Sense Resistor, 0.009 Ohm, 2W, 1%, Resistance:0.009Ohm, Product Range:Wsl_18 Series, Resistor Case/Package:2512 [6432 Metric], Power Rating:1W, Resistance Tolerance:± 1%, Resistor Technology:Metal Strip Rohs Compliant: Yes |Vishay WSL25129L000FEA18 RoHS: Compliant Min Qty: 2000 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 0 |
|
$1.1200 | Buy Now |
|
DISTI #
WSL25129L000FEA18
|
Avnet Americas | WSL-2512-18 .009 1% EA e3 - Tape and Reel (Alt: WSL25129L000FEA18) RoHS: Compliant Min Qty: 2000 Package Multiple: 2000 Lead time: 13 Weeks, 0 Days Container: Reel | 4000 |
|
$0.5409 / $0.5780 | Buy Now |
|
DISTI #
71-WSL25129L000FEA18
|
Mouser Electronics | Current Sense Resistors - SMD 2watts .009ohms 1% RoHS: Compliant | 12217 |
|
$0.6420 / $2.4500 | Buy Now |
|
|
Future Electronics | WSL-2512-18 .009 1% EA E3 RoHS: Compliant pbFree: Yes Min Qty: 2000 Package Multiple: 2000 Lead time: 13 Weeks Container: Reel | 18000Reel |
|
$0.1750 | Buy Now |
|
DISTI #
WSL25129L000FEA18
|
TTI | Current Sense Resistors - SMD 2watts .009ohms 1% RoHS: Compliant pbFree: Pb-Free Min Qty: 2000 Package Multiple: 2000 Container: Reel |
Americas - 18000 In Stock |
|
$0.2900 / $0.3790 | Buy Now |
|
DISTI #
WSL25129L000FEA18.
|
TTI | Current Sense Resistors - SMD .009 OHM 1% 2W 75PPM RoHS: Compliant pbFree: Pb-Free Min Qty: 20 Package Multiple: 10 Container: Cut Tape | Americas - 0 |
|
$0.3260 | Buy Now |
|
|
Future Electronics | WSL-2512-18 .009 1% EA E3 Min Qty: 2000 Package Multiple: 2000 |
18000 null |
|
$0.1750 | Buy Now |
|
DISTI #
WSL25129L000FEA18
|
Avnet Abacus | WSL251218 009 1 EA e3 (Alt: WSL25129L000FEA18) RoHS: Compliant Min Qty: 2000 Package Multiple: 2000 Lead time: 16 Weeks, 0 Days | Abacus - 0 |
|
Buy Now |
Part Details for WSL25129L000FEA18
WSL25129L000FEA18 CAD Models
WSL25129L000FEA18 Part Data Attributes
|
|
WSL25129L000FEA18
Vishay Intertechnologies
Buy Now
Datasheet
|
Compare Parts:
WSL25129L000FEA18
Vishay Intertechnologies
Fixed Resistor, Metal Strip, 2W, 0.009ohm, 0.1342V, 1% +/-Tol, 75ppm/Cel, Surface Mount, 2512, CHIP
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | VISHAY INTERTECHNOLOGY INC | |
| Package Description | CHIP | |
| Reach Compliance Code | compliant | |
| Factory Lead Time | 13 Weeks | |
| Samacsys Manufacturer | Vishay | |
| Additional Feature | ANTI-SULFUR | |
| Construction | Rectangular | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 170 °C | |
| Operating Temperature-Min | -65 °C | |
| Package Height | 0.635 mm | |
| Package Length | 6.35 mm | |
| Package Style | SMT | |
| Package Width | 3.18 mm | |
| Packing Method | TR, EMBOSSED PLASTIC, 7 INCH | |
| Rated Power Dissipation (P) | 2 W | |
| Rated Temperature | 70 °C | |
| Reference Standard | AEC-Q200 | |
| Resistance | 0.009 Ω | |
| Resistor Type | FIXED RESISTOR | |
| Size Code | 2512 | |
| Surface Mount | YES | |
| Technology | METAL STRIP | |
| Temperature Coefficient | 75 ppm/°C | |
| Terminal Finish | Matte Tin (Sn) - with Nickel (Ni) barrier | |
| Terminal Shape | WRAPAROUND | |
| Tolerance | 1% | |
| Working Voltage | 0.1342 V |
