WSC4527R1000FEB Information
WSC4527R1000FEB by Vishay Intertechnologies is a Wire Wound Resistor.
Wire Wound Resistors are under the broader part category of Resistors.
Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.
Price & Stock for WSC4527R1000FEB
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
WSC4527R1000FEB
|
Avnet Americas | - Tape and Reel (Alt: WSC4527R1000FEB) RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 26 Weeks, 0 Days Container: Reel | 0 |
|
$0.5412 / $0.7471 | Buy Now |
|
DISTI #
71-WSC4527R1000FEB
|
Mouser Electronics | Wirewound Resistors - SMD .1ohms 2watts 1% RoHS: Compliant | 874 |
|
$0.7040 / $1.4900 | Buy Now |
|
|
Bristol Electronics | 181 |
|
RFQ | ||
|
DISTI #
WSC4527R1000FEB
|
TTI | Wirewound Resistors - SMD .1ohms 2watts 1% RoHS: Compliant pbFree: Pb-Free Min Qty: 1000 Package Multiple: 1000 Container: Reel |
Americas - 3000 In Stock |
|
$0.5340 / $0.5670 | Buy Now |
|
DISTI #
WSC4527R1000FEB
|
TTI | Wirewound Resistors - SMD .1ohms 2watts 1% RoHS: Compliant pbFree: Pb-Free Min Qty: 1000 Package Multiple: 1000 Container: Reel |
Americas - 3000 In Stock |
|
$0.5340 / $0.5670 | Buy Now |
|
DISTI #
WSC4527R1000FEA.
|
TTI | Wirewound Resistors - SMD .1 OHM 1% 2W 150PPM RoHS: Compliant pbFree: Pb-Free Min Qty: 10 Package Multiple: 10 Container: Cut Tape | Americas - 0 |
|
$2.9800 | Buy Now |
|
DISTI #
WSC4527R1000FEA.
|
TTI | Wirewound Resistors - SMD .1 OHM 1% 2W 150PPM RoHS: Compliant pbFree: Pb-Free Min Qty: 10 Package Multiple: 10 Container: Cut Tape | Americas - 0 |
|
$2.9800 | Buy Now |
Part Details for WSC4527R1000FEB
WSC4527R1000FEB CAD Models
WSC4527R1000FEB Part Data Attributes
|
|
WSC4527R1000FEB
Vishay Intertechnologies
Buy Now
Datasheet
|
Compare Parts:
WSC4527R1000FEB
Vishay Intertechnologies
Fixed Resistor, Wire Wound, 2W, 0.1ohm, 0.447V, 1% +/-Tol, 150ppm/Cel, Surface Mount, 4527, CHIP
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | VISHAY INTERTECHNOLOGY INC | |
| Package Description | CHIP | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8533.21.00.80 | |
| Factory Lead Time | 26 Weeks | |
| Samacsys Manufacturer | Vishay | |
| Additional Feature | PRECISION | |
| Construction | Rectangular | |
| JESD-609 Code | e3 | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 275 °C | |
| Operating Temperature-Min | -65 °C | |
| Package Height | 4.24 mm | |
| Package Length | 11.56 mm | |
| Package Style | SMT | |
| Package Width | 6.98 mm | |
| Packing Method | TR, EMBOSSED PLASTIC, 13 INCH | |
| Rated Power Dissipation (P) | 2 W | |
| Rated Temperature | 70 °C | |
| Reference Standard | AEC-Q200 | |
| Resistance | 0.1 Ω | |
| Resistor Type | FIXED RESISTOR | |
| Size Code | 4527 | |
| Surface Mount | YES | |
| Technology | WIRE WOUND | |
| Temperature Coefficient | 150 ppm/°C | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Shape | WRAPAROUND | |
| Tolerance | 1% | |
| Working Voltage | 0.45 V |
