WFMB2010R5000FEA Information
WFMB2010R5000FEA by Vishay Intertechnologies is a Metal Strip Resistor.
Metal Strip Resistor are under the broader part category of Resistors.
Resistors are passive components that work by limiting electron flow in a circuit. They are available as fixed or as variable (potentionmeters). Read more about Resistors on our Resistors part category page.
Price & Stock for WFMB2010R5000FEA
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
98AC3992
|
Newark | Res, 0R5, 2W, 2010, Metal Plate, Resistance:0.5Ohm, Product Range:Wfm Series, Resistor Case/Package:2010 [5025 Metric], Power Rating:2W, Resistance Tolerance:± 1%, Resistor Technology:Metal Plate, Temperature Coefficient:± 50Ppm/°Crohs Compliant: Yes |Vishay WFMB2010R5000FEA RoHS: Compliant Min Qty: 4000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.4990 / $0.5290 | Buy Now |
|
DISTI #
01AH9850
|
Newark | Res, 0R5, 2W, 2010, Metal Plate, Resistance:0.5Ohm, Product Range:Wfm Series, Resistor Case/Package:2010 [5025 Metric], Power Rating:2W, Resistance Tolerance:± 1%, Resistor Technology:Metal Plate, Temperature Coefficient:± 50Ppm/°Crohs Compliant: Yes |Vishay WFMB2010R5000FEA RoHS: Compliant Min Qty: 4000 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 0 |
|
$0.7640 | Buy Now |
|
DISTI #
WFMB2010R5000FEA
|
Avnet Americas | WFMB2010 .5 1% NICR EA e3 - Tape and Reel (Alt: WFMB2010R5000FEA) RoHS: Not Compliant Min Qty: 4000 Package Multiple: 4000 Lead time: 111 Weeks, 0 Days Container: Reel | 0 |
|
$0.4733 / $0.5282 | Buy Now |
|
DISTI #
71-WFMB2010R5000FEA
|
Mouser Electronics | Current Sense Resistors - SMD 2watts .5ohms 1% B =NiCrAl High Power RoHS: Compliant | 0 |
|
$0.5720 / $1.8800 | Order Now |
|
|
Bristol Electronics | 37 |
|
RFQ | ||
|
DISTI #
WFMB2010R5000FEA
|
TTI | Current Sense Resistors - SMD 2watts .5ohms 1% B =NiCrAl High Power RoHS: Compliant pbFree: Pb-Free Min Qty: 4000 Package Multiple: 4000 Container: Reel | Americas - 0 |
|
$0.4720 / $0.5280 | Buy Now |
|
DISTI #
WFMB2010R5000FEA
|
Avnet Abacus | WFMB2010 5 1 NICR EA e3 - Tape and Reel (Alt: WFMB2010R5000FEA) RoHS: Compliant Min Qty: 4000 Package Multiple: 4000 Lead time: 83 Weeks, 0 Days Container: Reel | Abacus - 0 |
|
Buy Now |
Part Details for WFMB2010R5000FEA
WFMB2010R5000FEA CAD Models
WFMB2010R5000FEA Part Data Attributes
|
|
WFMB2010R5000FEA
Vishay Intertechnologies
Buy Now
Datasheet
|
Compare Parts:
WFMB2010R5000FEA
Vishay Intertechnologies
Fixed Resistor, Metal Strip, 3W, 0.5ohm, 1.2247V, 1% +/-Tol, 50ppm/Cel, Surface Mount, 2010, CHIP
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | VISHAY INTERTECHNOLOGY INC | |
| Package Description | CHIP | |
| Reach Compliance Code | unknown | |
| Factory Lead Time | 111 Weeks | |
| Samacsys Manufacturer | Vishay | |
| Additional Feature | ANTI-SULFUR | |
| Construction | Rectangular | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 170 °C | |
| Operating Temperature-Min | -65 °C | |
| Package Height | 0.5 mm | |
| Package Length | 5.08 mm | |
| Package Style | SMT | |
| Package Width | 2.54 mm | |
| Packing Method | TR, EMBOSSED PLASTIC, 7 INCH | |
| Rated Power Dissipation (P) | 3 W | |
| Rated Temperature | 70 °C | |
| Reference Standard | AEC-Q200 | |
| Resistance | 0.5 Ω | |
| Resistor Type | FIXED RESISTOR | |
| Size Code | 2010 | |
| Surface Mount | YES | |
| Technology | METAL STRIP | |
| Temperature Coefficient | 50 ppm/°C | |
| Terminal Shape | WRAPAROUND | |
| Tolerance | 1% | |
| Working Voltage | 1.2247 V |
