W3A45C103MAT2A Information
W3A45C103MAT2A by Kyocera AVX Components is an Array/Network Capacitor.
Array/Network Capacitors are under the broader part category of Capacitors.
A capacitor is a passive electronic component that stores energy. Capacitors are commonly used for energy storage, voltage suppression, and signal filtering. Read more about Capacitors on our Capacitors part category page.
Price & Stock for W3A45C103MAT2A
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
26M4985
|
Newark | Capacitor Array, 0.01 F, 20%, 4, 50 V, 0612 [1632 Metric], Smd Rohs Compliant: Yes |Kyocera Avx W3A45C103MAT2A RoHS: Compliant Min Qty: 10 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 609 |
|
$0.0780 / $0.2050 | Buy Now |
|
DISTI #
478-5874-1-ND
|
DigiKey | CAP ARRAY 10000PF 50V X7R 0612 Min Qty: 1 Lead time: 16 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) | Temporarily Out of Stock |
|
$0.0518 / $0.2800 | Buy Now |
|
DISTI #
W3A45C103MAT2A
|
Avnet Americas | Capacitor Array, 0.01 uF, 50 V, ? 20%, 4 Element, SMD, 0612 [1632 Metric] - Tape and Reel (Alt: W3A45C103MAT2A) RoHS: Compliant Min Qty: 4000 Package Multiple: 4000 Lead time: 16 Weeks, 0 Days Container: Reel | 0 |
|
$0.0687 / $0.0726 | Buy Now |
|
DISTI #
581-W3A45C103MAT2A
|
Mouser Electronics | Capacitor Arrays & Networks 0612 50V .01uF 20% RoHS: Compliant | 0 |
|
$0.0480 / $0.2900 | Order Now |
|
|
Quest Components | CAP,CERAMIC CHIP,4-CAP ARRAY,.01UF,50VDC,±20%,X7R,SMD,0612-CASE | 1760 |
|
$0.0576 / $0.1280 | Buy Now |
|
DISTI #
W3A45C103MAT2A
|
TTI | Capacitor Arrays & Networks 0612 50V .01uF 20% RoHS: Compliant pbFree: Pb-Free Min Qty: 4000 Package Multiple: 4000 Container: Reel |
Americas - 4000 In Stock |
|
$0.0650 | Buy Now |
|
DISTI #
W3A45C103MAT2A
|
TME | Capacitor: ceramic, MLCC, 10nF, 50V, X7R, ±20%, SMD, 0612, 180mm Min Qty: 4000 | 0 |
|
$0.0409 / $0.0500 | RFQ |
|
|
ComSIT USA | Electronic Component RoHS: Compliant |
|
|
RFQ | |
|
DISTI #
W3A45C103MAT2A
|
IBS Electronics | CAP CERAMIC ARRAY 0.01UF 50V X7R 20% 0612 SMD 4 CAPACITOR 125°, C PAPER T/R/EMBOSSED T/R Min Qty: 12000 Package Multiple: 1 | 0 |
|
$0.0437 / $0.0468 | Buy Now |
|
DISTI #
W3A45C103MAT2A
|
Avnet Abacus | Capacitor Array 001 uF 50 V 20 4 Element SMD 0612 1632 Metric - Tape and Reel (Alt: W3A45C103MAT2A) RoHS: Compliant Min Qty: 4000 Package Multiple: 4000 Lead time: 16 Weeks, 0 Days Container: Reel | Abacus - 20000 |
|
Buy Now |
Part Details for W3A45C103MAT2A
W3A45C103MAT2A CAD Models
W3A45C103MAT2A Part Data Attributes
|
|
W3A45C103MAT2A
Kyocera AVX Components
Buy Now
Datasheet
|
Compare Parts:
W3A45C103MAT2A
Kyocera AVX Components
Array/Network Capacitor, 50V, X7R, 0.01uF, Surface Mount, CHIP-8, CHIP, ROHS COMPLIANT
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | KYOCERA AVX COMPONENTS CORP | |
| Package Description | CHIP | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8532.25.00.45 | |
| Factory Lead Time | 16 Weeks | |
| Samacsys Manufacturer | Kyocera AVX | |
| Capacitance | 0.01 µF | |
| Capacitor Type | ARRAY/NETWORK CAPACITOR | |
| Dielectric Material | CERAMIC | |
| Height | 1.35 mm | |
| JESD-609 Code | e3 | |
| Length | 1.6 mm | |
| Mounting Feature | SURFACE MOUNT | |
| Negative Tolerance | 20% | |
| Network Type | ISOLATED C NETWORK | |
| Number of Elements | 1 | |
| Number of Functions | 4 | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Code | DIP | |
| Package Shape | RECTANGULAR PACKAGE | |
| Package Style | DIP | |
| Packing Method | TR, PAPER/EMBOSSED, 7 INCH | |
| Positive Tolerance | 20% | |
| Rated (DC) Voltage (URdc) | 50 V | |
| Seated Height-Max | 1.35 mm | |
| Size Code | 0612 | |
| Surface Mount | YES | |
| Temperature Characteristics Code | X7R | |
| Temperature Coefficient | 15% ppm/°C | |
| Terminal Finish | Matte Tin (Sn) - with Nickel (Ni) barrier | |
| Terminal Pitch | 0.76 mm | |
| Terminal Shape | WRAPAROUND | |
| Width | 3.2 mm |
W3A45C103MAT2A Frequently Asked Questions (FAQ)
-
The recommended soldering temperature for the W3A45C103MAT2A is between 230°C to 250°C for a maximum of 3 seconds.
-
Yes, the W3A45C103MAT2A is a high-frequency capacitor with a self-resonant frequency of 1.5 GHz, making it suitable for high-frequency applications.
-
The maximum operating voltage for the W3A45C103MAT2A is 50V DC.
-
Yes, the W3A45C103MAT2A is RoHS compliant, meaning it does not contain hazardous substances like lead, mercury, or cadmium.
-
The ESR of the W3A45C103MAT2A is 0.05 ohms maximum at 100 kHz.
