W31-X2M1G-30 Information
W31-X2M1G-30 by TE Connectivity is a Toggle Switch.
Toggle Switches are under the broader part category of Switches.
Electrical switches are binary devices that control the flow of current in a circuit by either allowing or preventing the flow of electrons. Read more about Switches on our Switches part category page.
Price & Stock for W31-X2M1G-30
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
17M3346
|
Newark | Circuit Breaker, Thermal, 1P, 250V, 30A, Product Range:W31 Series, Current Rating:30A, No. Of Poles:1 Pole, Voltage Rating Vdc:50Vdc, Voltage Rating Vac:250Vac, Circuit Breaker Mounting:Panel, Operating Voltage:250V Rohs Compliant: Yes |Potter&brumfield Te Connectivity W31-X2M1G-30 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 0 |
|
$32.7800 / $52.7100 | Buy Now |
|
DISTI #
PB421-ND
|
DigiKey | CIR BRKR THRM 30A 240VAC 50VDC Min Qty: 1 Lead time: 18 Weeks Container: Bulk |
136 In Stock |
|
$26.8947 / $51.4100 | Buy Now |
|
DISTI #
3-1393247-8
|
Avnet Americas | Circuit Breaker, Thermal, Toggle, Panel, Series Trip, 30 A, 1 Pole, 240 VAC, 50 VDC - Bulk (Alt: 3-1393247-8) RoHS: Compliant Min Qty: 250 Package Multiple: 25 Lead time: 57 Weeks, 2 Days Container: Bulk | 0 |
|
$21.4000 / $27.2987 | Buy Now |
|
DISTI #
17M3346
|
Avnet Americas | Circuit Breaker, Thermal, Toggle, Panel, Series Trip, 30 A, 1 Pole, 240 VAC, 50 VDC - Bulk (Alt: 17M3346) RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 18 Weeks, 3 Days Container: Bulk | 0 |
|
$35.7400 / $50.4800 | Buy Now |
|
DISTI #
655-W31-X2M1G-30
|
Mouser Electronics | Circuit Breakers 30A TOGGLE ACTUATOR RoHS: Compliant | 159 |
|
$26.8900 / $46.8200 | Buy Now |
|
|
Onlinecomponents.com | Circuit Breaker Thermal 1Pole 30A 250VAC/50VDC RoHS: Compliant |
389 In Stock |
|
$26.1900 / $44.1400 | Buy Now |
|
|
Bristol Electronics | Min Qty: 1 | 4 |
|
$30.0000 | Buy Now |
|
|
Quest Components | 3 |
|
$32.5000 | Buy Now | |
|
DISTI #
3-1393247-8
|
TTI | Circuit Breakers W31-X2M1G-30 CIRCUIT BREAKERS Min Qty: 1 Package Multiple: 1 Container: Tray |
Americas - 271 In Stock |
|
Buy Now | |
|
DISTI #
AMP3-1393247-8
|
Interstate Connecting Components | W31-X2M1G-30=W23/W31 | 17 |
|
$28.0646 / $30.2235 | Buy Now |
Part Details for W31-X2M1G-30
W31-X2M1G-30 CAD Models
W31-X2M1G-30 Part Data Attributes
|
|
W31-X2M1G-30
TE Connectivity
Buy Now
Datasheet
|
Compare Parts:
W31-X2M1G-30
TE Connectivity
TOGGLE SWITCH, SPST, LATCHED, 30A, 50VDC, PANEL MOUNT-THREADED
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TE CONNECTIVITY LTD | |
| Reach Compliance Code | not_compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8536.50.90.65 | |
| Factory Lead Time | 18 Weeks, 3 Days | |
| Samacsys Manufacturer | TE Connectivity | |
| Actuator Color | SILVER | |
| Body Breadth | 17.53 mm | |
| Body Height | 40.64 mm | |
| Body Length or Diameter | 35.15 mm | |
| Contact (AC) Max Rating R Load | 30A@250VAC | |
| Contact Current(AC)-Max | 30 A | |
| Contact Current(DC)-Max | 30 A | |
| Contact (DC) Max Rating R Load | 30A@50VDC | |
| Contact Voltage(AC)-Max | 250 V | |
| Contact Voltage(DC)-Max | 50 V | |
| Mounting Feature | PANEL MOUNT | |
| Surface Mount | NO | |
| Switch Action | LATCHED | |
| Switch Function | SPST | |
| Switch Type | TOGGLE SWITCH | |
| Termination Type | SOLDER |
