Part Details for VLMH3102-GS08 by Vishay Intertechnologies
Results Overview of VLMH3102-GS08 by Vishay Intertechnologies
- Distributor Offerings: (6 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Renewable Energy
VLMH3102-GS08 Information
VLMH3102-GS08 by Vishay Intertechnologies is a Visible LED.
Visible LEDs are under the broader part category of Optoelectronics.
Optoelectronic components work to detect, generate, and control light. They can essentially produce and/or react to light. Read more about Optoelectronics on our Optoelectronics part category page.
Price & Stock for VLMH3102-GS08
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
17X8420
|
Newark | Led, Amber, 18Mcd, 635Nm, Plcc-2, Led Color:Amber, Led Mounting:Smd, Bulb Size:-, Forward Current If:20Ma, Forward Voltage:2V, Wavelength Typ:635Nm, Luminous Intensity:18Mcd, Viewing Angle:120°, Lens Shape:Round, Product Range:- Rohs Compliant: Yes |Vishay VLMH3102-GS08 RoHS: Compliant Min Qty: 7500 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 0 |
|
$0.1370 | Buy Now |
|
DISTI #
48M8440
|
Newark | Led, Amber, 18Mcd, 635Nm, Plcc-2, Led Color:Amber, Led Mounting:Smd, Bulb Size:-, Forward Current If:20Ma, Forward Voltage:2V, Wavelength Typ:635Nm, Luminous Intensity:18Mcd, Viewing Angle:120°, Lens Shape:Round, Product Range:- Rohs Compliant: Yes |Vishay VLMH3102-GS08 RoHS: Compliant Min Qty: 7500 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.0840 / $0.1290 | Buy Now |
|
DISTI #
VLMH3102-GS08
|
Avnet Americas | SMD-LED RED PLCC2-e3 - Tape and Reel (Alt: VLMH3102-GS08) RoHS: Compliant Min Qty: 7500 Package Multiple: 7500 Lead time: 6 Weeks, 0 Days Container: Reel | 0 |
|
$0.1008 / $0.1029 | Buy Now |
|
DISTI #
78-VLMH3102
|
Mouser Electronics | Single Color LEDs Amber 18mcd(max)@10mA RoHS: Compliant | 14118 |
|
$0.0980 / $0.3700 | Buy Now |
|
DISTI #
VLMH3102-GS08
|
Avnet Asia | SMD-LED RED PLCC2-e3 (Alt: VLMH3102-GS08) RoHS: Compliant Min Qty: 7500 Package Multiple: 7500 Lead time: 8 Weeks, 0 Days | 0 |
|
RFQ | |
|
DISTI #
VLMH3102-GS08
|
EBV Elektronik | SMDLED RED PLCC2e3 (Alt: VLMH3102-GS08) RoHS: Compliant Min Qty: 7500 Package Multiple: 7500 Lead time: 7 Weeks, 0 Days | EBV - 0 |
|
Buy Now |
Part Details for VLMH3102-GS08
VLMH3102-GS08 CAD Models
VLMH3102-GS08 Part Data Attributes
|
|
VLMH3102-GS08
Vishay Intertechnologies
Buy Now
Datasheet
|
Compare Parts:
VLMH3102-GS08
Vishay Intertechnologies
Single Color LED, Red, Clear Nondiffused, 2.4mm, LCC-2
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | VISHAY INTERTECHNOLOGY INC | |
| Package Description | LCC-2 | |
| Reach Compliance Code | compliant | |
| Factory Lead Time | 6 Weeks | |
| Samacsys Manufacturer | Vishay | |
| Additional Feature | SUPPORTS INFRARED | |
| Color | RED | |
| Color@Wavelength | Red | |
| Configuration | SINGLE | |
| Forward Current-Max | 0.03 A | |
| Forward Voltage-Max | 2.8 V | |
| JESD-609 Code | e3 | |
| Lens Type | CLEAR NONDIFFUSED | |
| Luminous Intensity-Min | 120 cd | |
| Luminous Intensity-Nom | 12.55 mcd | |
| Mounting Feature | SURFACE MOUNT | |
| Number of Functions | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 100 °C | |
| Operating Temperature-Min | -40 °C | |
| Optoelectronic Device Type | SINGLE COLOR LED | |
| Overall Height | 1.75 mm | |
| Packing Method | TR | |
| Peak Wavelength | 635 nm | |
| Reverse Voltage-Max | 6 V | |
| Shape | ROUND | |
| Size | 2.4 mm | |
| Surface Mount | YES | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Pitch | 2.8 mm | |
| Viewing Angle | 120 deg |
VLMH3102-GS08 Frequently Asked Questions (FAQ)
-
The recommended storage temperature range for the VLMH3102-GS08 is -40°C to 100°C.
-
Yes, the VLMH3102-GS08 is AEC-Q101 qualified, making it suitable for automotive applications.
-
The maximum forward current rating for the VLMH3102-GS08 is 30mA.
-
Yes, the VLMH3102-GS08 is Pb-free and RoHS compliant, making it environmentally friendly.
-
The typical junction-to-ambient thermal resistance for the VLMH3102-GS08 is 350°C/W.
