UPW2C4R7MPD Information
UPW2C4R7MPD by Nichicon Corporation is an Aluminum Electrolytic Capacitor.
Aluminum Electrolytic Capacitors are under the broader part category of Capacitors.
A capacitor is a passive electronic component that stores energy. Capacitors are commonly used for energy storage, voltage suppression, and signal filtering. Read more about Capacitors on our Capacitors part category page.
Price & Stock for UPW2C4R7MPD
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
493-1993-ND
|
DigiKey | CAP ALUM 4.7UF 20% 160V RADIAL Min Qty: 1 Lead time: 28 Weeks Container: Bulk |
1505 In Stock |
|
$0.1477 / $0.5100 | Buy Now |
|
DISTI #
UPW2C4R7MPD
|
Avnet Abacus | Aluminum Electrolytic Capacitor 47 uF 160 V 20 3000 hours 105C Radial Leaded (Alt: UPW2C4R7MPD) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 143 Weeks, 0 Days | Abacus - 0 |
|
Buy Now |
Part Details for UPW2C4R7MPD
UPW2C4R7MPD CAD Models
UPW2C4R7MPD Part Data Attributes
|
|
UPW2C4R7MPD
Nichicon Corporation
Buy Now
Datasheet
|
Compare Parts:
UPW2C4R7MPD
Nichicon Corporation
Aluminum Electrolytic Capacitor, Polarized, Aluminum (wet), 160V, 20% +Tol, 20% -Tol, 4.7uF, Through Hole Mount, RADIAL LEADED, ROHS COMPLIANT
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | NICHICON CORP | |
| Package Description | RADIAL LEADED | |
| Reach Compliance Code | not_compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8532.22.00 | |
| Samacsys Manufacturer | Nichicon | |
| Additional Feature | NON SOLVENT-PROOF | |
| Capacitance | 4.7 µF | |
| Capacitor Type | ALUMINUM ELECTROLYTIC CAPACITOR | |
| Diameter | 8 mm | |
| Dielectric Material | ALUMINUM (WET) | |
| JESD-609 Code | e3 | |
| Leakage Current | 0.1152 mA | |
| Length | 11.5 mm | |
| Mounting Feature | THROUGH HOLE MOUNT | |
| Negative Tolerance | 20% | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 105 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Shape | CYLINDRICAL PACKAGE | |
| Package Style | Radial | |
| Packing Method | TAPE | |
| Polarity | POLARIZED | |
| Positive Tolerance | 20% | |
| Rated (DC) Voltage (URdc) | 160 V | |
| Reference Standard | AEC-Q200 | |
| Ripple Current | 12 mA | |
| Surface Mount | NO | |
| Tan Delta | 0.15 | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Pitch | 3.5 mm | |
| Terminal Shape | WIRE |
