3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for UDZSTE-1716B by ROHM Semiconductor
Results Overview of UDZSTE-1716B by ROHM Semiconductor
- Distributor Offerings: (8 listings)
- Number of FFF Equivalents: (1 replacement)
- CAD Models: (Available)
- Number of Functional Equivalents: (1 option)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Internet of Things (IoT)
Environmental Monitoring
Financial Technology (Fintech)
Smart Cities
Transportation and Logistics
Agriculture Technology
Telecommunications
Virtual Reality (VR), Augmented Reality (AR), and Vision Systems
Education and Research
Consumer Electronics
Security and Surveillance
Audio and Video Systems
Computing and Data Storage
Healthcare
Entertainment and Gaming
UDZSTE-1716B Information
UDZSTE-1716B by ROHM Semiconductor is a Zener Diode.
Zener Diodes are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for UDZSTE-1716B
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
UDZSTE-1716BCT-ND
|
DigiKey | DIODE ZENER 16V 200MW UMD2 Min Qty: 1 Lead time: 17 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
8374 In Stock |
|
$0.0347 / $0.2800 | Buy Now |
|
DISTI #
755-UDZSTE-1716B
|
Mouser Electronics | Zener Diodes 16V 5MA RoHS: Compliant | 0 |
|
Order Now | |
|
DISTI #
61741534
|
Verical | Zener Diode Single 16V 2% 50Ohm 200mW 2-Pin UMD T/R Min Qty: 981 Package Multiple: 1 Date Code: 2101 | Americas - 2930 |
|
$0.0723 / $0.0771 | Buy Now |
|
DISTI #
61212355
|
Verical | Zener Diode Single 16V 2% 50Ohm 200mW 2-Pin UMD T/R Min Qty: 174 Package Multiple: 1 Date Code: 2101 | Americas - 174 |
|
$0.4703 | Buy Now |
|
|
Bristol Electronics | 4231 |
|
RFQ | ||
|
|
Quest Components | ZENER DIODE,SINGLE, TWO TERMINAL,16V V(Z),3.2%,SOD-323 | 2491 |
|
$0.1320 / $0.4400 | Buy Now |
|
DISTI #
UDZSTE-1716B
|
TTI | Zener Diodes 16V 5MA RoHS: Compliant pbFree: Pb-Free Min Qty: 3000 Package Multiple: 3000 Container: Reel | Americas - 0 |
|
$0.0370 / $0.0500 | Buy Now |
|
DISTI #
UDZSTE-1716B
|
Avnet Asia | Diode Zener Single 16.18V 2% 200mW 2-Pin UMD T/R (Alt: UDZSTE-1716B) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 24 Weeks, 0 Days | 0 |
|
RFQ |
Part Details for UDZSTE-1716B
UDZSTE-1716B CAD Models
UDZSTE-1716B Part Data Attributes
|
|
UDZSTE-1716B
ROHM Semiconductor
Buy Now
Datasheet
|
Compare Parts:
UDZSTE-1716B
ROHM Semiconductor
Zener Diode, 16V V(Z), 2.04%, 0.2W, Silicon, Unidirectional, MINIMOLD, UMD2, SC-76, 2 PIN
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Not Recommended | |
| Ihs Manufacturer | ROHM CO LTD | |
| Part Package Code | SC-76 | |
| Pin Count | 2 | |
| Reach Compliance Code | not_compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8541.10.00.50 | |
| Samacsys Manufacturer | ROHM Semiconductor | |
| Additional Feature | HIGH RELIABILITY | |
| Configuration | SINGLE | |
| Diode Element Material | SILICON | |
| Diode Type | ZENER DIODE | |
| Dynamic Impedance-Max | 50 Ω | |
| JESD-30 Code | R-PDSO-F2 | |
| JESD-609 Code | e1 | |
| Knee Impedance-Max | 80 Ω | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity | UNIDIRECTIONAL | |
| Power Dissipation-Max | 0.2 W | |
| Qualification Status | Not Qualified | |
| Reference Voltage-Nom | 16 V | |
| Reverse Current-Max | 0.1 µA | |
| Reverse Test Voltage | 12 V | |
| Surface Mount | YES | |
| Technology | ZENER | |
| Terminal Finish | Tin/Silver/Copper (Sn/Ag/Cu) | |
| Terminal Form | FLAT | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 10 | |
| Voltage Tol-Max | 2.04% | |
| Working Test Current | 5 mA |
