UCC3912DPTR Information
UCC3912DPTR by Texas Instruments is a Power Management Circuit.
Power Management Circuits are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for UCC3912DPTR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
86040001
|
Verical | Hot Swap Controller 1-CH 8V N-Channel Positive Voltage 16-Pin SOIC T/R RoHS: Compliant Min Qty: 88 Package Multiple: 1 Date Code: 0701 | Americas - 100000 |
|
$4.2625 | Buy Now |
|
DISTI #
86050593
|
Verical | Hot Swap Controller 1-CH 8V N-Channel Positive Voltage 16-Pin SOIC T/R RoHS: Compliant Min Qty: 88 Package Multiple: 1 Date Code: 1301 | Americas - 12427 |
|
$4.2625 | Buy Now |
|
DISTI #
86050318
|
Verical | Hot Swap Controller 1-CH 8V N-Channel Positive Voltage 16-Pin SOIC T/R RoHS: Compliant Min Qty: 88 Package Multiple: 1 Date Code: 1001 | Americas - 7500 |
|
$4.2625 | Buy Now |
|
DISTI #
86040396
|
Verical | Hot Swap Controller 1-CH 8V N-Channel Positive Voltage 16-Pin SOIC T/R RoHS: Compliant Min Qty: 88 Package Multiple: 1 Date Code: 1101 | Americas - 5000 |
|
$4.2625 | Buy Now |
|
|
Bristol Electronics | 7500 |
|
RFQ | ||
|
|
Quest Components | 1-CHANNEL POWER SUPPLY SUPPORT CKT, PDSO16 | 6000 |
|
$3.6338 / $7.2675 | Buy Now |
|
|
Quest Components | 1-CHANNEL POWER SUPPLY SUPPORT CKT, PDSO16 | 1200 |
|
$3.6338 / $7.2675 | Buy Now |
|
|
Rochester Electronics | UCC3912 0-3A, 3-8V Single Hot-Swap IC Hi-Side MOSFET, Commercial Temp. RoHS: Compliant Status: Obsolete Min Qty: 1 | 124927 |
|
$2.7300 / $3.4100 | Buy Now |
|
|
Chip 1 Exchange | INSTOCK | 2500 |
|
RFQ |
Part Details for UCC3912DPTR
UCC3912DPTR CAD Models
UCC3912DPTR Part Data Attributes
|
|
UCC3912DPTR
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
UCC3912DPTR
Texas Instruments
3-V to 8-V hot swap controller with circuit breaker and adjustable current monitoring 16-SOIC 0 to 70
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Part Package Code | SOIC | |
| Package Description | SOIC-16 | |
| Pin Count | 16 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Adjustable Threshold | YES | |
| Analog IC - Other Type | HOT SWAP CONTROLLER | |
| JESD-30 Code | R-PDSO-G16 | |
| JESD-609 Code | e4 | |
| Length | 9.9 mm | |
| Moisture Sensitivity Level | 2 | |
| Number of Channels | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 16 | |
| Operating Temperature-Max | 70 °C | |
| Operating Temperature-Min | ||
| Output Current-Max | 4 A | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SOP | |
| Package Equivalence Code | SOP16,.4 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.75 mm | |
| Supply Current-Max (Isup) | 2 mA | |
| Supply Voltage-Max (Vsup) | 8 V | |
| Supply Voltage-Min (Vsup) | 3 V | |
| Supply Voltage-Nom (Vsup) | 5 V | |
| Surface Mount | YES | |
| Technology | BICMOS | |
| Temperature Grade | COMMERCIAL | |
| Terminal Finish | NICKEL PALLADIUM GOLD | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 1.27 mm | |
| Terminal Position | DUAL | |
| Threshold Voltage-Nom | +1.5V | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 3.9 mm |
