UC1708J Information
UC1708J by Texas Instruments is an MOSFET Driver.
MOSFET Drivers are under the broader part category of Drivers And Interfaces.
A driver controls the current or voltage delivered to components like LCDs or motors, while an interface component connects systems for data transfer and control. Read more about Drivers And Interfaces on our Drivers And Interfaces part category page.
Price & Stock for UC1708J
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
|
Cytech Systems Limited | 3-A/3-A DUAL-CHANNEL GATE DRIVER | 1000 |
|
RFQ |
Part Details for UC1708J
UC1708J CAD Models
UC1708J Part Data Attributes
|
|
UC1708J
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
UC1708J
Texas Instruments
3-A/3-A dual-channel gate driver with 35-V VDD 8-CDIP -55 to 125
|
| Pbfree Code | Yes | |
| Rohs Code | No | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Part Package Code | DIP | |
| Package Description | DIP, DIP8,.3 | |
| Pin Count | 8 | |
| Reach Compliance Code | not_compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| High Side Driver | NO | |
| Input Characteristics | STANDARD | |
| Interface IC Type | BUFFER OR INVERTER BASED MOSFET DRIVER | |
| JESD-30 Code | R-GDIP-T8 | |
| JESD-609 Code | e0 | |
| Length | 9.58 mm | |
| Number of Channels | 2 | |
| Number of Functions | 2 | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -55 °C | |
| Output Characteristics | TOTEM-POLE | |
| Output Current-Max | 3 A | |
| Output Peak Current Limit-Nom | 3 A | |
| Package Body Material | CERAMIC, GLASS-SEALED | |
| Package Code | DIP | |
| Package Equivalence Code | DIP8,.3 | |
| Package Shape | RECTANGULAR | |
| Package Style | IN-LINE | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 5.08 mm | |
| Supply Current-Max | 26 mA | |
| Supply Voltage-Max | 35 V | |
| Supply Voltage-Min | 5 V | |
| Supply Voltage-Nom | 20 V | |
| Surface Mount | NO | |
| Technology | BIPOLAR | |
| Temperature Grade | MILITARY | |
| Terminal Finish | Tin/Lead (Sn/Pb) | |
| Terminal Form | THROUGH-HOLE | |
| Terminal Pitch | 2.54 mm | |
| Terminal Position | DUAL | |
| Turn-off Time | 0.055 µs | |
| Turn-on Time | 0.075 µs | |
| Width | 7.62 mm |
Alternate Parts for UC1708J
This table gives cross-reference parts and alternative options found for UC1708J. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of UC1708J, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| UC3708N | Texas Instruments | $8.9293 | 3-A/3-A dual-channel gate driver with 35-V VDD, with 25-ns prop delay in a 16-pin SOIC package 8-PDIP 0 to 70 | UC1708J vs UC3708N |
| UC2708NG4 | Texas Instruments | Check for Price | Non-Inverting High Speed Power Drivers 8-PDIP -40 to 85 | UC1708J vs UC2708NG4 |
| 5962-0051401QPA | Texas Instruments | Check for Price | 3-A/3-A dual-channel gate driver with 35-V VDD 8-CDIP -55 to 125 | UC1708J vs 5962-0051401QPA |
| UC3708NG4 | Texas Instruments | Check for Price | 3-A/3-A dual-channel gate driver with 35-V VDD, with 25-ns prop delay in a 16-pin SOIC package 8-PDIP 0 to 70 | UC1708J vs UC3708NG4 |
| 5962-0051401QPX | Defense Logistics Agency | Check for Price | Buffer/Inverter Based MOSFET Driver, 3A, BIPolar, CDIP8, CERAMIC, DIP-8 | UC1708J vs 5962-0051401QPX |
| 5962-0051401QEX | Defense Logistics Agency | Check for Price | Buffer/Inverter Based MOSFET Driver, 3A, BIPolar, CDIP16, CERAMIC, DIP-16 | UC1708J vs 5962-0051401QEX |
| 5962-0051401QEX | Texas Instruments | Check for Price | 3A 2 CHANNEL, BUF OR INV BASED MOSFET DRIVER, CDIP16, CERAMIC, DIP-16 | UC1708J vs 5962-0051401QEX |
| 5962-0051401QEA | Texas Instruments | Check for Price | 3-A/3-A dual-channel gate driver with 35-V VDD 16-CDIP -55 to 125 | UC1708J vs 5962-0051401QEA |
| UC3708JE | Texas Instruments | Check for Price | 3A 2 CHANNEL, BUF OR INV BASED MOSFET DRIVER, CDIP16 | UC1708J vs UC3708JE |
| UC1708JE | Texas Instruments | Check for Price | 3-A/3-A dual-channel gate driver with 35-V VDD 16-CDIP -55 to 125 | UC1708J vs UC1708JE |
