TS5A63157DCKR Information
TS5A63157DCKR by Texas Instruments is a Multiplexer or Switch.
Multiplexers or Switches are under the broader part category of Signal Circuits.
A signal is an electronic means of transmitting information, either as an analog signal with continuous values or a digital signal with discrete values. Signals are used in various systems and networks. Read more about Signal Circuits on our Signal Circuits part category page.
Price & Stock for TS5A63157DCKR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
29AH1601
|
Newark | Analogue Switch, Single, Spdt, Sc-70-6, No. Of Channels:1Channels, Analogue Switch Type:Spdt, On State Resistance Max:12Ohm, Supply Voltage Range:1.65V To 5.5V, Analogue Switch Case:Sc-70, No. Of Pins:6Pins, Operating Temperature Rohs Compliant: Yes |Texas Instruments TS5A63157DCKR RoHS: Compliant Min Qty: 5 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 20 |
|
$0.4210 / $0.5440 | Buy Now |
|
DISTI #
296-21195-1-ND
|
DigiKey | IC SWITCH SPDT X 1 10OHM SC70-6 Min Qty: 1 Lead time: 12 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
6295 In Stock |
|
$0.1621 / $0.4100 | Buy Now |
|
DISTI #
595-TS5A63157DCKR
|
Mouser Electronics | Analog Switch ICs 15-Ohm SPDT Analog S witch RoHS: Compliant | 63198 |
|
$0.1680 / $0.3900 | Buy Now |
|
DISTI #
J56:1989_00585304
|
Arrow Electronics | Analog Multiplexer Single 2:1 6-Pin SC-70 T/R RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 12 Weeks Date Code: 2426 | Europe - 3000 |
|
$0.1552 | Buy Now |
|
DISTI #
V72:2272_07426912
|
Arrow Electronics | Analog Multiplexer Single 2:1 6-Pin SC-70 T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 12 Weeks Date Code: 2234 Container: Cut Strips | Americas - 711 |
|
$0.1552 / $0.2457 | Buy Now |
|
DISTI #
86297518
|
Verical | Analog Multiplexer Single 2:1 6-Pin SC-70 T/R RoHS: Compliant Min Qty: 1765 Package Multiple: 1 Date Code: 0501 | Americas - 9000 |
|
$0.1588 / $0.2125 | Buy Now |
|
DISTI #
63428247
|
Verical | Analog Multiplexer Single 2:1 6-Pin SC-70 T/R RoHS: Compliant Min Qty: 38 Package Multiple: 1 Date Code: 2234 | Americas - 711 |
|
$0.1552 / $0.1953 | Buy Now |
|
|
Bristol Electronics | 14 |
|
RFQ | ||
|
|
Rochester Electronics | TS5A63157 15-Ohm SPDT Analog Switch 5-V/3.3-V Single-Channel 2:1 Multiplexer/Demultiplexer RoHS: Compliant Status: Active Min Qty: 1 | 9000 |
|
$0.1270 / $0.2048 | Buy Now |
|
DISTI #
TS5A63157DCKR
|
TME | IC: analog switch, demultiplexer,multiplexer, SPDT, Ch: 1, SC70-6 Min Qty: 1 | 0 |
|
$0.2080 / $0.3690 | RFQ |
Part Details for TS5A63157DCKR
TS5A63157DCKR CAD Models
TS5A63157DCKR Part Data Attributes
|
|
TS5A63157DCKR
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
TS5A63157DCKR
Texas Instruments
5-V, 2:1 (SPDT), 1-channel general-purpose analog switch with overshoot and undershoot protection 6-SC70 -40 to 85
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Part Package Code | SOIC | |
| Package Description | SC-70, 6 PIN | |
| Pin Count | 6 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Analog IC - Other Type | SPDT | |
| Bandwidth-Nom | 371 MHz | |
| Input Voltage-Max | 5.5 V | |
| Input Voltage-Min | ||
| JESD-30 Code | R-PDSO-G6 | |
| JESD-609 Code | e4 | |
| Length | 2 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Channels | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 6 | |
| Off-state Isolation-Nom | 60 dB | |
| On-state Resistance Match-Nom | 0.1 Ω | |
| On-state Resistance-Max (Ron) | 45 Ω | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Output | COMMON OUTPUT | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | TSSOP | |
| Package Equivalence Code | TSSOP6,.08 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, THIN PROFILE, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.1 mm | |
| Supply Current-Max (Isup) | 0.00075 mA | |
| Supply Voltage-Max (Vsup) | 5.5 V | |
| Supply Voltage-Min (Vsup) | 1.65 V | |
| Supply Voltage-Nom (Vsup) | 1.8 V | |
| Surface Mount | YES | |
| Switch-off Time-Max | 12 ns | |
| Switch-on Time-Max | 24 ns | |
| Switching | BREAK-BEFORE-MAKE | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 1.25 mm |
