TS3A227ERVAR Information
TS3A227ERVAR by Texas Instruments is a Multiplexer or Switch.
Multiplexers or Switches are under the broader part category of Signal Circuits.
A signal is an electronic means of transmitting information, either as an analog signal with continuous values or a digital signal with discrete values. Signals are used in various systems and networks. Read more about Signal Circuits on our Signal Circuits part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| TS3A227ERVAR | Texas Instruments | Autonomous audio-accessory detection & configuration switch 16-VQFN -40 to 85 |
Price & Stock for TS3A227ERVAR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
296-38654-1-ND
|
DigiKey | IC DETECTION SWITCH 16VQFN Min Qty: 1 Lead time: 18 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
7605 In Stock |
|
$0.7512 / $1.6700 | Buy Now |
|
DISTI #
595-TS3A227ERVAR
|
Mouser Electronics | Switch ICs - Various Auto Audio Accessory Detection RoHS: Compliant | 3104 |
|
$0.7510 / $1.2200 | Buy Now |
|
DISTI #
V72:2272_07426699
|
Arrow Electronics | Analog Switch Dual SPDT 16-Pin VQFN EP T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 18 Weeks Date Code: 2230 Container: Cut Strips | Americas - 2820 |
|
$0.7707 / $0.8493 | Buy Now |
|
DISTI #
63267097
|
Verical | Analog Switch Dual SPDT 16-Pin VQFN EP T/R RoHS: Compliant Min Qty: 8 Package Multiple: 1 Date Code: 2230 | Americas - 2820 |
|
$0.7707 / $0.8493 | Buy Now |
|
|
Bristol Electronics | 500 |
|
RFQ | ||
|
DISTI #
SMC-TS3A227ERVAR
|
Sensible Micro Corporation | AS6081 Certified Vendor, 1 Yr Warranty RoHS: Not Compliant Min Qty: 25 Lead time: 2 Weeks, 0 Days | 63 |
|
RFQ | |
|
|
LCSC | VQFN-16(3.5x3.5) Analog Switches - Special Purpose ROHS | 127 |
|
$1.6201 / $2.3914 | Buy Now |
Part Details for TS3A227ERVAR
TS3A227ERVAR CAD Models
TS3A227ERVAR Part Data Attributes
|
|
TS3A227ERVAR
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
TS3A227ERVAR
Texas Instruments
60-mΩ, 4.5-V, autonomous audio accessory detection & configuration switch with I<sup>2</sup>C 16-VQFN -40 to 85
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Part Package Code | QFN | |
| Package Description | VQFN-16 | |
| Pin Count | 16 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Analog IC - Other Type | AUDIO/VIDEO SWITCH | |
| Bandwidth-Nom | 150 MHz | |
| Input Voltage-Max | 4.5 V | |
| Input Voltage-Min | 2.5 V | |
| JESD-30 Code | S-PQCC-N16 | |
| JESD-609 Code | e4 | |
| Length | 3.5 mm | |
| Moisture Sensitivity Level | 2 | |
| Number of Channels | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 16 | |
| Off-state Isolation-Nom | 90 dB | |
| On-state Resistance-Max (Ron) | 30000 Ω | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Output | SEPARATE OUTPUT | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | VQCCN | |
| Package Equivalence Code | LCC16,.14SQ,20 | |
| Package Shape | SQUARE | |
| Package Style | CHIP CARRIER, VERY THIN PROFILE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Seated Height-Max | 1 mm | |
| Supply Current-Max (Isup) | 0.045 mA | |
| Supply Voltage-Max (Vsup) | 4.5 V | |
| Supply Voltage-Min (Vsup) | 2.5 V | |
| Surface Mount | YES | |
| Switch-off Time-Max | 5000 ns | |
| Switch-on Time-Max | 35000 ns | |
| Switching | BREAK-BEFORE-MAKE | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | QUAD | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 3.5 mm |
