Capacitors / Fixed Capacitors / TR3E226K035C0200
Datasheets
TR3E226K035C0200 by:

Tantalum Capacitor, Polarized, Tantalum (dry/solid), 35V, 10% +Tol, 10% -Tol, 22uF, Surface Mount, 2917, CHIP

Part Details for TR3E226K035C0200 by Vishay Intertechnologies

Results Overview of TR3E226K035C0200 by Vishay Intertechnologies

Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.

Applications Consumer Electronics Audio and Video Systems

TR3E226K035C0200 Information

TR3E226K035C0200 by Vishay Intertechnologies is a Fixed Capacitor.
Fixed Capacitors are under the broader part category of Capacitors.

A capacitor is a passive electronic component that stores energy. Capacitors are commonly used for energy storage, voltage suppression, and signal filtering. Read more about Capacitors on our Capacitors part category page.

Price & Stock for TR3E226K035C0200

Part # Distributor Description Stock Price Buy
DISTI # 66AJ1988
Newark Cap, 22Uf, 35V, Tant, Case E, Capacitance:22Μf, Voltage(Dc):35V, Capacitor Case/Package:2917 [7343 Metric], Capacitance Tolerance:± 10%, Esr:0.2Ohm, Manufacturer Size Code:E, Failure Rate:-, Ripple Current:910Ma, Product Height:4Mmrohs Compliant: Yes |Vishay TR3E226K035C0200 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape 283
  • 1 $1.1700
  • 10 $1.1700
  • 25 $1.1700
  • 50 $1.1700
  • 100 $1.1700
$1.1700 Buy Now
DISTI # 82R4929
Newark Cap, 22Uf, 35V, Tant, Case E, Capacitance:22Μf, Voltage(Dc):35V, Capacitor Case/Package:2917 [7343 Metric], Capacitance Tolerance:± 10%, Esr:0.2Ohm, Manufacturer Size Code:E, Failure Rate:-, Ripple Current:910Ma, Product Height:4Mmrohs Compliant: Yes |Vishay TR3E226K035C0200 RoHS: Compliant Min Qty: 400 Package Multiple: 1 Date Code: 1 Container: Reel 0
  • 400 $1.4900
  • 800 $1.3900
  • 1,600 $1.3700
  • 2,400 $1.3400
$1.3400 / $1.4900 Buy Now
DISTI # TR3E226K035C0200
Avnet Americas TR3226K035EC0200 - Tape and Reel (Alt: TR3E226K035C0200) RoHS: Compliant Min Qty: 400 Package Multiple: 400 Lead time: 13 Weeks, 0 Days Container: Reel 0
  • 400 $0.4655
  • 800 $0.4631
  • 1,600 $0.4462
  • 2,400 $0.4439
  • 3,200 $0.4416
$0.4416 / $0.4655 Buy Now
DISTI # 66AJ1988
Avnet Americas TR3226K035EC0200 - Product that comes on tape, but is not reeled (Alt: 66AJ1988) RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 13 Weeks, 4 Days Container: Ammo Pack 0
  • 1 $3.0900
  • 10 $2.3200
  • 25 $2.1700
  • 50 $2.0100
  • 100 $1.7200
$1.7200 / $3.0900 Buy Now
DISTI # 82R4929
Avnet Americas TR3226K035EC0200 - Tape and Reel (Alt: 82R4929) RoHS: Compliant Min Qty: 400 Package Multiple: 400 Lead time: 13 Weeks, 4 Days Container: Reel 0
  • 1 $1.2900
  • 800 $1.2000
  • 2,400 $1.1900
$1.1900 / $1.2900 Buy Now
DISTI # 74-TR3E226K035C0200
Mouser Electronics Tantalum Capacitors - Solid SMD 22uF 35volts 10% E cs ESR 0.2 Molded RoHS: Compliant 105
  • 1 $2.8200
  • 10 $1.9500
  • 50 $1.9300
  • 100 $1.8000
  • 250 $1.3400
  • 400 $1.2700
  • 800 $1.2100
  • 2,400 $1.1900
$1.1900 / $2.8200 Buy Now
Future Electronics TR3 Series 22 uF ±10 % 35V Surface Mount Molded Low ESR Tantalum Capacitor RoHS: Compliant pbFree: Yes Min Qty: 400 Package Multiple: 400 Lead time: 13 Weeks Container: Reel 400
Reel
  • 400 $0.4850
  • 800 $0.4750
  • 1,200 $0.4700
  • 2,000 $0.4600
$0.4600 / $0.4850 Buy Now
Bristol Electronics   400
RFQ
Quest Components TANTALUM CAPACITOR, POLARIZED, TANTALUM (DRY/SOLID), 35V, 10% +TOL, 10% -TOL, 22UF, SURFACE MOUNT, 2917 1709
  • 1 $1.5375
  • 261 $0.6150
  • 1,302 $0.5381
$0.5381 / $1.5375 Buy Now
Quest Components TANTALUM CAPACITOR, POLARIZED, TANTALUM (DRY/SOLID), 35V, 10% +TOL, 10% -TOL, 22UF, SURFACE MOUNT, 2917 320
  • 1 $1.5375
  • 66 $0.7688
  • 261 $0.6150
$0.6150 / $1.5375 Buy Now
DISTI # TR3E226K035C0200
TTI Tantalum Capacitors - Solid SMD 22uF 35volts 10% E cs ESR 0.2 Molded RoHS: Compliant pbFree: Pb-Free Min Qty: 400 Package Multiple: 400 Container: Reel Americas - 0
  • 400 $0.9000
  • 800 $0.8800
  • 1,200 $0.8600
  • 2,400 $0.8500
$0.8500 / $0.9000 Buy Now
Future Electronics TR3 Series 22 uF �10 % 35V Surface Mount Molded Low ESR Tantalum Capacitor Min Qty: 400 Package Multiple: 400 400
null
  • 400 $0.4850
  • 800 $0.4750
  • 1,200 $0.4700
  • 2,000 $0.4600
$0.4600 / $0.4850 Buy Now
DISTI # TR3E226K035C0200
IBS Electronics CAP TANT SOLID 22UF 35V E CASE 10% (7.3 X 4.3 X 4MM) SMD 7343-43 0.2 OHM 125C T/R Min Qty: 400 Package Multiple: 1 0
  • 400 $0.6240
  • 800 $0.6110
  • 1,200 $0.6045
  • 1,600 $0.5980
$0.5980 / $0.6240 Buy Now
DISTI # TR3E226K035C0200
Avnet Abacus TR3226K035EC0200 (Alt: TR3E226K035C0200) RoHS: Compliant Min Qty: 10000 Package Multiple: 400 Lead time: 15 Weeks, 0 Days Abacus - 0
Buy Now

Part Details for TR3E226K035C0200

TR3E226K035C0200 CAD Models

  • Part Symbol

    Part Symbol

  • Footprint

    footprint

  • 3D Model

    3D Model

Available Download Formats

Sign in to download CAD models Register or Sign In

By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy

TR3E226K035C0200 Part Data Attributes

Parametric Data
TR3E226K035C0200 Vishay Intertechnologies
Buy Now Datasheet
Compare Parts:
TR3E226K035C0200 Vishay Intertechnologies Tantalum Capacitor, Polarized, Tantalum (dry/solid), 35V, 10% +Tol, 10% -Tol, 22uF, Surface Mount, 2917, CHIP
Rohs Code Yes
Part Life Cycle Code Active
Ihs Manufacturer VISHAY INTERTECHNOLOGY INC
Package Description CHIP
Reach Compliance Code compliant
Factory Lead Time 13 Weeks, 4 Days
Samacsys Manufacturer Vishay
Capacitance 22 µF
Capacitor Type TANTALUM CAPACITOR
Dielectric Material TANTALUM (DRY/SOLID)
ESR 200 mΩ
Height 4 mm
JESD-609 Code e3
Leakage Current 0.0077 mA
Length 7.3 mm
Mounting Feature SURFACE MOUNT
Negative Tolerance 10%
Number of Terminals 2
Operating Temperature-Max 125 °C
Operating Temperature-Min -55 °C
Package Shape RECTANGULAR PACKAGE
Package Style SMT
Packing Method TR, EMBOSSED PLASTIC, 7 INCH
Polarity POLARIZED
Positive Tolerance 10%
Rated (DC) Voltage (URdc) 35 V
Ripple Current 364 mA
Size Code 2917
Surface Mount YES
Tan Delta 0.06
Terminal Finish Matte Tin (Sn) - with Nickel (Ni) barrier
Terminal Shape J BEND
Width 4.3 mm

Alternate Parts for TR3E226K035C0200

This table gives cross-reference parts and alternative options found for TR3E226K035C0200. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of TR3E226K035C0200, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.

Part Number Manufacturer Composite Price Description Compare
T493X226K035CT642C7640 KEMET Corporation Check for Price Tantalum Capacitor, Polarized, Tantalum (dry/solid), 35V, 10% +Tol, 10% -Tol, 22uF, 2917, TR3E226K035C0200 vs T493X226K035CT642C7640
T493X226K035AN6411 KEMET Corporation Check for Price Tantalum Capacitor, Tantalum (dry/solid), TR3E226K035C0200 vs T493X226K035AN6411
T493X226K035BH6130C-7280 KEMET Corporation Check for Price Tantalum Capacitor, Polarized, Tantalum, 35V, 10% +Tol, 10% -Tol, 22uF, 2917 TR3E226K035C0200 vs T493X226K035BH6130C-7280
T493X226K035BC6110WAFL KEMET Corporation Check for Price Tantalum Capacitor, Tantalum (dry/solid), TR3E226K035C0200 vs T493X226K035BC6110WAFL
T493X226K035CH622A7640 KEMET Corporation Check for Price Tantalum Capacitor, Polarized, Tantalum (dry/solid), 35V, 10% +Tol, 10% -Tol, 22uF, 2917, TR3E226K035C0200 vs T493X226K035CH622A7640
T493X226K035CH612B7640 KEMET Corporation Check for Price Tantalum Capacitor, Polarized, Tantalum (dry/solid), 35V, 10% +Tol, 10% -Tol, 22uF, 2917, TR3E226K035C0200 vs T493X226K035CH612B7640
T493X226K035BM6112 KEMET Corporation Check for Price Tantalum Capacitor, Tantalum (dry/solid), TR3E226K035C0200 vs T493X226K035BM6112
T493X226K035BM61207280 KEMET Corporation Check for Price Tantalum Capacitor, Polarized, Tantalum (dry/solid), 35V, 10% +Tol, 10% -Tol, 22uF, Surface Mount, 2917, CHIP TR3E226K035C0200 vs T493X226K035BM61207280
T493X226K035BN61307280 KEMET Corporation Check for Price Tantalum Capacitor, Polarized, Tantalum (dry/solid), 35V, 10% +Tol, 10% -Tol, 22uF, Surface Mount, 2917, CHIP TR3E226K035C0200 vs T493X226K035BN61307280
T493X226K035AK6311 KEMET Corporation Check for Price Tantalum Capacitor, Tantalum (dry/solid), TR3E226K035C0200 vs T493X226K035AK6311

TR3E226K035C0200 Related Parts

TR3E226K035C0200 Frequently Asked Questions (FAQ)

  • The recommended land pattern for TR3E226K035C0200 can be found in Vishay's application note 'Land Pattern Recommendations for Surface-Mount Ceramic Chip Capacitors' (document number 28356).

  • TR3E226K035C0200 is a moisture-sensitive device. It's essential to follow the recommended storage and handling procedures outlined in IPC/JEDEC J-STD-033 to prevent moisture absorption and ensure reliability.

  • While the datasheet provides ESR values at 100 kHz, Vishay can provide additional ESR data at higher frequencies upon request. Contact Vishay's technical support for more information.

  • TR3E226K035C0200 is designed to meet the vibration requirements of IEC 60068-2-6. However, it's essential to evaluate the capacitor's performance in your specific application and consider additional testing or derating if necessary.

  • Vishay provides reliability data for their ceramic capacitors in their 'Reliability Handbook' (document number 23042). The expected lifespan of TR3E226K035C0200 depends on various factors, including operating conditions, voltage, and temperature. Consult the handbook for more information.
