TPS63060DSCT Information
TPS63060DSCT by Texas Instruments is a Switching Regulator or Controller.
Switching Regulator or Controllers are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for TPS63060DSCT
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
29AH8180
|
Newark | Buck/Boost, Sync, Adj, 10Son, Topology:Buck-Boost, Input Voltage Min:2.5V, Input Voltage Max:12V, No. Of Outputs:1Outputs, Dc/Dc Converter Ic Case:Son, No. Of Pins:10Pins, Output Current:2A, Output Voltage Min:2.5V, Output Voltage Rohs Compliant: Yes |Texas Instruments TPS63060DSCT RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 0 |
|
$3.2400 / $7.2300 | Buy Now |
|
DISTI #
296-30178-1-ND
|
DigiKey | IC REG BUCK BOOST ADJ 2A 10WSON Min Qty: 1 Lead time: 12 Weeks Container: Cut Tape (CT), Digi-Reel®, Tape & Reel (TR) |
637 In Stock |
|
$1.4557 / $2.8400 | Buy Now |
|
DISTI #
595-TPS63060DSCT
|
Mouser Electronics | Switching Voltage Regulators 2.5-12Vin 2.25A Sw C rnt Limit A 595-TPS63060DSCR RoHS: Compliant | 2295 |
|
$1.4200 / $2.8400 | Buy Now |
|
DISTI #
SMC-TPS63060DSCT
|
Sensible Micro Corporation | AS6081 Certified Vendor, 1 Yr Warranty RoHS: Not Compliant Min Qty: 25 Lead time: 2 Weeks, 0 Days | 330 |
|
RFQ | |
|
|
LCSC | Boost type Adjustable 2A 2.5V8V 2.5V12V WSON-10-EP(3x3) DC-DC Converters ROHS | 49 |
|
$0.4966 / $0.5255 | Buy Now |
|
|
Vyrian | Other Function Semiconductors | 6037 |
|
RFQ | |
|
|
Win Source Electronics | IC REG BUCK BOOST ADJ 2A 10WSON | 59380 |
|
$0.5198 / $0.6713 | Buy Now |
Part Details for TPS63060DSCT
TPS63060DSCT CAD Models
TPS63060DSCT Part Data Attributes
|
|
TPS63060DSCT
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
TPS63060DSCT
Texas Instruments
2.5V to 12V input voltage, 93% Efficient, 2.25A Switch Current Limit, Buck-Boost Converter 10-WSON -40 to 125
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| parentfamilyid | 4215473 | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Part Package Code | SON | |
| Package Description | 3 X 3 MM, GREEN, PLASTIC, WSON-10 | |
| Pin Count | 10 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Schedule B Code | 8542.39.00.00 | |
| kg CO2e/kg | 12.04 | |
| Average Weight (mg) | 29.1 | |
| CO2e (mg) | 350.364 | |
| Samacsys Description | Switching Voltage Regulators 2.5-12Vin,2.25A Sw Crnt Limit | |
| Samacsys Manufacturer | Texas Instruments | |
| Samacsys Modified On | 2023-06-22 10:55:39 | |
| Total Weight | 18.777141 | |
| Category CO2 Kg | 504 | |
| CO2 | 9463.679064 | |
| Compliance Temperature Grade | Industrial: -40C to +85C | |
| EU RoHS Version | RoHS 2 (2015/863/EU) | |
| Candidate List Date | 2025-01-21 | |
| CAS Accounted for Wt | 100 | |
| CA Prop 65 Presence | YES | |
| CA Prop 65 CAS Numbers | 7439-92-1, 7440-02-0, 1333-86-4 | |
| EFUP | e | |
| Conflict Mineral Status | DRC Conflict Free | |
| Conflict Mineral Status Source | CMRT V6.40 | |
| Analog IC - Other Type | SWITCHING REGULATOR | |
| Control Mode | CURRENT-MODE | |
| Control Technique | PULSE WIDTH MODULATION | |
| Input Voltage-Max | 12 V | |
| Input Voltage-Min | 2.5 V | |
| Input Voltage-Nom | 5 V | |
| JESD-30 Code | S-PDSO-N10 | |
| JESD-609 Code | e4 | |
| Length | 3 mm | |
| Moisture Sensitivity Level | 2 | |
| Number of Functions | 1 | |
| Number of Terminals | 10 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Current-Max | 1.3 A | |
| Output Voltage-Max | 8 V | |
| Output Voltage-Min | 2.5 V | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | HVSON | |
| Package Equivalence Code | SOLCC10,.12,20 | |
| Package Shape | SQUARE | |
| Package Style | SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 0.8 mm | |
| Surface Mount | YES | |
| Switcher Configuration | BUCK-BOOST | |
| Switching Frequency-Max | 2600 kHz | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Nickel/Palladium/Gold/Silver (Ni/Pd/Au/Ag) | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 3 mm |
