Part Details for TPS543C20RVFR by Texas Instruments
Results Overview of TPS543C20RVFR by Texas Instruments
- Distributor Offerings: (7 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (3 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
TPS543C20RVFR Information
TPS543C20RVFR by Texas Instruments is a Switching Regulator or Controller.
Switching Regulator or Controllers are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for TPS543C20RVFR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
296-48199-1-ND
|
DigiKey | IC REG BUCK ADJ 40A 40LQFN Min Qty: 1 Lead time: 6 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
3034 In Stock |
|
$5.4125 / $9.8300 | Buy Now |
|
DISTI #
595-TPS543C20RVFR
|
Mouser Electronics | Switching Voltage Regulators 4-V to 14-V 40-A sy nchronous SWIFT buc A 595-TPS543C20RVFT RoHS: Compliant | 2419 |
|
$5.4100 / $9.8300 | Buy Now |
|
|
Bristol Electronics | Min Qty: 1 | 148 |
|
$3.6736 / $8.9600 | Buy Now |
|
|
Quest Components | SWITCHING REGULATOR, CURRENT-MODE, 40A, 2000KHZ SWITCHING FREQ-MAX, PQCC40 | 118 |
|
$5.2000 / $12.0000 | Buy Now |
|
DISTI #
SMC-TPS543C20RVFR
|
Sensible Micro Corporation | AS6081 Certified Vendor, 1 Yr Warranty RoHS: Not Compliant Min Qty: 25 Lead time: 2 Weeks, 0 Days Date Code: 1850*36,2117*6 | 42 |
|
RFQ | |
|
|
Vyrian | Other Function Semiconductors | 12072 |
|
RFQ | |
|
|
Win Source Electronics | IC REG BUCK ADJ 40A 40LQFN | 2700 |
|
$4.5047 / $6.7570 | Buy Now |
Part Details for TPS543C20RVFR
TPS543C20RVFR CAD Models
TPS543C20RVFR Part Data Attributes
|
|
TPS543C20RVFR
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
TPS543C20RVFR
Texas Instruments
4-V to 14-V, 40-A synchronous SWIFT™ buck converter with adaptive internal compensation 40-LQFN-CLIP -40 to 125
|
| Pbfree Code | Yes | |
| Rohs Code | No | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Package Description | LQFN-40 | |
| Reach Compliance Code | not_compliant | |
| Date Of Intro | 2017-03-19 | |
| Samacsys Manufacturer | Texas Instruments | |
| Additional Feature | ALSO OPERATES UP TO 16 V SUPPLY VOLTAGE; OUTPUT VOLTAGE= 0.6V TO 5.5V | |
| Analog IC - Other Type | SWITCHING REGULATOR | |
| Control Mode | CURRENT-MODE | |
| Control Technique | PULSE WIDTH MODULATION | |
| Input Voltage-Max | 14 V | |
| Input Voltage-Min | 4 V | |
| Input Voltage-Nom | 4.5 V | |
| JESD-30 Code | R-PQCC-N40 | |
| JESD-609 Code | e4 | |
| Length | 7 mm | |
| Moisture Sensitivity Level | 2 | |
| Number of Functions | 1 | |
| Number of Outputs | 1 | |
| Number of Terminals | 40 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Current-Max | 40 A | |
| Output Voltage-Max | 5.5 V | |
| Output Voltage-Min | 0.6 V | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | HQCCN | |
| Package Equivalence Code | LCC40,.2X.28,20 | |
| Package Shape | RECTANGULAR | |
| Package Style | CHIP CARRIER, HEAT SINK/SLUG | |
| Peak Reflow Temperature (Cel) | 260 | |
| Seated Height-Max | 1.52 mm | |
| Surface Mount | YES | |
| Switcher Configuration | BUCK | |
| Switching Frequency-Max | 2000 kHz | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.5 mm | |
| Terminal Position | QUAD | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 5 mm |
