TPS2557QDRBTQ1 Information
TPS2557QDRBTQ1 by Texas Instruments is a Power Management Circuit.
Power Management Circuits are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for TPS2557QDRBTQ1
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
296-50076-1-ND
|
DigiKey | IC PWR SWITCH N-CHAN 1:1 8SON Min Qty: 1 Lead time: 12 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
924 In Stock |
|
$0.8631 / $1.7600 | Buy Now |
|
DISTI #
595-TPS2557QDRBTQ1
|
Mouser Electronics | Power Switch ICs - Power Distribution Prec Auto Adj Crnt- Ltd Pwr-Disty Switch A 595-TPS2557QDRBRQ1 RoHS: Compliant | 9739 |
|
$0.8300 / $1.7600 | Buy Now |
|
|
Win Source Electronics | IC PWR DIST SWITCH ADJ 8SON / DIST Single 6.5V Automotive 8-Pin VSON EP T/R | 82840 |
|
$0.4812 / $0.6215 | Buy Now |
Part Details for TPS2557QDRBTQ1
TPS2557QDRBTQ1 CAD Models
TPS2557QDRBTQ1 Part Data Attributes
|
|
TPS2557QDRBTQ1
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
TPS2557QDRBTQ1
Texas Instruments
Automotive 0.5-5A adjustable ILIMIT, 2.5-6.5V, 22mΩ USB power switch, active-high 8-SON -40 to 125
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Package Description | SON-8 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Adjustable Threshold | YES | |
| Analog IC - Other Type | POWER SUPPLY SUPPORT CIRCUIT | |
| Input Voltage-Max | 6.5 V | |
| Input Voltage-Min | 2.5 V | |
| JESD-30 Code | S-PDSO-N8 | |
| JESD-609 Code | e4 | |
| Length | 3 mm | |
| Moisture Sensitivity Level | 2 | |
| Number of Channels | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 8 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | HVSON | |
| Package Shape | SQUARE | |
| Package Style | SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Screening Level | AEC-Q100 | |
| Seated Height-Max | 1 mm | |
| Supply Current-Max (Isup) | 0.12 mA | |
| Supply Voltage-Max (Vsup) | 6.5 V | |
| Supply Voltage-Min (Vsup) | 2.5 V | |
| Supply Voltage-Nom (Vsup) | 5 V | |
| Surface Mount | YES | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 3 mm |
TPS2557QDRBTQ1 Frequently Asked Questions (FAQ)
-
The maximum current rating of the TPS2557QDRBTQ1 is 2.5A.
-
The TPS2557QDRBTQ1 has a built-in overcurrent protection feature that limits the output current to prevent damage to the device and the load in case of a fault condition.
-
The operating temperature range of the TPS2557QDRBTQ1 is -40°C to 125°C.
-
Yes, the TPS2557QDRBTQ1 is designed for high-reliability applications and is qualified to automotive and industrial standards.
-
The TPS2557QDRBTQ1 has a built-in thermal shutdown feature that turns off the device when the junction temperature exceeds 150°C to prevent damage to the device.
