TPS2051CDBVT Information
TPS2051CDBVT by Texas Instruments is a Power Management Circuit.
Power Management Circuits are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| TPS2051CDBVT | Texas Instruments | Single Channel, Current-Limited USB Power Distribution Switch 5-SOT-23 -40 to 85 |
Price & Stock for TPS2051CDBVT
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
296-29759-1-ND
|
DigiKey | IC PWR SWITCH N-CHAN 1:1 SOT23-5 Min Qty: 1 Lead time: 6 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
4169 In Stock |
|
$0.4600 / $1.0800 | Buy Now |
|
DISTI #
2156-TPS2051CDBVT-ND
|
DigiKey | IC PWR SWITCH N-CHAN 1:1 SOT23-5 Min Qty: 1 Lead time: 6 Weeks Container: Bulk MARKETPLACE PRODUCT |
1000 In Stock |
|
$0.6500 | Buy Now |
|
DISTI #
595-TPS2051CDBVT
|
Mouser Electronics | Power Switch ICs - Power Distribution SGL CHANNEL CRNT-LTD USB PWR DIST SWITCH A 595-TPS2051CDBVR RoHS: Compliant | 1556 |
|
$0.4600 / $1.0100 | Buy Now |
|
DISTI #
V72:2272_07410735
|
Arrow Electronics | Power Switch Hi Side 1-OUT 97mOhm 5-Pin SOT-23 T/R RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 6 Weeks Date Code: 2140 Container: Cut Strips | Americas - 83 |
|
$0.4719 / $0.5504 | Buy Now |
|
DISTI #
86048093
|
Verical | Power Switch Hi Side 1-OUT 97mOhm 5-Pin SOT-23 T/R RoHS: Compliant Min Qty: 482 Package Multiple: 1 Date Code: 1401 | Americas - 750 |
|
$0.7790 | Buy Now |
|
DISTI #
64939570
|
Verical | Power Switch Hi Side 1-OUT 97mOhm 5-Pin SOT-23 T/R RoHS: Compliant Min Qty: 13 Package Multiple: 1 Date Code: 2140 | Americas - 83 |
|
$0.4719 / $0.5052 | Buy Now |
|
|
Rochester Electronics | TPS2051C Single Channel, Current-Limited USB Power Distribution Switch RoHS: Compliant Status: Active Min Qty: 1 | 1000 |
|
$0.3864 / $0.6232 | Buy Now |
|
|
Cytech Systems Limited | IC PWR SWITCH N-CHAN 1:1 SOT23-5 | 750 |
|
RFQ | |
|
|
LCSC | 4.5V5.5V 97m Active High 500mA 1 High-side switch SOT-23-5 Power Distribution Switches ROHS | 23 |
|
$0.9093 / $1.2772 | Buy Now |
|
|
Vyrian | Other Function Semiconductors | 37811 |
|
RFQ |
Part Details for TPS2051CDBVT
TPS2051CDBVT CAD Models
TPS2051CDBVT Part Data Attributes
|
|
TPS2051CDBVT
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
TPS2051CDBVT
Texas Instruments
0.5A loading, 4.5-5.5V, 97mΩ USB power switch, active-high, output discharge, reverse blocking 5-SOT-23 -40 to 125
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Part Package Code | SOT-23 | |
| Pin Count | 5 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Adjustable Threshold | NO | |
| Analog IC - Other Type | LOAD SWITCH | |
| Input Voltage-Max | 5.5 V | |
| Input Voltage-Min | 4.5 V | |
| JESD-30 Code | R-PDSO-G5 | |
| JESD-609 Code | e4 | |
| Length | 2.9 mm | |
| Moisture Sensitivity Level | 2 | |
| Number of Channels | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 5 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | LSSOP | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, LOW PROFILE, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.45 mm | |
| Supply Voltage-Max (Vsup) | 5.5 V | |
| Supply Voltage-Min (Vsup) | 4.5 V | |
| Supply Voltage-Nom (Vsup) | 5 V | |
| Surface Mount | YES | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.95 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 1.6 mm |
