TLV70028DDCR Information
TLV70028DDCR by Texas Instruments is a Linear Regulator IC.
Linear Regulator ICs are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for TLV70028DDCR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
296-39280-1-ND
|
DigiKey | IC REG LINEAR 2.8V 200MA SOT23 Min Qty: 1 Lead time: 12 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
7481 In Stock |
|
$0.0578 / $0.1700 | Buy Now |
|
DISTI #
595-TLV70028DDCR
|
Mouser Electronics | LDO Voltage Regulators 200mA Low IQ LDO Reg for Portables A 595-TLV70028DDCT RoHS: Compliant | 5861 |
|
$0.0600 / $0.1700 | Buy Now |
|
|
Quest Components | FIXED POSITIVE LDO REGULATOR, 2.8V, 0.25V DROPOUT, PMOS, PDSO5 | 570 |
|
$0.0756 / $0.1680 | Buy Now |
|
|
Rochester Electronics | TLV700 200mA Low-Iq Low-Dropout (LDO) Regulator for Portables RoHS: Compliant Status: Active Min Qty: 1 | 120 |
|
$0.0462 / $0.0745 | Buy Now |
|
|
LCSC | 68dB(1kHz) 200mA Fixed 2.8V Positive electrode 5.5V TSOT-23-5 Voltage Regulators - Linear Low Drop Out (LDO) Regulators ROHS | 50 |
|
$0.0586 / $0.0620 | Buy Now |
|
|
Win Source Electronics | LDO Regulator Pos 2.8V 0.2A 5-Pin TSOT-23 T/R / IC REG LDO 2.8V 0.2A 5SOT | 586400 |
|
$0.0686 / $0.1029 | Buy Now |
Part Details for TLV70028DDCR
TLV70028DDCR CAD Models
TLV70028DDCR Part Data Attributes
|
|
TLV70028DDCR
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
TLV70028DDCR
Texas Instruments
200-mA, high-PSRR, low-IQ, low-dropout voltage regulator with enable 5-SOT-23-THIN -40 to 125
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Part Package Code | SOT-23 | |
| Pin Count | 5 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Adjustability | FIXED | |
| Dropout Voltage1-Max | 0.25 V | |
| Dropout Voltage1-Nom | 0.175 V | |
| Input Voltage Absolute-Max | 6 V | |
| Input Voltage-Max | 5.5 V | |
| Input Voltage-Min | 2 V | |
| JESD-30 Code | R-PDSO-G5 | |
| JESD-609 Code | e4 | |
| Length | 2.9 mm | |
| Line Regulation-Max | 0.005% | |
| Load Regulation-Max | 0.015% | |
| Moisture Sensitivity Level | 2 | |
| Number of Functions | 1 | |
| Number of Outputs | 1 | |
| Number of Terminals | 5 | |
| Operating Temperature TJ-Max | 125 °C | |
| Operating Temperature TJ-Min | -40 °C | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Current1-Max | 0.2 A | |
| Output Voltage1-Max | 2.856 V | |
| Output Voltage1-Min | 2.744 V | |
| Output Voltage1-Nom | 2.8 V | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | TSSOP | |
| Package Equivalence Code | TSOP5/6,.11,37 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, THIN PROFILE, SHRINK PITCH | |
| Packing Method | TR | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Regulator Type | FIXED POSITIVE SINGLE OUTPUT LDO REGULATOR | |
| Seated Height-Max | 1.1 mm | |
| Surface Mount | YES | |
| Technology | PMOS | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.95 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Voltage Tolerance-Max | 2% | |
| Width | 1.6 mm |
TLV70028DDCR Frequently Asked Questions (FAQ)
-
The TLV70028DDCR has an absolute maximum input voltage rating of 6.5V. Exceeding this voltage can cause permanent damage to the device.
-
To ensure stability, it's essential to follow the recommended PCB layout guidelines, use a sufficient output capacitor (at least 1uF), and maintain a minimum ESR (Equivalent Series Resistance) of 0.1 ohms.
-
The TLV70028DDCR can operate with an input voltage as low as 2.7V, but the output voltage regulation may not be guaranteed below 3.5V.
-
The TLV70028DDCR is rated for operation up to 125°C (TJ). However, the device's performance and reliability may degrade at higher temperatures. It's essential to follow the recommended operating conditions and thermal management guidelines.
-
The output voltage of the TLV70028DDCR is adjustable using an external resistor divider network. The output voltage can be calculated using the formula: Vout = 1.2V x (1 + R1/R2), where R1 and R2 are the resistors in the divider network.
