TLP109(TPL,E(T Information
TLP109(TPL,E(T by Toshiba America Electronic Components is an Optocoupler.
Optocoupler are under the broader part category of Optoelectronics.
Optoelectronic components work to detect, generate, and control light. They can essentially produce and/or react to light. Read more about Optoelectronics on our Optoelectronics part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| TLP109 | Toshiba Electronic Devices & Storage Corporation | Photocoupler (photo-IC output), 1 Mbps, 3750 Vrms, 5pin SO6 |
