TLC59116IPWRG4 Information
TLC59116IPWRG4 by Texas Instruments is a Display Driver.
Display Drivers are under the broader part category of Drivers And Interfaces.
A driver controls the current or voltage delivered to components like LCDs or motors, while an interface component connects systems for data transfer and control. Read more about Drivers And Interfaces on our Drivers And Interfaces part category page.
Price & Stock for TLC59116IPWRG4
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
|
Vyrian | Interface ICs | 1188 |
|
RFQ |
Part Details for TLC59116IPWRG4
TLC59116IPWRG4 CAD Models
TLC59116IPWRG4 Part Data Attributes
|
|
TLC59116IPWRG4
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
TLC59116IPWRG4
Texas Instruments
16-Bit Fast-Mode Plus (FM+) I2C-Bus Constant-Current LED Sink Driver 28-TSSOP -40 to 85
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Part Package Code | SSOP | |
| Package Description | TSSOP, TSSOP28,.25 | |
| Pin Count | 28 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Data Input Mode | SERIAL | |
| Interface IC Type | LED DISPLAY DRIVER | |
| JESD-30 Code | R-PDSO-G28 | |
| JESD-609 Code | e4 | |
| Length | 9.7 mm | |
| Moisture Sensitivity Level | 1 | |
| Multiplexed Display Capability | NO | |
| Number of Functions | 1 | |
| Number of Segments | 16 | |
| Number of Terminals | 28 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | TSSOP | |
| Package Equivalence Code | TSSOP28,.25 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, THIN PROFILE, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.2 mm | |
| Supply Voltage-Max | 5.5 V | |
| Supply Voltage-Min | 3 V | |
| Supply Voltage-Nom | 3.3 V | |
| Surface Mount | YES | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | NICKEL PALLADIUM GOLD | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 4.4 mm | |
| fmax-Min | 0.1 MHz |
Alternate Parts for TLC59116IPWRG4
This table gives cross-reference parts and alternative options found for TLC59116IPWRG4. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of TLC59116IPWRG4, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| TLC59116IPWR | Texas Instruments | $3.4132 | 16-bit Fast-Mode Plus (FM+) I2C-Bus constant-current LED sink driver 28-TSSOP -40 to 85 | TLC59116IPWRG4 vs TLC59116IPWR |
TLC59116IPWRG4 Frequently Asked Questions (FAQ)
-
The TLC59116IPWRG4 can handle up to 120mA per output, but it's recommended to limit it to 100mA for reliable operation.
-
Make sure to follow the power-up sequence specified in the datasheet, and wait for the internal oscillator to stabilize before sending any commands. Also, ensure that the VCC pin is properly decoupled with a capacitor.
-
No, the TLC59116IPWRG4 is designed to operate with a 3.3V supply. Using a 5V supply may damage the device or cause it to malfunction.
-
The TLC59116IPWRG4 has a built-in thermal shutdown feature that will shut down the device if it overheats. To handle this, ensure good thermal design and heat dissipation, and consider adding thermal monitoring and shutdown detection in your system design.
-
Yes, but with caution. The TLC59116IPWRG4 can drive inductive loads, but you need to ensure that the output pins are properly clamped to prevent voltage spikes, and consider adding external protection components such as diodes or resistors.
