3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for TL431ILP by Texas Instruments
Results Overview of TL431ILP by Texas Instruments
- Distributor Offerings: (17 listings)
- Number of FFF Equivalents: (7 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (10 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Consumer Electronics
Energy and Power Systems
Renewable Energy
Automotive
TL431ILP Information
TL431ILP by Texas Instruments is a Voltage Reference.
Voltage References are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for TL431ILP
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
29AH7987
|
Newark | Voltage Ref, Shunt, 2.495V-36V, To-226Aa, Voltage Reference Type:Shunt - Adjustable, Product Range:Tl431 Series, Reference Voltage:2.495V To 36V, Initial Accuracy:2%, Temperature Coefficient:-, Voltage Reference Case Style:To-226Aa, Rohs Compliant: Yes |Texas Instruments TL431ILP RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Bulk | 9 |
|
$0.5130 | Buy Now |
|
DISTI #
296-1292-ND
|
DigiKey | IC VREF SHUNT ADJ 2.2% TO92-3 Min Qty: 1 Lead time: 6 Weeks Container: Bulk |
1663 In Stock |
|
$0.4140 / $0.9000 | Buy Now |
|
DISTI #
595-TL431ILP
|
Mouser Electronics | Voltage References Adj Shunt RoHS: Compliant | 7177 |
|
$0.3560 / $0.9000 | Buy Now |
|
DISTI #
V99:2348_07373633
|
Arrow Electronics | V-Ref Adjustable 2.495V to 36V 100mA 3-Pin TO-92 Bulk RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 6 Weeks Date Code: 2219 | Americas - 978 |
|
$0.3217 / $0.5235 | Buy Now |
|
DISTI #
74514579
|
Verical | V-Ref Adjustable 2.495V to 36V 100mA 3-Pin TO-92 Bulk RoHS: Compliant Min Qty: 19 Package Multiple: 1 Date Code: 2219 | Americas - 978 |
|
$0.3217 / $0.4494 | Buy Now |
|
|
Bristol Electronics | 1600 |
|
RFQ | ||
|
|
Bristol Electronics | 352 |
|
RFQ | ||
|
|
Bristol Electronics | 346 |
|
RFQ | ||
|
|
Bristol Electronics | 21 |
|
RFQ | ||
|
|
Quest Components | 1-OUTPUT TWO TERM VOLTAGE REFERENCE, 2.495 V, PBCY3 | 394 |
|
$0.3163 / $0.6777 | Buy Now |
Part Details for TL431ILP
TL431ILP CAD Models
TL431ILP Part Data Attributes
|
|
TL431ILP
Texas Instruments
Buy Now
Datasheet
|
Compare Parts:
TL431ILP
Texas Instruments
Adjustable precision shunt regulator 3-TO-92 -40 to 85
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | TEXAS INSTRUMENTS INC | |
| Part Package Code | TO-92 | |
| Pin Count | 3 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Texas Instruments | |
| Additional Feature | OUTPUT VOLTAGE ADJUSTABLE FROM 2.495V TO 36V | |
| Analog IC - Other Type | TWO TERMINAL VOLTAGE REFERENCE | |
| JESD-30 Code | O-XBCY-T3 | |
| JESD-609 Code | e3 | |
| Number of Functions | 1 | |
| Number of Outputs | 1 | |
| Number of Terminals | 3 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Current-Max | 0.1 A | |
| Output Voltage-Max | 2.55 V | |
| Output Voltage-Min | 2.44 V | |
| Output Voltage-Nom | 2.495 V | |
| Package Body Material | UNSPECIFIED | |
| Package Code | TO-92 | |
| Package Equivalence Code | SIP3,.1,50 | |
| Package Shape | ROUND | |
| Package Style | CYLINDRICAL | |
| Qualification Status | Not Qualified | |
| Surface Mount | NO | |
| Technology | BIPOLAR | |
| Temp Coef of Voltage-Max | 92 ppm/°C | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Matte Tin (Sn) | |
| Terminal Form | THROUGH-HOLE | |
| Terminal Position | BOTTOM | |
| Trim/Adjustable Output | YES | |
| Voltage Tolerance-Max | 2.204408% |
Alternate Parts for TL431ILP
This table gives cross-reference parts and alternative options found for TL431ILP. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of TL431ILP, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| TL431CLP | Fairchild Semiconductor Corporation | Check for Price | Three Terminal Voltage Reference, 1 Output, 2.495V, Trim/Adjustable, BIPolar, PBCY3, TO-92, 3 PIN | TL431ILP vs TL431CLP |
| TL431CLP | Texas Instruments | Check for Price | Adjustable precision shunt regulator 3-TO-92 0 to 70 | TL431ILP vs TL431CLP |
| TL431ILP | Rochester Electronics LLC | Check for Price | Three Terminal Voltage Reference, 1 Output, 2.495V, Trim/Adjustable, BIPolar, PBCY3, ROHS COMPLIANT, PLASTIC, TO-226, TO-92, 3 PIN | TL431ILP vs TL431ILP |
| TL431CLPRPG | onsemi | $0.2872 | Voltage Reference, Programmable Precision, Shunt Regulator, TO-92 (TO-226) 5.33mm Body Height, 2000-FNFLD | TL431ILP vs TL431CLPRPG |
| TL431CLP | Rochester Electronics LLC | Check for Price | Three Terminal Voltage Reference, 1 Output, 2.495V, Trim/Adjustable, BIPolar, PBCY3, ROHS COMPLIANT, PLASTIC, TO-226, TO-92, 3 PIN | TL431ILP vs TL431CLP |
| TL431ILPG | onsemi | $0.3432 | Voltage Reference, Programmable Precision, Shunt Regulator, TO-92 (TO-226) 5.33mm Body Height, 2000-BLKBG | TL431ILP vs TL431ILPG |
| TL431CLPR | Texas Instruments | $0.1445 | Adjustable precision shunt regulator 3-TO-92 0 to 70 | TL431ILP vs TL431CLPR |
TL431ILP Frequently Asked Questions (FAQ)
-
The recommended operating temperature range for the TL431ILP is -40°C to 125°C.
-
Yes, the TL431ILP can be used as a voltage regulator, but it's primarily designed as a programmable precision reference voltage source.
-
To ensure stability, use a minimum capacitance of 10nF between the REF and ADJ pins, and a minimum resistance of 1kΩ between the ADJ pin and the output voltage.
-
The maximum output current of the TL431ILP is 15mA.
-
Yes, the TL431ILP is suitable for high-reliability applications, as it's built with a proprietary BiCMOS process and has a high level of radiation tolerance.
