Part Details for TL431AICT by STMicroelectronics
Results Overview of TL431AICT by STMicroelectronics
- Distributor Offerings: (13 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Consumer Electronics
Energy and Power Systems
Renewable Energy
Automotive
TL431AICT Information
TL431AICT by STMicroelectronics is a Voltage Reference.
Voltage References are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Price & Stock for TL431AICT
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
47AK7067
|
Newark | Volt Ref, Shunt - Adj, 2.495V, 105Deg C Rohs Compliant: Yes |Stmicroelectronics TL431AICT RoHS: Compliant Min Qty: 5 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 3015 |
|
$0.1580 / $0.3700 | Buy Now |
|
DISTI #
497-12010-1-ND
|
DigiKey | IC VREF SHUNT ADJ 1% SOT323-6L Min Qty: 1 Lead time: 10 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
7659 In Stock |
|
$0.1466 / $0.3700 | Buy Now |
|
DISTI #
TL431AICT
|
Avnet Americas | Voltage Reference, Shunt Adjustable, 2.47 V to 2.52 V, 6 Pins, SOT-323 - Tape and Reel (Alt: TL431AICT) RoHS: Compliant Min Qty: 6000 Package Multiple: 3000 Lead time: 10 Weeks, 0 Days Container: Reel | 0 |
|
$0.1294 / $0.1321 | Buy Now |
|
DISTI #
511-TL431AICT
|
Mouser Electronics | Voltage References 2.5V to 36V Shunt 1 to 100mA 0.22 Ohm RoHS: Compliant | 52041 |
|
$0.1410 / $0.3700 | Buy Now |
|
DISTI #
V36:1790_06568540
|
Arrow Electronics | V-Ref Adjustable 2.495V to 36V 100mA 6-Pin SOT-323 T/R RoHS: Compliant Min Qty: 6000 Package Multiple: 3000 Lead time: 10 Weeks Date Code: 2440 | Americas - 24000 |
|
$0.2243 / $0.2364 | Buy Now |
|
|
STMicroelectronics | Adjustable micropower shunt voltage reference RoHS: Compliant Min Qty: 1 | 52041 |
|
$0.1700 / $0.3600 | Buy Now |
|
|
Future Electronics | TL431 Series Adj 2.495 to 36 V ±1 % Programmable Voltage Reference - SOT-323-6 RoHS: Compliant pbFree: Yes Min Qty: 3000 Package Multiple: 3000 Lead time: 10 Weeks Container: Reel | 3000Reel |
|
$0.1340 / $0.1400 | Buy Now |
|
DISTI #
87021301
|
Verical | V-Ref Adjustable 2.495V to 36V 100mA 6-Pin SOT-323 T/R RoHS: Compliant Min Qty: 6000 Package Multiple: 3000 Date Code: 2440 | Americas - 24000 |
|
$0.2243 / $0.2364 | Buy Now |
|
|
Future Electronics | TL431 Series Adj 2.495 to 36 V �1 % Programmable Voltage Reference - SOT-323-6 Min Qty: 3000 Package Multiple: 3000 |
3000 null |
|
$0.1340 / $0.1400 | Buy Now |
|
DISTI #
TL431AICT
|
TME | IC: voltage reference source, 2.495V, ±1%, SOT323-6L, reel,tape Min Qty: 1 | 0 |
|
$0.1400 / $0.4480 | RFQ |
Part Details for TL431AICT
TL431AICT CAD Models
TL431AICT Part Data Attributes
|
|
TL431AICT
STMicroelectronics
Buy Now
Datasheet
|
Compare Parts:
TL431AICT
STMicroelectronics
Adjustable micropower shunt voltage reference
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | STMICROELECTRONICS | |
| Package Description | SOT-323, 6 PIN | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Factory Lead Time | 10 Weeks | |
| Samacsys Manufacturer | STMicroelectronics | |
| Additional Feature | ADJUSTABLE OUTPUT VOLTAGE FROM 2.5 TO 36 V | |
| Analog IC - Other Type | TWO TERMINAL VOLTAGE REFERENCE | |
| JESD-30 Code | R-PDSO-G6 | |
| JESD-609 Code | e3 | |
| Length | 2 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Outputs | 1 | |
| Number of Terminals | 6 | |
| Operating Temperature-Max | 105 °C | |
| Operating Temperature-Min | -40 °C | |
| Output Current-Max | 0.1 A | |
| Output Voltage-Max | 2.52 V | |
| Output Voltage-Min | 2.47 V | |
| Output Voltage-Nom | 2.495 V | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | TSSOP | |
| Package Equivalence Code | TSSOP6,.08 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, THIN PROFILE, SHRINK PITCH | |
| Peak Reflow Temperature (Cel) | 260 | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 1.1 mm | |
| Surface Mount | YES | |
| Technology | BIPOLAR | |
| Temp Coef of Voltage-Max | 82.924 ppm/°C | |
| Temperature Grade | INDUSTRIAL | |
| Terminal Finish | Matte Tin (Sn) - annealed | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Trim/Adjustable Output | YES | |
| Width | 1.25 mm |
TL431AICT Frequently Asked Questions (FAQ)
-
The TL431AICT can operate from -40°C to 125°C, making it suitable for a wide range of applications.
-
To ensure stability, it's essential to decouple the TL431AICT with a capacitor (typically 10nF to 100nF) between the REF and ADJ pins, and to use a low-ESR capacitor (e.g., ceramic or film) for the output capacitor.
-
To minimize noise and ensure proper operation, keep the TL431AICT away from high-current paths and noisy signals, use a solid ground plane, and keep the input and output capacitors close to the device. Also, use a low-impedance path for the output capacitor to minimize voltage drops.
-
The output voltage (Vout) of the TL431AICT can be calculated using the formula: Vout = Vref x (1 + R1/R2), where Vref is the internal reference voltage (2.5V), and R1 and R2 are the resistors connected between the REF and ADJ pins.
-
The typical current consumption of the TL431AICT is around 2.5mA, but this can vary depending on the specific application and operating conditions.
