TJA1145ATK/FD/0Z Information
TJA1145ATK/FD/0Z by NXP Semiconductors is a Network Interface.
Network Interfaces are under the broader part category of Telecommunication Circuits.
A telecommunications circuit transmits and receives information between points. Key components include transmitters, receivers, amplifiers, and multiplexers. Read more about Telecommunication Circuits on our Telecommunication Circuits part category page.
Price & Stock for TJA1145ATK/FD/0Z
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
21AJ6895
|
Newark | Can Fd Transceiver, 5Mbps, Hvson-14 Rohs Compliant: Yes |Nxp TJA1145ATK/FD/0Z RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 39 |
|
$1.9600 / $3.0600 | Buy Now |
|
DISTI #
40AH5446
|
Newark | High-Speed Can Transceiver For Partial Networking/ Reel Rohs Compliant: Yes |Nxp TJA1145ATK/FD/0Z RoHS: Compliant Min Qty: 6000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$1.4900 / $1.7000 | Buy Now |
|
DISTI #
568-TJA1145ATK/FD/0ZCT-ND
|
DigiKey | IC TRANSCEIVER FULL 1/1 14HVSON Min Qty: 1 Lead time: 15 Weeks Container: Digi-Reel®, Tape & Reel (TR), Cut Tape (CT) |
4068 In Stock |
|
$1.6174 / $3.1200 | Buy Now |
|
DISTI #
TJA1145ATK/FD/0Z
|
Avnet Americas | CAN FD Transceiver, 1 TX, 1 RX, 4.5 V to 5.5 V, 14 Pins, HVSON - Tape and Reel (Alt: TJA1145ATK/FD/0Z) Min Qty: 6000 Package Multiple: 6000 Lead time: 15 Weeks, 0 Days Container: Reel | 0 |
|
$1.4143 / $1.4627 | Buy Now |
|
DISTI #
771-TJA1145ATK/FD/0Z
|
Mouser Electronics | CAN Interface IC High-speed CAN transceiver for partial networking RoHS: Compliant | 0 |
|
$1.5800 / $3.1200 | Order Now |
|
DISTI #
87136383
|
Verical | CAN 5Mbps Normal/Sleep/Standby/Off/Overtemp 5V Automotive AEC-Q100 14-Pin HVSON EP T/R RoHS: Compliant Min Qty: 19 Package Multiple: 1 | Americas - 5166 |
|
$1.5900 / $2.1600 | Buy Now |
|
DISTI #
TJA1145ATK/FD/0Z
|
IBS Electronics | ROHS3COMPLIANT FULL TRANSCEIVER SURFACE MOUNT INTERFACE TRANSCEIVER -40C~150C TJ 5MBPS 800MV Min Qty: 6000 Package Multiple: 1 | 0 |
|
$2.0150 | Buy Now |
|
|
NXP Semiconductors | High-speed CAN transceiver for partial networking, Reel 13" Q1/T1 in Sulfur Barrier Bag RoHS: Compliant pbFree: Yes Lead time: 15 Weeks, 0 Days Container: Reel | 39578 |
|
$1.5100 / $1.7900 | Buy Now |
|
DISTI #
TJA1145ATK/FD/0Z
|
Avnet Silica | CAN FD Transceiver 1 TX 1 RX 45 V to 55 V 14 Pins HVSON (Alt: TJA1145ATK/FD/0Z) RoHS: Compliant Min Qty: 6000 Package Multiple: 6000 Lead time: 17 Weeks, 0 Days | Silica - 0 |
|
Buy Now | |
|
DISTI #
TJA1145ATK/FD/0Z
|
Chip One Stop | Semiconductors RoHS: Compliant Min Qty: 1 Lead time: 0 Weeks, 1 Days Container: Cut Tape | 5166 |
|
$1.4000 / $3.0800 | Buy Now |
Part Details for TJA1145ATK/FD/0Z
TJA1145ATK/FD/0Z CAD Models
TJA1145ATK/FD/0Z Part Data Attributes
|
|
TJA1145ATK/FD/0Z
NXP Semiconductors
Buy Now
Datasheet
|
Compare Parts:
TJA1145ATK/FD/0Z
NXP Semiconductors
1-Trnsvr, PDSO14
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | NXP SEMICONDUCTORS | |
| Package Description | HVSON-14 | |
| Reach Compliance Code | compliant | |
| Factory Lead Time | 15 Weeks | |
| Samacsys Manufacturer | NXP | |
| Data Rate | 5000 Mbps | |
| JESD-30 Code | R-PDSO-N14 | |
| JESD-609 Code | e4 | |
| Length | 3 mm | |
| Moisture Sensitivity Level | 1 | |
| Number of Functions | 1 | |
| Number of Terminals | 14 | |
| Number of Transceivers | 1 | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -40 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | HVSON | |
| Package Equivalence Code | SOLCC14,.12,25 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, HEAT SINK/SLUG, VERY THIN PROFILE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Screening Level | AEC-Q100 | |
| Seated Height-Max | 1 mm | |
| Supply Current-Max | 65 mA | |
| Supply Voltage-Nom | 5 V | |
| Surface Mount | YES | |
| Telecom IC Type | CAN FD TRANSCEIVER | |
| Terminal Finish | Nickel/Palladium/Gold/Silver (Ni/Pd/Au/Ag) | |
| Terminal Form | NO LEAD | |
| Terminal Pitch | 0.65 mm | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 4.5 mm |
