TFZVTR27B Information
TFZVTR27B by ROHM Semiconductor is a Zener Diode.
Zener Diodes are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for TFZVTR27B
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
91Y7052
|
Newark | Zener Diode, 0.5W, Sod-323He, Zener Voltage Vz Typ:27V, Power Dissipation Pd:500Mw, Diode Case Style:Sod-323He, Zener Tolerance ±:-, No. Of Pins:2Pins, Operating Temperature Max:150°C, Product Range:Tfzv Series, Automotive Rohs Compliant: Yes |Rohm TFZVTR27B RoHS: Compliant Min Qty: 5 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 0 |
|
Buy Now | |
|
DISTI #
TFZVTR27BCT-ND
|
DigiKey | DIODE ZENER 27V 500MW TUMD2M Min Qty: 1 Lead time: 17 Weeks Container: Digi-Reel®, Tape & Reel (TR), Cut Tape (CT) |
784 In Stock |
|
$0.0413 / $0.3200 | Buy Now |
|
DISTI #
755-TFZVTR27B
|
Mouser Electronics | Zener Diodes Zener Diode RoHS: Compliant | 7581 |
|
$0.0410 / $0.3200 | Buy Now |
|
DISTI #
69095257
|
Verical | Zener Diode Single 27V 3% 45Ohm 500mW 2-Pin TUMD-M T/R RoHS: Compliant Min Qty: 1042 Package Multiple: 1 Date Code: 2301 | Americas - 3000 |
|
$0.0681 / $0.0702 | Buy Now |
|
DISTI #
87728121
|
Verical | Zener Diode Single 27V 3% 45Ohm 500mW 2-Pin TUMD-M T/R RoHS: Compliant Min Qty: 1374 Package Multiple: 1 Date Code: 2449 | Americas - 2850 |
|
$0.0806 / $0.1900 | Buy Now |
|
DISTI #
62414153
|
Verical | Zener Diode Single 27V 3% 45Ohm 500mW 2-Pin TUMD-M T/R RoHS: Compliant Min Qty: 863 Package Multiple: 1 Date Code: 2201 | Americas - 872 |
|
$0.0812 | Buy Now |
|
|
Quest Components | 3097 |
|
$0.1230 / $0.4100 | Buy Now | |
|
DISTI #
TFZVTR27B
|
TTI | Zener Diodes Zener Diode RoHS: Compliant pbFree: Pb-Free Min Qty: 3000 Package Multiple: 3000 Container: Reel | Americas - 0 |
|
$0.0550 / $0.0570 | Buy Now |
|
DISTI #
TFZVTR27B
|
Avnet Asia | Diode Zener Single 27V 500mW 2-Pin TUMD T/R (Alt: TFZVTR27B) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 24 Weeks, 0 Days | 0 |
|
RFQ |
Part Details for TFZVTR27B
TFZVTR27B CAD Models
TFZVTR27B Part Data Attributes
|
|
TFZVTR27B
ROHM Semiconductor
Buy Now
Datasheet
|
Compare Parts:
TFZVTR27B
ROHM Semiconductor
Zener Diode,
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ROHM CO LTD | |
| Package Description | SC-108B, 2 PIN | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8541.10.00.50 | |
| Samacsys Manufacturer | ROHM Semiconductor | |
| Additional Feature | HIGH RELIABILITY | |
| Case Connection | CATHODE | |
| Configuration | SINGLE | |
| Diode Element Material | SILICON | |
| Diode Type | ZENER DIODE | |
| JESD-30 Code | R-PDSO-F2 | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 150 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity | UNIDIRECTIONAL | |
| Power Dissipation-Max | 0.5 W | |
| Reference Voltage-Nom | 27 V | |
| Surface Mount | YES | |
| Technology | ZENER | |
| Terminal Form | FLAT | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Voltage Tol-Max | 2.52% | |
| Working Test Current | 5 mA |
