TB6674FG Information
TB6674FG by Toshiba America Electronic Components is a Motion Control Electronic.
Motion Control Electronics are under the broader part category of Signal Circuits.
A signal is an electronic means of transmitting information, either as an analog signal with continuous values or a digital signal with discrete values. Signals are used in various systems and networks. Read more about Signal Circuits on our Signal Circuits part category page.
Part Details for TB6674FG
TB6674FG CAD Models
TB6674FG Part Data Attributes
|
|
TB6674FG
Toshiba America Electronic Components
Buy Now
Datasheet
|
Compare Parts:
TB6674FG
Toshiba America Electronic Components
IC STEPPER MOTOR CONTROLLER, 0.4 A, PDSO16, 0.300 INCH, 1 MM PITCH, PLASTIC, HSOP-16, Motion Control Electronics
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | TOSHIBA CORP | |
| Part Package Code | SOIC | |
| Package Description | SSOP, SOP16/24,.37,40 | |
| Pin Count | 16 | |
| Reach Compliance Code | unknown | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | Toshiba | |
| Analog IC - Other Type | STEPPER MOTOR CONTROLLER | |
| JESD-30 Code | R-PDSO-G16 | |
| Length | 13 mm | |
| Number of Functions | 1 | |
| Number of Terminals | 16 | |
| Operating Temperature-Max | 75 °C | |
| Operating Temperature-Min | -30 °C | |
| Output Current-Max | 0.4 A | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | SSOP | |
| Package Equivalence Code | SOP16/24,.37,40 | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE, SHRINK PITCH | |
| Qualification Status | Not Qualified | |
| Seated Height-Max | 2.85 mm | |
| Supply Current-Max (Isup) | 5 mA | |
| Supply Voltage-Max (Vsup) | 5.5 V | |
| Supply Voltage-Min (Vsup) | 4.5 V | |
| Supply Voltage-Nom (Vsup) | 5 V | |
| Surface Mount | YES | |
| Technology | BCDMOS | |
| Temperature Grade | COMMERCIAL EXTENDED | |
| Terminal Form | GULL WING | |
| Terminal Pitch | 1 mm | |
| Terminal Position | DUAL | |
| Width | 6.4 mm |
