3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for T55Z476M020C0070 by Vishay Intertechnologies
Results Overview of T55Z476M020C0070 by Vishay Intertechnologies
- Distributor Offerings: (6 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Consumer Electronics
Audio and Video Systems
Entertainment and Gaming
Automotive
T55Z476M020C0070 Information
T55Z476M020C0070 by Vishay Intertechnologies is a Tantalum Capacitor.
Tantalum Capacitors are under the broader part category of Capacitors.
A capacitor is a passive electronic component that stores energy. Capacitors are commonly used for energy storage, voltage suppression, and signal filtering. Read more about Capacitors on our Capacitors part category page.
Price & Stock for T55Z476M020C0070
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
78AC7178
|
Newark | Cap, 47Uf, 20V, Tant, Polymer, Case Z, Capacitance:47Μf, Capacitance Tolerance:± 20%, Voltage(Dc):20V, Manufacturer Size Code:Z, Esr:0.07Ohm, Capacitor Case/Package:2917 [7343 Metric], Product Length:7.3Mm, Product Width:4.3Mm Rohs Compliant: Yes |Vishay T55Z476M020C0070 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Cut Tape | 421 |
|
$0.0730 | Buy Now |
|
DISTI #
78AC7179
|
Newark | Cap, 47Uf, 20V, Tant, Polymer, Case Z, Capacitance:47Μf, Capacitance Tolerance:± 20%, Voltage(Dc):20V, Manufacturer Size Code:Z, Esr:0.07Ohm, Capacitor Case/Package:2917 [7343 Metric], Product Length:7.3Mm, Product Width:4.3Mm Rohs Compliant: Yes |Vishay T55Z476M020C0070 RoHS: Compliant Min Qty: 800 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.6450 / $0.8720 | Buy Now |
|
DISTI #
78AC7178
|
Avnet Americas | T55 vPolyTan Polymer High Performance Chip Capacitor 47uF 20V 7343-19 Size ?20% Tolerance 70m Ohm SMD T/R - Product that comes on tape, but is not reeled (Alt: 78AC7178) RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 21 Weeks, 3 Days Container: Ammo Pack | 421 Partner Stock |
|
$0.9760 / $1.7700 | Buy Now |
|
DISTI #
74-T55Z476M020C0070
|
Mouser Electronics | Tantalum Capacitors - Polymer 47uF 20volts 20% Z Case 70 Max. ESR RoHS: Compliant | 0 |
|
$0.6920 / $2.0200 | Order Now |
|
|
Chip 1 Exchange | INSTOCK | 4160 |
|
RFQ | |
|
|
Wuhan P&S | 47uF,20V,��20%,Solid Tantalum Cap Min Qty: 1 | 2400 |
|
$0.4000 / $1.6400 | Buy Now |
Part Details for T55Z476M020C0070
T55Z476M020C0070 CAD Models
T55Z476M020C0070 Part Data Attributes
|
|
T55Z476M020C0070
Vishay Intertechnologies
Buy Now
Datasheet
|
Compare Parts:
T55Z476M020C0070
Vishay Intertechnologies
Tantalum Capacitor, Tantalum (solid Polymer),
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | VISHAY INTERTECHNOLOGY INC | |
| Package Description | CHIP | |
| Reach Compliance Code | unknown | |
| ECCN Code | EAR99 | |
| HTS Code | 8532.21.00.50 | |
| Factory Lead Time | 21 Weeks, 3 Days | |
| Samacsys Manufacturer | Vishay | |
| Additional Feature | ESR AND RIPPLE CURRENT IS MEASURED AT 100KHZ | |
| Capacitance | 47 µF | |
| Capacitor Type | TANTALUM CAPACITOR | |
| Dielectric Material | TANTALUM (SOLID POLYMER) | |
| ESR | 70 mΩ | |
| Height | 1.8 mm | |
| JESD-609 Code | e4 | |
| Leakage Current | 0.094 mA | |
| Length | 7.3 mm | |
| Mounting Feature | SURFACE MOUNT | |
| Negative Tolerance | 20% | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 105 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Style | SMT | |
| Packing Method | TR, EMBOSSED PLASTIC, 7 INCH | |
| Polarity | POLARIZED | |
| Positive Tolerance | 20% | |
| Rated (DC) Voltage (URdc) | 20 V | |
| Ripple Current | 652 mA | |
| Size Code | 2917 | |
| Surface Mount | YES | |
| Tan Delta | 0.1 | |
| Terminal Finish | Nickel/Palladium/Gold (Ni/Pd/Au) | |
| Terminal Shape | J BEND | |
| Width | 4.3 mm |
