SZESD7351P2T5G Information
SZESD7351P2T5G by onsemi is a Transient Suppressor.
Transient Suppressors are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for SZESD7351P2T5G
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
81Y4173
|
Newark | Esd Diode, 3.3V, 0.15W, Sod-923, Clamping Voltage Vc Max:10V, Diode Case Style:Sod-923, No. Of Pins:2Pins, Operating Voltage:3.3V, Power Dissipation Pd:150Mw, Product Range:Szesd7351 Series, Automotive Qualification Standard:Aec-Q101Rohs Compliant: Yes |Onsemi SZESD7351P2T5G RoHS: Compliant Min Qty: 8000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.0750 / $0.0990 | Buy Now |
|
DISTI #
488-SZESD7351P2T5GCT-ND
|
DigiKey | TVS DIODE 3.3VWM SOD923 Min Qty: 1 Lead time: 5 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
5636 In Stock |
|
$0.0681 / $0.3400 | Buy Now |
|
DISTI #
SZESD7351P2T5G
|
Avnet Americas | ESD Protection Diode Uni-Directional 3.3 V Stand-Off 20 KV 2-Pin SOD-923 T/R - Tape and Reel (Alt: SZESD7351P2T5G) RoHS: Compliant Min Qty: 16000 Package Multiple: 8000 Lead time: 5 Weeks, 0 Days Container: Reel | 0 |
|
$0.0646 / $0.0696 | Buy Now |
|
DISTI #
863-SZESD7351P2T5G
|
Mouser Electronics | ESD Protection Diodes / TVS Diodes LOW CAP ESD IN SOD-923 RoHS: Compliant | 11798 |
|
$0.0720 / $0.3400 | Buy Now |
|
|
Onlinecomponents.com | ESD Protection Diode SOD-923 Automotive RoHS: Compliant | Alternative Product Available |
|
$0.0641 / $0.0734 | Buy Now |
|
DISTI #
86036289
|
Verical | ESD Suppressor TVS Uni-Dir 3.3V 2-Pin SOD-923 T/R Automotive AEC-Q101 RoHS: Compliant Min Qty: 3932 Package Multiple: 1 Date Code: 2201 | Americas - 192000 |
|
$0.0713 / $0.0954 | Buy Now |
|
DISTI #
86035310
|
Verical | ESD Suppressor TVS Uni-Dir 3.3V 2-Pin SOD-923 T/R Automotive AEC-Q101 RoHS: Compliant Min Qty: 3932 Package Multiple: 1 Date Code: 2101 | Americas - 184000 |
|
$0.0713 / $0.0954 | Buy Now |
|
|
Rochester Electronics | ESD7351 - ESD Protection Diode SOD-923 Automotive RoHS: Compliant Status: Active Min Qty: 1 | 376000 |
|
$0.0570 / $0.0919 | Buy Now |
|
|
Future Electronics | esd Min Qty: 8000 Package Multiple: 8000 |
8000 null |
|
$0.0560 / $0.0591 | Buy Now |
|
DISTI #
SZESD7351P2T5G
|
Richardson RFPD | TVS RoHS: Compliant Min Qty: 16000 | 0 |
|
$0.0700 | Buy Now |
Part Details for SZESD7351P2T5G
SZESD7351P2T5G CAD Models
SZESD7351P2T5G Part Data Attributes
|
|
SZESD7351P2T5G
onsemi
Buy Now
Datasheet
|
Compare Parts:
SZESD7351P2T5G
onsemi
ESD Protection Diode SOD-923 Automotive, SOD-923-2, 8000-REEL, Automotive Qualified
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | ONSEMI | |
| Part Package Code | SOD-923-2 | |
| Manufacturer Package Code | 514AB | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8541.10.00.50 | |
| Factory Lead Time | 5 Weeks | |
| Samacsys Manufacturer | onsemi | |
| Additional Feature | EXCELLENT CLAMPING CAPABILITY, LOW CAPACITANCE, ULTRA LOW CAPACITANCE | |
| Breakdown Voltage-Min | 5 V | |
| Breakdown Voltage-Nom | 5 V | |
| Clamping Voltage-Max | 10 V | |
| Configuration | SINGLE | |
| Diode Element Material | SILICON | |
| Diode Type | TRANS VOLTAGE SUPPRESSOR DIODE | |
| JESD-30 Code | R-PDSO-F2 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 150 °C | |
| Operating Temperature-Min | -55 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity | UNIDIRECTIONAL | |
| Power Dissipation-Max | 0.15 W | |
| Reference Standard | AEC-Q101; IEC-61000-4-5 | |
| Rep Pk Reverse Voltage-Max | 3.3 V | |
| Surface Mount | YES | |
| Technology | AVALANCHE | |
| Terminal Finish | Matte Tin (Sn) - annealed | |
| Terminal Form | FLAT | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 30 |
