Part Details for STY139N65M5 by STMicroelectronics
Results Overview of STY139N65M5 by STMicroelectronics
- Distributor Offerings: (14 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Energy and Power Systems
Renewable Energy
STY139N65M5 Information
STY139N65M5 by STMicroelectronics is a Power Field-Effect Transistor.
Power Field-Effect Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for STY139N65M5
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
45AC7799
|
Newark | Mosfet, N-Ch, 650V, 130A, Max-247, Channel Type:N Channel, Drain Source Voltage Vds:650V, Continuous Drain Current Id:130A, Transistor Mounting:Through Hole, Rds(On) Test Voltage:10V, Gate Source Threshold Voltage Max:4V Rohs Compliant: Yes |Stmicroelectronics STY139N65M5 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 0 Container: Bulk | 1436 |
|
$33.3100 / $38.7000 | Buy Now |
|
DISTI #
24AC0059
|
Newark | Ptd High Voltage Rohs Compliant: Yes |Stmicroelectronics STY139N65M5 RoHS: Compliant Min Qty: 600 Package Multiple: 1 Date Code: 0 Container: Bulk | 0 |
|
$30.8300 | Buy Now |
|
DISTI #
497-13043-5-ND
|
DigiKey | MOSFET N-CH 650V 130A MAX247 Min Qty: 1 Lead time: 16 Weeks Container: Tube | Temporarily Out of Stock |
|
$24.5440 / $33.2500 | Buy Now |
|
DISTI #
45AC7799
|
Avnet Americas | Trans MOSFET N-CH 650V 130A 3-Pin(3+Tab) Max247 Tube - Bulk (Alt: 45AC7799) RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 111 Weeks, 0 Days Container: Bulk | 125 Partner Stock |
|
$30.2800 / $35.6900 | Buy Now |
|
DISTI #
STY139N65M5
|
Avnet Americas | Trans MOSFET N-CH 650V 130A 3-Pin(3+Tab) Max247 Tube - Rail/Tube (Alt: STY139N65M5) RoHS: Compliant Min Qty: 600 Package Multiple: 600 Lead time: 16 Weeks, 0 Days Container: Tube | 0 |
|
$20.4679 / $21.7633 | Buy Now |
|
DISTI #
511-STY139N65M5
|
Mouser Electronics | MOSFETs N-Ch 650V 0.014 Ohm Mdmesh M5 130A RoHS: Compliant | 488 |
|
$24.3000 / $33.5000 | Buy Now |
|
DISTI #
E02:0323_05956340
|
Arrow Electronics | Trans MOSFET N-CH 650V 130A 3-Pin(3+Tab) Max247 Tube Min Qty: 1 Package Multiple: 1 Lead time: 16 Weeks Date Code: 2511 | Europe - 7321 |
|
$24.3501 / $24.6015 | Buy Now |
|
|
STMicroelectronics | N-channel 650 V, 0.014 Ohm typ., 130 A MDmesh M5 Power MOSFET in Max247 package RoHS: Compliant Min Qty: 1 | 382 |
|
$24.5400 / $33.2400 | Buy Now |
|
DISTI #
88074880
|
Verical | Trans MOSFET N-CH 650V 130A 3-Pin(3+Tab) Max247 Tube Min Qty: 1 Package Multiple: 1 Date Code: 2511 | Americas - 7321 |
|
$24.4488 / $24.7011 | Buy Now |
|
DISTI #
STY139N65M5
|
TME | Transistor: N-MOSFET, MDmesh™ V, unipolar, 650V, 78A, 625W, MAX247 Min Qty: 1 | 0 |
|
$25.6500 / $35.9100 | RFQ |
Part Details for STY139N65M5
STY139N65M5 CAD Models
STY139N65M5 Part Data Attributes
|
|
STY139N65M5
STMicroelectronics
Buy Now
Datasheet
|
Compare Parts:
STY139N65M5
STMicroelectronics
N-channel 650 V, 0.014 Ohm typ., 130 A MDmesh M5 Power MOSFET in Max247 package
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | STMICROELECTRONICS | |
| Package Description | ROHS COMPLIANT, MAX247, 3 PIN | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| Factory Lead Time | 16 Weeks | |
| Samacsys Manufacturer | STMicroelectronics | |
| Avalanche Energy Rating (Eas) | 2400 mJ | |
| Configuration | SINGLE WITH BUILT-IN DIODE | |
| DS Breakdown Voltage-Min | 650 V | |
| Drain Current-Max (ID) | 130 A | |
| Drain-source On Resistance-Max | 0.017 Ω | |
| FET Technology | METAL-OXIDE SEMICONDUCTOR | |
| JESD-30 Code | R-PSIP-T3 | |
| Number of Elements | 1 | |
| Number of Terminals | 3 | |
| Operating Mode | ENHANCEMENT MODE | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | IN-LINE | |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED | |
| Polarity/Channel Type | N-CHANNEL | |
| Pulsed Drain Current-Max (IDM) | 520 A | |
| Surface Mount | NO | |
| Terminal Form | THROUGH-HOLE | |
| Terminal Position | SINGLE | |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED | |
| Transistor Application | SWITCHING | |
| Transistor Element Material | SILICON |
