Part Details for STPS1545G-TR by STMicroelectronics
Results Overview of STPS1545G-TR by STMicroelectronics
- Distributor Offerings: (11 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (1 option)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
STPS1545G-TR Information
STPS1545G-TR by STMicroelectronics is a Rectifier Diode.
Rectifier Diodes are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for STPS1545G-TR
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
3366908
|
Farnell | SCHOTTKY RECTIFIER, 45V, 15A, TO-263 RoHS: Compliant Min Qty: 1 Lead time: 39 Weeks, 1 Days Container: Cut Tape | 5314 |
|
$0.8074 / $1.9687 | Buy Now |
|
DISTI #
3366908RL
|
Farnell | SCHOTTKY RECTIFIER, 45V, 15A, TO-263 RoHS: Compliant Min Qty: 100 Lead time: 39 Weeks, 1 Days Container: Reel | 5314 |
|
$0.8074 / $1.1426 | Buy Now |
|
|
STMicroelectronics | Power Schottky Rectifier RoHS: Compliant Min Qty: 1 | 31 |
|
$1.1000 / $1.5800 | Buy Now |
|
DISTI #
86023425
|
Verical | Diode Schottky 45V 15A 3-Pin(2+Tab) D2PAK T/R Automotive AEC-Q101 Min Qty: 286 Package Multiple: 1 Date Code: 2101 | Americas - 90000 |
|
$0.9713 / $1.3125 | Buy Now |
|
DISTI #
86039174
|
Verical | Diode Schottky 45V 15A 3-Pin(2+Tab) D2PAK T/R Automotive AEC-Q101 Min Qty: 286 Package Multiple: 1 | Americas - 60000 |
|
$0.9713 / $1.3125 | Buy Now |
|
|
Rochester Electronics | STPS1545 - Automotive Analog and Power-AUTO RoHS: Compliant Status: Active Min Qty: 1 | 150000 |
|
$0.6510 / $1.0500 | Buy Now |
|
DISTI #
STPS1545G-TR
|
TME | Diode: Schottky rectifying, D2PAK, SMD, 45V, 15A, reel,tape Min Qty: 1 | 0 |
|
$0.3570 / $0.7220 | RFQ |
|
DISTI #
STPS1545G-TR
|
Avnet Silica | Diode Schottky 45V 15A 3Pin2Tab D2PAK TR (Alt: STPS1545G-TR) RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 143 Weeks, 0 Days | Silica - 0 |
|
Buy Now | |
|
DISTI #
STPS1545G-TR
|
EBV Elektronik | Diode Schottky 45V 15A 3Pin2Tab D2PAK TR (Alt: STPS1545G-TR) RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 143 Weeks, 0 Days | EBV - 3000 |
|
Buy Now | |
|
|
LCSC | 45V 15A 840mV30A D2PAK Schottky Diodes ROHS | 1 |
|
$2.6191 / $4.2244 | Buy Now |
Part Details for STPS1545G-TR
STPS1545G-TR CAD Models
STPS1545G-TR Part Data Attributes
|
|
STPS1545G-TR
STMicroelectronics
Buy Now
Datasheet
|
Compare Parts:
STPS1545G-TR
STMicroelectronics
45 V, 15 A Power Schottky Rectifier
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | STMICROELECTRONICS | |
| Part Package Code | TO-263 | |
| Package Description | D2PAK-3 | |
| Pin Count | 3 | |
| Reach Compliance Code | not_compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8541.10.00.80 | |
| Samacsys Manufacturer | STMicroelectronics | |
| Additional Feature | FREE WHEELING DIODE | |
| Application | FAST RECOVERY POWER | |
| Case Connection | CATHODE | |
| Configuration | SINGLE | |
| Diode Element Material | SILICON | |
| Diode Type | RECTIFIER DIODE | |
| Forward Voltage-Max (VF) | 0.57 V | |
| JESD-30 Code | R-PSSO-G2 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Non-rep Pk Forward Current-Max | 220 A | |
| Number of Elements | 1 | |
| Number of Phases | 1 | |
| Number of Terminals | 2 | |
| Operating Temperature-Max | 175 °C | |
| Output Current-Max | 15 A | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 245 | |
| Qualification Status | Not Qualified | |
| Rep Pk Reverse Voltage-Max | 45 V | |
| Surface Mount | YES | |
| Technology | SCHOTTKY | |
| Terminal Finish | Matte Tin (Sn) - annealed | |
| Terminal Form | GULL WING | |
| Terminal Position | SINGLE | |
| Time@Peak Reflow Temperature-Max (s) | 30 |
Alternate Parts for STPS1545G-TR
This table gives cross-reference parts and alternative options found for STPS1545G-TR. The Form Fit Function (FFF) tab will give you the options that are more likely to serve as direct pin-to-pin alternates or drop-in parts. The Functional Equivalents tab will give you options that are likely to match the same function of STPS1545G-TR, but it may not fit your design. Always verify details of parts you are evaluating, as these parts are offered as suggestions for what you are looking for and are not guaranteed.
| Part Number | Manufacturer | Composite Price | Description | Compare |
|---|---|---|---|---|
| STPS1545G | STMicroelectronics | Check for Price | Power Schottky Rectifier | STPS1545G-TR vs STPS1545G |
