STLD40DPMR Information
STLD40DPMR by STMicroelectronics is a Switching Regulator or Controller.
Switching Regulator or Controllers are under the broader part category of Power Circuits.
A power circuit delivers electricity in order to operate a load for an electronic device. Power circuits include transformers, generators and switches. Read more about Power Circuits on our Power Circuits part category page.
Part Details for STLD40DPMR
STLD40DPMR CAD Models
STLD40DPMR Part Data Attributes
|
|
STLD40DPMR
STMicroelectronics
Buy Now
Datasheet
|
Compare Parts:
STLD40DPMR
STMicroelectronics
White Led Power Supply For Large Display Backlight
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Obsolete | |
| Ihs Manufacturer | STMICROELECTRONICS | |
| Part Package Code | DFN | |
| Package Description | 3 X 3 MM, 1 MM HEIGHT, LEAD FREE, DFN-8 | |
| Pin Count | 8 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8542.39.00.01 | |
| Samacsys Manufacturer | STMicroelectronics |
STLD40DPMR Frequently Asked Questions (FAQ)
-
A 2-layer or 4-layer PCB with a solid ground plane and thermal vias is recommended. Ensure a minimum of 1mm clearance around the device for airflow and heat dissipation.
-
Implement a thermal management strategy, such as a heat sink or thermal interface material, to keep the junction temperature below 150°C. Monitor the device's thermal status using the thermal monitoring pin (TMON).
-
Use a common-mode choke and a differential-mode filter to reduce EMI emissions. Ensure proper shielding of the device and PCB traces to minimize radiation. Follow the recommended layout and component placement guidelines in the datasheet.
-
Use a low-ESR capacitor (e.g., 10uF) for power supply decoupling, and place it as close as possible to the device's power pins. Ensure a stable power supply voltage within the recommended range (3.3V to 5.5V).
-
Use controlled impedance traces (e.g., 50Ω) for high-speed signals, and ensure proper termination and matching. Minimize signal reflections and ringing by using series resistors or AC coupling capacitors.
