STL8DN10LF3 Information
STL8DN10LF3 by STMicroelectronics is a Power Field-Effect Transistor.
Power Field-Effect Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for STL8DN10LF3
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
45AC7623
|
Newark | Mosfet, Aec-Q101, N-Ch, 100V, Powerflat, Channel Type:N Channel, Drain Source Voltage Vds:100V, Continuous Drain Current Id:20A, Transistor Mounting:Surface Mount, Rds(On) Test Voltage:10V, Gate Source Threshold Voltage Max:3V Rohs Compliant: Yes |Stmicroelectronics STL8DN10LF3 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 159 |
|
$1.3900 / $2.5200 | Buy Now |
|
DISTI #
497-13168-1-ND
|
DigiKey | MOSFET 2N-CH 100V 20A POWERFLAT Min Qty: 1 Lead time: 13 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
1989 In Stock |
|
$0.8600 / $2.6100 | Buy Now |
|
DISTI #
STL8DN10LF3
|
Avnet Americas | Power MOSFET, N Channel, 100 V, 20 A, 0.025 ohm, PowerFLAT, Surface Mount - Tape and Reel (Alt: STL8DN10LF3) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 13 Weeks, 0 Days Container: Reel | 0 |
|
$0.8600 / $0.9185 | Buy Now |
|
DISTI #
STL8DN10LF3
|
Avnet Americas | Power MOSFET, N Channel, 100 V, 20 A, 0.025 ohm, PowerFLAT, Surface Mount - Tape and Reel (Alt: STL8DN10LF3) RoHS: Compliant Min Qty: 3000 Package Multiple: 3000 Lead time: 13 Weeks, 0 Days Container: Reel | 0 |
|
$0.8190 / $0.8709 | Buy Now |
|
DISTI #
511-STL8DN10LF3
|
Mouser Electronics | MOSFETs Dual N-Ch 100V 7.8A 25mOhm STripFET III RoHS: Compliant | 3235 |
|
$0.8600 / $2.5600 | Buy Now |
|
DISTI #
E02:0323_06872209
|
Arrow Electronics | Trans MOSFET N-CH 100V 20A 8-Pin Power Flat T/R Automotive AEC-Q101 Min Qty: 3000 Package Multiple: 3000 Lead time: 13 Weeks Date Code: 2441 | Europe - 3000 |
|
$0.8529 | Buy Now |
|
|
STMicroelectronics | Automotive-grade dual N-channel 100 V, 25 mOhm typ., 7.8 A STripFET F3 Power MOSFET in PowerFLAT 5x6 double island package RoHS: Compliant Min Qty: 1 | 3235 |
|
$1.0200 / $2.5100 | Buy Now |
|
DISTI #
85914691
|
Verical | Trans MOSFET N-CH 100V 20A 8-Pin Power Flat T/R Automotive AEC-Q101 Min Qty: 3000 Package Multiple: 3000 Date Code: 2441 | Americas - 3000 |
|
$0.8553 | Buy Now |
|
DISTI #
STL8DN10LF3
|
TME | Transistor: N-MOSFET, unipolar Min Qty: 1 | 0 |
|
$1.1800 / $2.0900 | RFQ |
|
DISTI #
STL8DN10LF3
|
IBS Electronics | TRANSISTOR MOSFET ARRAY DUAL N-CH 100V 20A 8-PIN POWERFLAT T/R Min Qty: 3000 Package Multiple: 1 | 6000 |
|
$1.0595 | Buy Now |
Part Details for STL8DN10LF3
STL8DN10LF3 CAD Models
STL8DN10LF3 Part Data Attributes
|
|
STL8DN10LF3
STMicroelectronics
Buy Now
Datasheet
|
Compare Parts:
STL8DN10LF3
STMicroelectronics
Automotive-grade dual N-channel 100 V, 25 mOhm typ., 7.8 A STripFET F3 Power MOSFET in PowerFLAT 5x6 double island package
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | STMICROELECTRONICS | |
| Package Description | ROHS COMPLIANT, POWERFLAT-8 | |
| Reach Compliance Code | not_compliant | |
| ECCN Code | EAR99 | |
| Factory Lead Time | 13 Weeks | |
| Samacsys Manufacturer | STMicroelectronics | |
| Additional Feature | AVALANCHE RATED | |
| Avalanche Energy Rating (Eas) | 190 mJ | |
| Case Connection | DRAIN | |
| Configuration | SEPARATE, 2 ELEMENTS WITH BUILT-IN DIODE | |
| DS Breakdown Voltage-Min | 100 V | |
| Drain Current-Max (ID) | 20 A | |
| Drain-source On Resistance-Max | 0.05 Ω | |
| FET Technology | METAL-OXIDE SEMICONDUCTOR | |
| JESD-30 Code | R-PDSO-F6 | |
| JESD-609 Code | e3 | |
| Moisture Sensitivity Level | 1 | |
| Number of Elements | 2 | |
| Number of Terminals | 6 | |
| Operating Mode | ENHANCEMENT MODE | |
| Operating Temperature-Max | 175 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity/Channel Type | N-CHANNEL | |
| Power Dissipation-Max (Abs) | 70 W | |
| Pulsed Drain Current-Max (IDM) | 31.2 A | |
| Reference Standard | AEC-Q101 | |
| Surface Mount | YES | |
| Terminal Finish | Matte Tin (Sn) - annealed | |
| Terminal Form | FLAT | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED | |
| Transistor Application | SWITCHING | |
| Transistor Element Material | SILICON |
