STF7NM60N Information
STF7NM60N by STMicroelectronics is a Power Field-Effect Transistor.
Power Field-Effect Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for STF7NM60N
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
94T3406
|
Newark | Power Mosfet, N Channel, 5 A, 600 V, 0.84 Ohm, 10 V, 3 V Rohs Compliant: Yes |Stmicroelectronics STF7NM60N RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 740 |
|
$0.8990 / $2.2400 | Buy Now |
|
DISTI #
497-10570-5-ND
|
DigiKey | MOSFET N-CH 600V 5A TO220FP Min Qty: 1 Lead time: 14 Weeks Container: Tube |
795 In Stock |
|
$1.2705 / $2.2800 | Buy Now |
|
DISTI #
STF7NM60N
|
Avnet Americas | Trans MOSFET N-CH 600V 5A 3-Pin(3+Tab) TO-220FP Tube - Rail/Tube (Alt: STF7NM60N) RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 14 Weeks, 0 Days Container: Tube | 0 |
|
$1.2100 / $1.2866 | Buy Now |
|
DISTI #
511-STF7NM60N
|
Mouser Electronics | MOSFETs N-Ch 600 V 4.7 A MDmesh 2nd Gen RoHS: Compliant | 601 |
|
$1.2700 / $1.6300 | Buy Now |
|
DISTI #
V79:2366_24002865
|
Arrow Electronics | Trans MOSFET N-CH 600V 5A 3-Pin(3+Tab) TO-220FP Tube Min Qty: 1 Package Multiple: 1 Date Code: 1742 | Americas - 4214 |
|
$0.9947 | Buy Now |
|
DISTI #
E02:0323_03155867
|
Arrow Electronics | Trans MOSFET N-CH 600V 5A 3-Pin(3+Tab) TO-220FP Tube Min Qty: 1 Package Multiple: 1 Lead time: 14 Weeks Date Code: 2508 | Europe - 1443 |
|
$1.4324 / $2.5705 | Buy Now |
|
|
STMicroelectronics | N-channel 600 V, 0.8 Ohm typ., 5 A MDmesh II Power MOSFET in TO-220FP package RoHS: Compliant Min Qty: 1 | 601 |
|
$1.2900 / $1.6000 | Buy Now |
|
|
Future Electronics | N-Channel 600 V 0.9 Ω MDmesh™ Power MOSFET - TO-220FP RoHS: Compliant pbFree: Yes Min Qty: 1 Package Multiple: 1 Lead time: 14 Weeks Container: Tube | 500Tube |
|
$1.3700 / $1.4700 | Buy Now |
|
|
Future Electronics | N-Channel 600 V 0.9 Ω MDmesh™ Power MOSFET - TO-220FP RoHS: Compliant pbFree: Yes Min Qty: 1000 Package Multiple: 50 Lead time: 14 Weeks Container: Tube | 0Tube |
|
$1.3700 / $1.4400 | Buy Now |
|
DISTI #
35894472
|
Verical | Trans MOSFET N-CH 600V 5A 3-Pin(3+Tab) TO-220FP Tube Min Qty: 6 Package Multiple: 1 Date Code: 1742 | Americas - 4214 |
|
$0.9947 | Buy Now |
Part Details for STF7NM60N
STF7NM60N CAD Models
STF7NM60N Part Data Attributes
|
|
STF7NM60N
STMicroelectronics
Buy Now
Datasheet
|
Compare Parts:
STF7NM60N
STMicroelectronics
N-channel 600 V, 0.8 Ohm typ., 5 A MDmesh II Power MOSFET in TO-220FP package
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | STMICROELECTRONICS | |
| Part Package Code | TO-220AB | |
| Pin Count | 3 | |
| Reach Compliance Code | not_compliant | |
| ECCN Code | EAR99 | |
| Factory Lead Time | 14 Weeks | |
| Samacsys Manufacturer | STMicroelectronics | |
| Avalanche Energy Rating (Eas) | 119 mJ | |
| Case Connection | ISOLATED | |
| Configuration | SINGLE WITH BUILT-IN DIODE | |
| DS Breakdown Voltage-Min | 600 V | |
| Drain Current-Max (ID) | 5 A | |
| Drain-source On Resistance-Max | 0.9 Ω | |
| FET Technology | METAL-OXIDE SEMICONDUCTOR | |
| JEDEC-95 Code | TO-220AB | |
| JESD-30 Code | R-PSFM-T3 | |
| Number of Elements | 1 | |
| Number of Terminals | 3 | |
| Operating Mode | ENHANCEMENT MODE | |
| Operating Temperature-Max | 150 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | FLANGE MOUNT | |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED | |
| Polarity/Channel Type | N-CHANNEL | |
| Power Dissipation-Max (Abs) | 20 W | |
| Pulsed Drain Current-Max (IDM) | 20 A | |
| Qualification Status | Not Qualified | |
| Surface Mount | NO | |
| Terminal Form | THROUGH-HOLE | |
| Terminal Position | SINGLE | |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED | |
| Transistor Application | SWITCHING | |
| Transistor Element Material | SILICON |
