STF5N62K3 Information
STF5N62K3 by STMicroelectronics is a Power Field-Effect Transistor.
Power Field-Effect Transistors are under the broader part category of Transistors.
A transistor is a small semiconductor device used to amplify, control, or create electrical signals. When selecting a transistor, factors such as voltage, current rating, gain, and power dissipation must be considered, with common types. Read more about Transistors on our Transistors part category page.
Price & Stock for STF5N62K3
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
94T3402
|
Newark | Mosfet Transistor, N Channel, 4.2 A, 620 V, 1.28 Ohm, 10 V, 3.75 V Rohs Compliant: Yes |Stmicroelectronics STF5N62K3 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 578 |
|
$1.2100 / $2.6700 | Buy Now |
|
DISTI #
497-12583-5-ND
|
DigiKey | MOSFET N-CH 620V 4.2A TO220FP Min Qty: 1 Lead time: 13 Weeks Container: Tube | Temporarily Out of Stock |
|
$0.9982 / $2.4300 | Buy Now |
|
DISTI #
STF5N62K3
|
Avnet Americas | Trans MOSFET N-CH 620V 4.2A 3-Pin(3+Tab) TO-220FP Tube - Rail/Tube (Alt: STF5N62K3) RoHS: Compliant Min Qty: 1000 Package Multiple: 1000 Lead time: 111 Weeks, 0 Days Container: Tube | 0 |
|
RFQ | |
|
DISTI #
511-STF5N62K3
|
Mouser Electronics | MOSFETs N-Ch 620V 1.28V Ohm 4.2A SuperMESH 3 RoHS: Compliant | 920 |
|
$0.9980 / $2.3800 | Buy Now |
|
|
STMicroelectronics | N-channel 620 V, 1.28 Ohm typ., 4.2 A MDmesh K3 Power MOSFET in a TO-220FP package COO: China RoHS: Compliant Min Qty: 1 | 920 |
|
$1.0400 / $2.3300 | Buy Now |
|
DISTI #
STF5N62K3
|
TME | Transistor: N-MOSFET, unipolar Min Qty: 1 | 0 |
|
$0.7700 / $2.0500 | RFQ |
|
|
ComSIT USA | 620 V, 4.2 A, 1.28 OHM, TO-220FP SUPERMESH3 N-CHANNEL POWER MOSFET Power Field-Effect Transistor, 4.2A I(D), 620V, 1.6ohm, 1-Element, N-Channel, Silicon, Metal-oxide Semiconductor FET, TO-220AB ECCN: EAR99 RoHS: Compliant |
|
|
RFQ | |
|
DISTI #
STF5N62K3
|
Avnet Silica | Trans MOSFET NCH 620V 42A 3Pin3Tab TO220FP Tube (Alt: STF5N62K3) RoHS: Compliant Min Qty: 2000 Package Multiple: 50 Lead time: 14 Weeks, 0 Days | Silica - 0 |
|
Buy Now | |
|
DISTI #
STF5N62K3
|
EBV Elektronik | Trans MOSFET NCH 620V 42A 3Pin3Tab TO220FP Tube (Alt: STF5N62K3) RoHS: Compliant Min Qty: 50 Package Multiple: 50 Lead time: 14 Weeks, 0 Days | EBV - 0 |
|
Buy Now |
Part Details for STF5N62K3
STF5N62K3 CAD Models
STF5N62K3 Part Data Attributes
|
|
STF5N62K3
STMicroelectronics
Buy Now
Datasheet
|
Compare Parts:
STF5N62K3
STMicroelectronics
N-channel 620 V, 1.28 Ohm typ., 4.2 A SuperMESH3(TM) Power MOSFET in TO-220FP package
|
| Rohs Code | Yes | |
| Part Life Cycle Code | End Of Life | |
| Ihs Manufacturer | STMICROELECTRONICS | |
| Part Package Code | TO-220AB | |
| Pin Count | 3 | |
| Reach Compliance Code | not_compliant | |
| ECCN Code | EAR99 | |
| Factory Lead Time | 111 Weeks | |
| Samacsys Manufacturer | STMicroelectronics | |
| Additional Feature | ULTRA LOW-ON RESISTANCE | |
| Avalanche Energy Rating (Eas) | 120 mJ | |
| Case Connection | ISOLATED | |
| Configuration | SINGLE WITH BUILT-IN DIODE | |
| DS Breakdown Voltage-Min | 620 V | |
| Drain Current-Max (ID) | 4.2 A | |
| Drain-source On Resistance-Max | 1.6 Ω | |
| FET Technology | METAL-OXIDE SEMICONDUCTOR | |
| JEDEC-95 Code | TO-220AB | |
| JESD-30 Code | R-PSFM-T3 | |
| Number of Elements | 1 | |
| Number of Terminals | 3 | |
| Operating Mode | ENHANCEMENT MODE | |
| Operating Temperature-Max | 150 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | FLANGE MOUNT | |
| Peak Reflow Temperature (Cel) | NOT SPECIFIED | |
| Polarity/Channel Type | N-CHANNEL | |
| Power Dissipation-Max (Abs) | 25 W | |
| Pulsed Drain Current-Max (IDM) | 16.8 A | |
| Surface Mount | NO | |
| Terminal Form | THROUGH-HOLE | |
| Terminal Position | SINGLE | |
| Time@Peak Reflow Temperature-Max (s) | NOT SPECIFIED | |
| Transistor Application | SWITCHING | |
| Transistor Element Material | SILICON |
