3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for SSA-LXB20SIW by ITW Lumex
Results Overview of SSA-LXB20SIW by ITW Lumex
- Distributor Offerings: (3 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
Applications
Consumer Electronics
Industrial Automation
SSA-LXB20SIW Information
SSA-LXB20SIW by ITW Lumex is a Visible LED.
Visible LEDs are under the broader part category of Optoelectronics.
Optoelectronic components work to detect, generate, and control light. They can essentially produce and/or react to light. Read more about Optoelectronics on our Optoelectronics part category page.
Available Datasheets
| Part # | Manufacturer | Description | Datasheet |
|---|---|---|---|
| 54AC377/SSA | Rochester Electronics LLC | 54AC377/SSA - Dual marked (M38510/75603SSA) - SPACE-LEVEL LOGIC | |
| 54AC240/SSA-R | Texas Instruments | 54AC240/SSA-R - Dual marked (M38510R75703SSA) - SPACE-LEVEL LOGIC |
Price & Stock for SSA-LXB20SIW
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
SSA-LXB20SIW-ND
|
DigiKey | LED CBI 5.08X2MM 20-SEG RED VERT Lead time: 14 Weeks Container: Tube | Temporarily Out of Stock |
|
Buy Now | |
|
DISTI #
696-LXB20SIW
|
Mouser Electronics | LED Bars & Arrays 20 SEGMENT RED RoHS: Compliant | 0 |
|
$5.2800 | Order Now |
|
DISTI #
71495461
|
RS | 2X5mm 20SEG ARRY, AlInGaP RED, BLK/WHT Min Qty: 1000 Package Multiple: 1 Container: Bulk | 0 |
|
$5.2440 / $5.4630 | RFQ |
Part Details for SSA-LXB20SIW
SSA-LXB20SIW CAD Models
SSA-LXB20SIW Part Data Attributes
|
|
SSA-LXB20SIW
ITW Lumex
Buy Now
Datasheet
|
Compare Parts:
SSA-LXB20SIW
ITW Lumex
Single Color LED Array, Super High Intensity Red, Diffused Milky White, 5mm,
|
| Pbfree Code | Yes | |
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | LUMEX INC | |
| Reach Compliance Code | compliant | |
| HTS Code | 8541.40.20.00 | |
| Samacsys Manufacturer | Lumex | |
| Color | SUPER HIGH INTENSITY RED | |
| Configuration | SEPARATE, 20 ELEMENTS | |
| Forward Current-Max | 0.025 A | |
| Lens Type | DIFFUSED MILKY WHITE | |
| Luminous Intensity-Nom | 80.0 mcd | |
| Mounting Feature | RADIAL MOUNT | |
| Number of Functions | 20 | |
| Number of Terminals | 40 | |
| Operating Temperature-Max | 85 °C | |
| Operating Temperature-Min | -40 °C | |
| Optoelectronic Device Type | SINGLE COLOR LED ARRAY | |
| Overall Height | 8 mm | |
| Packing Method | BULK | |
| Peak Wavelength | 636 nm | |
| Shape | RECTANGULAR | |
| Size | 5 mm | |
| Surface Mount | NO | |
| Terminal Pitch | 2.5 mm | |
| Viewing Angle | 160 deg |
