Part Symbol
-
Footprint
-
3D Model
Available Download Formats
By downloading CAD models, you agree to our Terms & Conditions and Privacy Policy
Part Details for SPC5674FF3MVV3 by NXP Semiconductors
Results Overview of SPC5674FF3MVV3 by NXP Semiconductors
- Distributor Offerings: (8 listings)
- Number of FFF Equivalents: (0 replacements)
- CAD Models: (Available)
- Number of Functional Equivalents: (0 options)
- Part Data Attributes: (Available)
- Reference Designs: (Not Available)
Tip: Data for a part may vary between manufacturers. You can filter for manufacturers on the top of the page next to the part image and part number.
SPC5674FF3MVV3 Information
SPC5674FF3MVV3 by NXP Semiconductors is a Microcontroller.
Microcontrollers are under the broader part category of Microcontrollers and Processors.
Microcontrollers (MCUs) are small, low-power integrated circuits used to control embedded systems. Microcontrollers are primarily used to automate and control devices. Read more about Microcontrollers and Processors on our Microcontrollers and Processors part category page.
Price & Stock for SPC5674FF3MVV3
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
43W6308
|
Newark | Mcu, 32Bit, Power, 264Mhz, Pbga-516, Product Range:Mpc5 Family Mpc56Xx Series Microcontrollers, Architecture:Power Architecture, Mcu Core Size:32Bit, Program Memory Size:4Mb, Ram Memory Size:265Kb, Cpu Speed:264Mhz, No. Of I/O S:-, Rohs Compliant: No |Nxp SPC5674FF3MVV3 RoHS: Not Compliant Min Qty: 1 Package Multiple: 1 Date Code: 1 Container: Bulk | 68 |
|
$63.0000 / $86.0500 | Buy Now |
|
DISTI #
79AH6724
|
Newark | Nxp 32-Bit Mcu, Power Arch Core, 4Mb Flash, 264Mhz, -40/+125Degc, Automotive Grade, Pbga 516 Rohs Compliant: Yes |Nxp SPC5674FF3MVV3 RoHS: Compliant Min Qty: 40 Package Multiple: 1 Date Code: 0 Container: Bulk | 0 |
|
$61.5400 / $63.4600 | Buy Now |
|
DISTI #
568-13567-ND
|
DigiKey | IC MCU 32BIT 4MB FLASH 516FPBGA Min Qty: 1 Lead time: 12 Weeks Container: Tray |
120 In Stock |
|
$68.0908 / $91.4800 | Buy Now |
|
DISTI #
SPC5674FF3MVV3
|
Avnet Americas | 32 Bit Microcontroller, MPC5 Family MPC56xx Series Microcontrollers, Power Architecture, 32 bit - Trays (Alt: SPC5674FF3MVV3) RoHS: Not Compliant Min Qty: 80 Package Multiple: 40 Lead time: 12 Weeks, 0 Days Container: Tray | 0 |
|
$55.9284 / $65.7404 | Buy Now |
|
DISTI #
841-SPC5674FF3MVV3
|
Mouser Electronics | 32-bit Microcontrollers - MCU 4Mb Flash, 256k RAM RoHS: Not Compliant | 104 |
|
$70.2900 / $90.4000 | Buy Now |
|
|
Rochester Electronics | MPC5674F - MAMBA -NXP 32-bit MCU, Power Arch core, 4MB Flash RoHS: Not Compliant Status: Active Min Qty: 1 | 682 |
|
$51.6400 / $64.5500 | Buy Now |
|
DISTI #
SPC5674FF3MVV3
|
Avnet Silica | 32 Bit Microcontroller MPC5 Family MPC56xx Series Microcontrollers Power Architecture 32 bit (Alt: SPC5674FF3MVV3) RoHS: Not Compliant Min Qty: 40 Package Multiple: 40 Lead time: 14 Weeks, 0 Days | Silica - 0 |
|
Buy Now | |
|
DISTI #
SPC5674FF3MVV3
|
EBV Elektronik | 32 Bit Microcontroller MPC5 Family MPC56xx Series Microcontrollers Power Architecture 32 bit (Alt: SPC5674FF3MVV3) RoHS: Not Compliant Min Qty: 40 Package Multiple: 40 Lead time: 14 Weeks, 0 Days | EBV - 0 |
|
Buy Now |
Part Details for SPC5674FF3MVV3
SPC5674FF3MVV3 CAD Models
SPC5674FF3MVV3 Part Data Attributes
|
|
SPC5674FF3MVV3
NXP Semiconductors
Buy Now
Datasheet
|
Compare Parts:
SPC5674FF3MVV3
NXP Semiconductors
RISC MICROCONTROLLER
|
| Rohs Code | No | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | NXP SEMICONDUCTORS | |
| Reach Compliance Code | unknown | |
| ECCN Code | 3A991.A.2 | |
| HTS Code | 8542.31.00.01 | |
| Factory Lead Time | 12 Weeks | |
| Samacsys Manufacturer | NXP | |
| Has ADC | YES | |
| Address Bus Width | ||
| Bit Size | 32 | |
| Boundary Scan | YES | |
| CPU Family | E200 | |
| Clock Frequency-Max | 40 MHz | |
| DAC Channels | NO | |
| DMA Channels | YES | |
| External Data Bus Width | ||
| JESD-30 Code | S-PBGA-B516 | |
| JESD-609 Code | e0 | |
| Length | 27 mm | |
| Moisture Sensitivity Level | 3 | |
| Number of Terminals | 516 | |
| On Chip Program ROM Width | 8 | |
| Operating Temperature-Max | 125 °C | |
| Operating Temperature-Min | -40 °C | |
| PWM Channels | YES | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Code | BGA | |
| Package Equivalence Code | BGA516,26X26,40 | |
| Package Shape | SQUARE | |
| Package Style | GRID ARRAY | |
| Peak Reflow Temperature (Cel) | 245 | |
| Qualification Status | Not Qualified | |
| RAM (bytes) | 262144 | |
| ROM (words) | 4194304 | |
| ROM Programmability | FLASH | |
| Screening Level | AEC-Q100 | |
| Speed | 264 MHz | |
| Supply Current-Max | 1000 mA | |
| Supply Voltage-Max | 1.32 V | |
| Supply Voltage-Min | 1.14 V | |
| Supply Voltage-Nom | 1.2 V | |
| Surface Mount | YES | |
| Technology | CMOS | |
| Temperature Grade | AUTOMOTIVE | |
| Terminal Finish | Tin/Lead (Sn/Pb) | |
| Terminal Form | BALL | |
| Terminal Pitch | 1 mm | |
| Terminal Position | BOTTOM | |
| Time@Peak Reflow Temperature-Max (s) | 30 | |
| Width | 27 mm | |
| uPs/uCs/Peripheral ICs Type | MICROCONTROLLER, RISC |
SPC5674FF3MVV3 Frequently Asked Questions (FAQ)
-
The SPC5674FF3MVV3 can operate in a temperature range of -40°C to 125°C.
-
The clock settings can be configured using the Clock Generation Unit (CGU) module. The CGU module allows you to configure the clock sources, clock frequencies, and clock distribution. Refer to the device's reference manual for more information.
-
The maximum frequency of the CPU is 264 MHz.
-
The SPC5674FF3MVV3 has 3MB of flash memory.
-
Yes, the SPC5674FF3MVV3 is designed for safety-critical applications and is compliant with the ISO 26262 functional safety standard.
