SP1001-05XTG Information
SP1001-05XTG by Littelfuse Inc is a Transient Suppressor.
Transient Suppressors are under the broader part category of Diodes.
A diode is a electrical part that can control the direction in which the current flows in a device. Consider factors like voltage drop, current capacity, reverse voltage, and operating frequency when selecting a diode. Read more about Diodes on our Diodes part category page.
Price & Stock for SP1001-05XTG
| Part # | Distributor | Description | Stock | Price | Buy | |
|---|---|---|---|---|---|---|
|
DISTI #
28X4443
|
Newark | Diode, Tvs, Esd Protection, 12Pf, Full Reel, Clamping Voltage Vc Max:13V, Diode Case Style:Sot-563, No. Of Pins:6Pins, Operating Voltage:-, Power Dissipation Pd:-, Product Range:Spa Sp1001 Series, Automotive Qualification Standard:- Rohs Compliant: Yes |Littelfuse SP1001-05XTG RoHS: Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 0 Container: Reel | 0 |
|
$0.1990 / $0.2060 | Buy Now |
|
DISTI #
01P7746
|
Newark | Diode, Tvs, Esd Protection, 12Pf, Clamping Voltage Vc Max:13V, Diode Case Style:Sot-563, No. Of Pins:6Pins, Operating Voltage:-, Power Dissipation Pd:-, Product Range:Spa Sp1001 Series, Automotive Qualification Standard:- Rohs Compliant: Yes |Littelfuse SP1001-05XTG RoHS: Compliant Min Qty: 3000 Package Multiple: 1 Date Code: 0 Container: Cut Tape | 0 |
|
$0.2580 | Buy Now |
|
DISTI #
F2898CT-ND
|
DigiKey | TVS DIODE 5.5VWM 13VC SOT563 Min Qty: 1 Lead time: 11 Weeks Container: Digi-Reel®, Cut Tape (CT), Tape & Reel (TR) |
6565 In Stock |
|
$0.2035 / $0.5800 | Buy Now |
|
DISTI #
576-SP1001-05XTG
|
Mouser Electronics | ESD Protection Diodes / TVS Diodes 5 channels RoHS: Compliant | 4963 |
|
$0.2030 / $0.5700 | Buy Now |
|
DISTI #
V79:2366_17794282
|
Arrow Electronics | ESD Suppressor TVS Uni-Dir 5.5V 6-Pin SOT-563 T/R Automotive AEC-Q101 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Date Code: 2244 | Americas - 29780 |
|
$0.1944 / $0.3825 | Buy Now |
|
DISTI #
V72:2272_06478377
|
Arrow Electronics | ESD Suppressor TVS Uni-Dir 5.5V 6-Pin SOT-563 T/R Automotive AEC-Q101 RoHS: Compliant Min Qty: 1 Package Multiple: 1 Lead time: 11 Weeks Date Code: 2209 Container: Cut Strips | Americas - 902 |
|
$0.3863 / $0.4049 | Buy Now |
|
DISTI #
83683127
|
Verical | ESD Suppressor TVS Uni-Dir 5.5V 6-Pin SOT-563 T/R Automotive AEC-Q101 RoHS: Compliant Min Qty: 31 Package Multiple: 1 Date Code: 2244 | Americas - 29780 |
|
$0.1944 / $0.3589 | Buy Now |
|
DISTI #
78439928
|
Verical | ESD Suppressor TVS Uni-Dir 5.5V 6-Pin SOT-563 T/R Automotive AEC-Q101 RoHS: Compliant Min Qty: 132 Package Multiple: 1 | Americas - 3000 |
|
$0.2231 / $0.5110 | Buy Now |
|
DISTI #
71306282
|
Verical | ESD Suppressor TVS Uni-Dir 5.5V 6-Pin SOT-563 T/R Automotive AEC-Q101 RoHS: Compliant Min Qty: 171 Package Multiple: 1 Date Code: 2301 | Americas - 3000 |
|
$0.4170 / $0.4801 | Buy Now |
|
DISTI #
61738192
|
Verical | ESD Suppressor TVS Uni-Dir 5.5V 6-Pin SOT-563 T/R Automotive AEC-Q101 RoHS: Compliant Min Qty: 27 Package Multiple: 1 Date Code: 2209 | Americas - 902 |
|
$0.3863 / $0.3975 | Buy Now |
Part Details for SP1001-05XTG
SP1001-05XTG CAD Models
SP1001-05XTG Part Data Attributes
|
|
SP1001-05XTG
Littelfuse Inc
Buy Now
Datasheet
|
Compare Parts:
SP1001-05XTG
Littelfuse Inc
Trans Voltage Suppressor Diode, 5.5V V(RWM), Bidirectional, 5 Element, Silicon, GREEN, PLASTIC PACKAGE-6
|
| Rohs Code | Yes | |
| Part Life Cycle Code | Active | |
| Ihs Manufacturer | LITTELFUSE INC | |
| Pin Count | 6 | |
| Reach Compliance Code | compliant | |
| ECCN Code | EAR99 | |
| HTS Code | 8541.10.00.50 | |
| Samacsys Manufacturer | LITTELFUSE | |
| Additional Feature | LOW CAPACITANCE | |
| Breakdown Voltage-Nom | 6.7 V | |
| Clamping Voltage-Max | 9.7 V | |
| Configuration | COMMON ANODE, 5 ELEMENTS | |
| Diode Element Material | SILICON | |
| Diode Type | TRANS VOLTAGE SUPPRESSOR DIODE | |
| JESD-30 Code | R-PDSO-F6 | |
| JESD-609 Code | e3 | |
| Number of Elements | 5 | |
| Number of Terminals | 6 | |
| Operating Temperature-Max | 150 °C | |
| Package Body Material | PLASTIC/EPOXY | |
| Package Shape | RECTANGULAR | |
| Package Style | SMALL OUTLINE | |
| Peak Reflow Temperature (Cel) | 260 | |
| Polarity | BIDIRECTIONAL | |
| Qualification Status | Not Qualified | |
| Rep Pk Reverse Voltage-Max | 5.5 V | |
| Surface Mount | YES | |
| Technology | AVALANCHE | |
| Terminal Finish | MATTE TIN | |
| Terminal Form | FLAT | |
| Terminal Position | DUAL | |
| Time@Peak Reflow Temperature-Max (s) | 40 |
SP1001-05XTG Frequently Asked Questions (FAQ)
-
A good PCB layout for the SP1001-05XTG involves keeping the input and output traces separate, using a solid ground plane, and minimizing the distance between the TVS diode and the protected circuit. A 4-layer PCB with a dedicated ground plane is recommended.
-
The SP1001-05XTG is designed to handle high surge currents. It can withstand a maximum surge current of 100A (8/20μs) and is certified to IEC 61000-4-5 (Lightning) and ISO 7637-2 (Automotive) standards.
-
The SP1001-05XTG operates over a temperature range of -40°C to 150°C. The device's performance remains stable across this range, but the leakage current may increase at higher temperatures.
-
Yes, the SP1001-05XTG can be used in high-frequency applications up to 1 GHz. However, the device's performance may degrade at frequencies above 500 MHz due to parasitic inductance and capacitance.
-
The SP1001-05XTG is designed to withstand repetitive surges. A derating factor of 0.7 is recommended to ensure the device's reliability and prevent thermal runaway.
